OWNER'S MANUAL

M 528C-MAGE

110-013-101 REV A

ECO 202945

Date Effective: February 2018

Table of Contents

Need help?

Do you have a question about the M 528C-MAGE 32040 and is the answer not in the manual?

Questions and answers

Summary of Contents for Global Surgical M 528C-MAGE 32040

Page 1 OWNER’S MANUAL M 528C-MAGE 110-013-101 REV A ECO 202945 Date Effective: February 2018...
Page 2 IF OUTSIDE THE USA:1-636-861-3388 COPYRIGHT NOTICE © COPYRIGHT 2015, GLOBAL SURGICAL CORPORATION. NO PART OF THIS PUBLICATION MAY BE COPIED, PHOTOCOPIED, REPRODUCED, TRANSLATED, OR REDUCED TO ANY ELECTRONIC MEDIUM OR MACHINE-READABLE FORM, IN WHOLE OR IN PART, WITHOUT THE PRIOR WRITTEN CONSENT OF...
Page 3 Congratulations on your purchase of the M 528C-MAGE Image Capture System. We truly appreciate your business, and we’re grateful for the trust you’ve placed in us...
Page 4: Table Of Contents
TABLE OF CONTENTS Section 1 Important Safety Instructions ..................1-1 Symbol Definitions ........................1-1 Warnings and Cautions ......................1-2 Section 2 Product Information ....................... 2-1 Image Capture System ......................2-1 Components ..........................2-1 Section 3 Installation........................3-1 Connecting the Magewell to the Computer ................3-1 Installing the Wireless Handheld Mouse ................
Page 5: Section 1 Important Safety Instructions
Important Safety Instructions THE SAFETY AND SATISFACTION OF OUR CUSTOMERS AND THEIR PATIENTS WARNING ARE THE HIGHEST PRIORITIES OF GLOBAL SURGICAL CORPORATION. THIS MANUAL CONTAINS IMPORTANT INFORMATION REGARDING THE SAFE AND PROPER USE OF THIS EQUIPMENT AND SHOULD BE READ THOROUGHLY BY ALL OPERATORS PRIOR TO THEIR FIRST USE OF THE EQUIPMENT.
Page 6: Warnings And Cautions
ACCESSORY. USING ANY OTHER SIMILAR CABLES MIGHT CAUSE CAPTURE CAUTION PROBLEMS AND EVEN DAMAGE THE CAPTURE DEVICE. Use HDMI cables from Global Surgical to ensure proper fit and image quality. NOTICE For Instructions for use, Regulatory Information, Warranty Information see manual for NOTICE each product.
Page 7: Section 2 Product Information
Product Information 2.1 Image Capture System The Global Surgical HD cube camera is designed to provide a High Definition 1080p video signal from your microscope, which is viewed live on any connected HD televisions (HDTV) within your operatory. The Magewell USB3 Image Capture System converts the HD video signal from the camera into a live HD digital signal delivered via USB3.
Page 8 Section 2 Product Information POWER HDMI VIDEO CAMERA HDMI INPUT MAGEWELL LOOP THRU USB PORT OPTIONAL PROVIDED USB 3.0 HDMI CABLE USB2 USB3 Figure 2-1 Wiring Diagram for M 528C-MAGE Setup...
Page 9: Section 3 Installation
Section 3 Installation Please be certain that all conditions outlined in Section 8 “Computer Specifications” and “HDMI NOTICE Cable Requirements” have been met before proceeding. 3.1 Connecting the Magewell to the Computer The Magewell Device must be connected to your computer via the USB3 cable provided. Place the Magewell Device near the computer but do not yet connect it to your computer.
Page 10: Installing The Wireless Handheld Mouse
Section 3 Installation NOTE: Only a USB3 connection will provide the data transfer speed which will ensure smooth video display and recording. 7. Connect the blue USB3 cable between the Magewell Device’s SS USB port and the computer’s SS USB port (or regular USB port).
Page 11: Section 4 Troubleshooting The Installation
Section 4 Troubleshooting The Installation Table 4-1 Troubleshooting Problem Solution Check all of your connections Leave everything connected and powered, and restart your Camera doesn’t appear in the “Devices” computer. or “Device Manager” list. Disconnect and then reconnect each connection and the camera power plug sequentially, one at a time while watching for the connection to be established If an HD Television is connected, use the TV menu to select the input matching the port on your...
Page 12: Section 5 Capture Express Software
Section 5 Capture Express Software 5.1 Installing Capture Express software: Make certain: • The Magewell Device is connected to your computer with the provided USB3 cable. • Your HDMI camera is connected to the “Input” of your Magewell Device • Your HDMI camera is connected to power, and powered on.
Page 13: Capture Express Software Controls
2. “Start” and “Stop” buttons at the lower right are used to capture video. Sound can be recorded as well if you have a mic. Contact Global Surgical Technical Service for additional instructions. 3. A Video Recording Timer display is provided in the center at the bottom of the window.
Page 14: Section 6 Specifications
IT Department or your contractor for assistance). • Purchase your HDMI cables from Global Surgical to ensure proper fit and image quality. See Table 3-2 • Install the HDMI cable runs from the microscope location to your computer location and as needed from your computer location out to your HDTVs.
Page 15 Global Surgical Corporation 3610 Tree Court Industrial Blvd. St. Louis, MO 63122 EMERGO EUROPE Prinsessegracht 20 2514 AP The Hague The Netherlands...
