Summary of Contents for 360 FLY 360 FLY

  • Page 1 Quick Start Guide www.360fly.com...
  • Page 2 Your 360fly has landed. Build your profile and join the 360° uprising at 360fly.com 360fly password: (If you’re one to forget these types of things, maybe write it here.) facebook.com/360fly twitter.com/360fly...
  • Page 3 Congratulations on your new camera! With the world’s widest single lens field of view and your unique POV, you now have the power to step outside the border. Beyond the frame. And into the fully immersive, interactive world of 360° video. You’re now part of a new community of visual storytellers, one that will fundamentally change the way we see...
  • Page 4 Let’s do this. Step 1: Download our 360fly app. The 360fly app is key to capturing your entire world. Just search “360fly” in the App Store or Google Play and download it to your mobile device. Launch the app to set up your camera and build a 360fly profile.
  • Page 5 the power to edit and share clips on the fly. In other words, get it already. Step 2: Remove camera from the packaging and Tilt Mount. NOTE: DO NOT THROW AWAY the Tilt Mount. (For the ins and outs, see the Tilt Mount section.) Step 3: Charge your camera for at least 30 minutes by placing it on...
  • Page 6 Step 4: Remove camera from its Power Cradle and turn it on by holding the OnePush button down for 4 seconds. Step 5: Connect your mobile device and camera by tapping the “camera” icon in the app. Now tap the camera drop down arrow to add or select a camera.
  • Page 7 NOTE: For iOS, exit the app, go to your device’s “Settings” and connect to your camera’s wifi. Step 7: Stick your baseplates and mounts on anything that moves… then start capturing and sharing everything around you in 360 degree HD video.
  • Page 8 Power to fly. Your 360fly is powered on, records and powers off with its OnePush button. It also vibrates to inform you of its state. To power on your 360fly, press and hold the OnePush button for 4 seconds. The camera will vibrate three times.
  • Page 9 press the OnePush button. The camera will vibrate once and the light will turn red. Just remember, red’s recording. To stop recording, press the OnePush button. The camera will vibrate two times and the light will return to blue. To power off your 360fly, press and hold the OnePush button for 3 seconds.
  • Page 10 Capturing full 360° video. Your 360fly isn’t just a camera. It’s the new eye of social media, putting you at the center of the action while allowing viewers to explore every angle, every POV and every visual sensation of your adventures. To record through the 360fly app, select the Camera icon.
  • Page 11 Tap the white Record button in the center to start capturing. Your camera will vibrate and its LED will turn from blue to red. To stop recording, tap the now red Record button. You can review any footage recorded on your camera by going to the “On My Camera”...
  • Page 12 360fly edits and sharing. 360fly gives you the power to capture, edit and share online up to 2 minutes of your most epic footage directly from your mobile device. To edit and share footage you’ve captured, launch the 360fly app, tap the “Camera”...
  • Page 13 Select the video you want to edit and you’ll enter the Player view. Tap the Edit button, bottom right. Three options for editing your clip will appear: Clip Capture , Watch Me Still Capture . These easy-to-use features will allow you to edit your footage, add filters, create slo-mo / fast-motion segments, even add a soundtrack.
  • Page 14 A new reality in virtual reality. 360fly’s footage is designed to work seamlessly with Google Cardboard VR Viewers. To watch your footage using a Google Cardboard VR Viewer, just tap the “Viewer” icon top right when you’re in the Player screen. Words don’t do it justice, so be sure to get a headset and explore 360fly VR for yourself.
  • Page 15 Google Cardboard VR Viewer...
  • Page 16 Footage, memory space and a good trashing. Your 360fly is a lens, camera and storage device all in one. Its internal battery and 32GB memory gives you the power to capture approximately 2 hours of 360° HD footage each time out. To view footage on your mobile device, open the 360fly app, tap the Camera icon and select the...
  • Page 17 “On My Camera” tab. To view, edit and explore 360° footage on your computer, download the 360fly Director at 360fly.com/Director. Use your Power Cradle to connect your camera to your computer and then simply drag the clips you wish to view from your camera to the Director.
  • Page 18 from your desktop. In the app, simply swipe to the left on iOS or press and hold on a clip on Android to reveal the “Trash” icon. From your desktop, dock the camera to your computer, select the clips you want to remove and drag them to the trash.
  • Page 19 Charging. To charge, insert USB cable into a compatible USB outlet adapter (Example: most smartphone chargers). For best results, charge while the device is powered off.
  • Page 20 What’s in the box. USB Cable 360fly Tilt Mount Action Camera Adapter...
  • Page 21 Power Cradle Mic Plug & Strap Baseplate: Curved Baseplate: Flat Pouch...
  • Page 22 Know and love your 360fly. OnePush Button Tilt Mount Buttons...
  • Page 23 Reset Button Bottom of Camera Power Cradle Straphole MIC Hole Mic Plug Lock Hole Guide...
  • Page 24 Removing Tilt Mounts. Press and hold both Turn the Tilt Mount Tilt Mount buttons. counter clockwise.
  • Page 25 Remove the Tilt Mount Twist the 360fly camera from the baseplate. off the Tilt Mount.
  • Page 26 Attaching Tilt Mounts. Align 360fly and Tilt Mount. Turn clockwise to lock.
  • Page 27 360fly can only be attached to the Tilt Mount in one direction.
  • Page 28 Stick your landings. Attach your 360fly camera to helmets, boards and virtually any gear with its flat and curved baseplates. Attaching baseplates. First, be sure to use the baseplate that matches the surface’s curvature. Now follow the three steps on the next page to ensure a secure fit.
  • Page 29 Flat or curved? FLAT CURVED (i.e. snowboard, table) (i.e. helmet)
  • Page 30 Attaching baseplates to surfaces. Make sure the surface Remove backing paper is cleaned and dry. on baseplate adhesive.
  • Page 31 Attach the baseplate with the arrow facing FRONT (i.e. front of the helmet).
  • Page 32 Attaching Tilt Mounts to baseplates. Align 360fly and Tilt Mount.
  • Page 33 Turn the Tilt Mount Turn until you hear clockwise. “click” to fully lock.
  • Page 34 Action Camera Adapter. The Action Camera Adapter included with your 360fly lets you attach your camera to most other popular action camera mounts you already own, making it even easier for you to capture every angle of every ride, turn, slope, wave, game, race and adventure.
  • Page 36 Long live your 360fly. Your 360fly camera is built to stand up to rigors of your active lifestyle. That said, there are a few things you can do to help it capture cleaner footage for years to come. The all-important Mic Plug. With its Mic Plug securely in place, your 360fly camera is water resistant down to 5ATM.
  • Page 37 Always, always use the Mic Plug to protect your camera in and around water. Failure to use it as recommended could lead to water damage and void the warranty. NOTE: The Mic Plug should always be stored on the side of your Tilt Mount when not in use.
  • Page 38 The all-important Mic Plug. Push and turn to fully Push the Mic Plug secure the Mic Plug. into the microphone When using the Mic Plug, hole to insert it. audio will NOT be available.
  • Page 39 Use Mic Plug when 360fly could be When not using the submerged. Mic Plug, store it in the hole on the side Failure to use the Mic of the Tilt Mount. Plug voids warranty.
  • Page 40 Keep it clean. A clean lens means cleaner footage. 360 fly’s lens can be cleaned using a clean, soft cloth. Lens cleaning solution, water or isopropyl alcohol can be used for additional cleaning. Always remember to insert the Mic Plug and wash off your camera after saltwater use.
  • Page 41 Use your pouch, friend. Return your 360fly to its pouch after use to help protect its lens from scratching, chipping or other damage.
  • Page 42 The rare reset. Reset Button Bottom of Camera...
  • Page 43 On rare occasions, it might become necessary to reset your 360fly if it becomes unresponsive. Step 1: Locate the reset button on the bottom of the unit. Step 2: Use a dull pointed object such as a paper clip to quickly press and release the reset button.
  • Page 44 Now let’s see it. During its development, the 360fly was tested and refined by some of the world’s top athletes, techies, optical engineers, videographers and visual artists. And while they captured and created some amazing content, we’re still in the early days of 360°...
  • Page 45 If you’re still reading this, you obviously have good vision and an even greater sense of curiosity. We’re guessing you also have the talent and creativity to do things with this camera even we couldn’t imagine. We can’t wait to see it. facebook.com/360fly twitter.com/360fly...
  • Page 46 Support, FAQs and troubleshooting. For all your support needs, FAQs, user input and additional details, please visit 360fly.com/support. Things can and do change. To view or download our most up-to-date Quick Start Guide, visit 360fly.com/QuickStartGuide.
  • Page 48 www.360fly.com © 2015 360fly, Inc. All Rights Reserved. 360fly, the Fly Icon and 360fly(icon) are trademarks of 360fly, Inc. All other trademarks are property of their respective owners. For a complete list of patents, please visit www.360fly.com/patents...
