LUMISSION 6200012 Quick Start Manual

Technical specifica ons
RoHS
EN60598-2-22
2002/95/EC 2006/95/EC
Power
Voltage driver
Opera on Func ons
Test Func ons ( Auto Test )
Power factor
Colour
Colour temperature
Luminous flux (AC)
Luminous flux (DC ba .)
Expected life me L80B20
Dimensions H / W / L
Ba ery type
Ba ery protec on
Ba ery autonomy
Ba ery replacement
(Fig 1.2)
Installa on Instruc on
* These following instructions are intended soley for trained electricians or
the installation company responsible.
* Always read the manual and safety instructions before installing the
emergency bulkhead.
* Switch off or disconnect the mains before starting installation (fig 1.3)
* Remove the diffusor from the body by removing the two crosshead screws.
* The gear tray hinges by pushing the two market (>>) clamps outwards.
* Mount the bulkhead fixture with suitable screws and dowels at the desired
location on a wall / roof.
* Make use of the included grommet or a PG-gland (fig 2.1) to maintain IP65.
* Make sure the battery is connected by the DC-plug system fixed on the PCB
main board. The battery must be charged for at least 24hours.
* Connect the bulkhead fixture according to the IEE wiring regulations and
follow the instruction illustrated in fig 1.4 to choose the desired operation
mode of the emergency bulkhead.
* For fixture spacing information see fig 1.5
IK 08
IP65
355mm
Selfy Emergency Bulkhead 7W AT
Product code(s)
6200012 (down)
6267809
6200014 (right)
220~240VAC 50/60Hz
(Non) Con nuous / Switched
Automa c Self Test ( Month / year IEC 62034 )
79 / 119 / 355 mm
4,8V 1800mAh Ni-Cd
Overload and unloading
119mm
Ø20mm
6200013 (le )
6200011 (up)
3hrs
AT
7 Wa
(+/-10%)
> 0,75
white
4000K
300 lm
130-180 lm
50000 hours
3 hours
Every 4 years
(product code: 6200015)
(Fig 1.3)
Mains 220-240V (50/60Hz)
!
(Fig 1.4)
con nuous con nuous / switched
A
Terminal Connection Matrix:
A) operation mode (continuous )
B) operation mode (switched on/off )
C) operation mode (non-continuous )
(Fig 1.5)
spacing
1,7 2,3
H=2,5m
1,6 2,2
H= 3m
0,7 1,8
H= 4m
(Fig 1.1)
OFF !
ON
non con nuous
B C
LS L N E Battery
Control Led
v + v v v
connected Green/on
v v v
connected Green/on
switch
- v v v
connected Green/on
6,8 4,7
6,7 4,7
6,6 4,7
©Version 2019
