- Page 1 Mounting Hardware OWNERS MANUAL ARMS260-AR Swing Away Hardware for IDM-ALLROUND-9 & IDM-ARLITE Joysticks...
- Page 2 Customer Satisfaction Stealth Products strives for 100% customer satisfaction. Your complete satisfaction is important. Please contact us with feedback or suggested changes that will help improve the quality and usability of our products. You may reach us at: Stealth Products, LLC...
- Page 3 Important Information Important Information All persons responsible for fitting, adjustment, and daily use of the devices discussed in these instructions must be familiar with and understand all safety aspects of the devices mentioned. In order for our products to be used successfully, you must: •...
-
Page 4: Introduction
Ordering Documentation You can download additional copies of this manual on the Stealth website: https://stlpro.site/stealth-docs and search: ARMS260-AR Owners Manual in the search bar at the top of the page. -
Page 5: Warranty
Warranty Our products are designed, manufactured, and produced to the highest of standards. If any defect in material or workmanship is found, Stealth Products will repair or replace the product at our discretion. Any implied warranty, including the implied warranties of merchantability and fitness for a particular purpose, shall not extend beyond the duration of this warranty. -
Page 6: Table Of Contents
9.1 Mounting Hardware Parts ................3 9.2 Tools ........................5 10.0 Functioning ..................... 6 10.1 Features of the ARMS260-AR ................ 6 10.2 Mounting Options ..................... 6 11.0 Installation Instructions ................. 7 11.1 Installing ARM260 Rod to Arm Rest Track ..........7 11.2 Installing Joystick Mount to Lateral Rod .......... - Page 7 Table of Contents 12.0 First Time Use ..................12 12.1 Dealer Assistance .................... 12 12.2 User Testing ..................... 12 12.3 Conditions of Use ..................12 13.0 Maintenance ..................13 13.1 Maintenance ....................13 13.2 Cleaning ......................13 13.3 Disinfecting ...................... 13 14.0 Notes ......................
-
Page 8: Warning Labels
SAFETY necessary. Limited Liability Stealth Products, LLC accepts no liability for personal injury or damage to property that may arise from the failure of the user or other persons to follow the recommendations, warnings, and instructions in this manual. Stealth Products does not hold responsibility for final integration of final assembly of product to end user. -
Page 9: Safety Precautions
Safety Precautions • • • 260- • • 260- • CAUTION Watch out for pinch points while operating the ARMS260-AR. Fingers or small wires/tubing must be away from the flip-down sleeve while engaging. viii... -
Page 10: Design And Function
& rotation of the input device at multiple points. Features The ARMS260-AR Swing Away system allows versatile and on demand adjustment. The system offers depth, height, and angle adjustment. Rod can be bent and cut to accommodate specifications.* It rests within the swing away ball which allows for a 30°... - Page 11 Installation Instructions...
-
Page 12: Parts And Accessories
Parts and Accessories Mounting Hardware Parts ARMS260-AR Item Description ARM260 Rod 3/4” ARM260 Track Mount GAT406 Track Lateral Rod 18” Lateral Rod Mount Mini-Hitch Joystick Mount Permobil Ear Assembly Swing-Away... - Page 13 Parts and Accessories Item Description Locknut M5 Locknut Socket Head Screw M5 x 0.8 x 18MM Socket Head Shoulder Screw Socket Set Screw #10-32 x 1/8” Socket Cap Cup Point Set Screw Socket Head Screw 1/4-20 x 5/8” Socket Head Screw Socket Head Screw 1/43-20 x 3/4”...
-
Page 14: Tools
Parts and Accessories Tools The tools you will need to complete installation are as follows: Hardware Description 3/16” T-Handle Socket Head Screws on Track Mount 5/32” T-Handle Button Head Screws on Mini-Hitch Swivel Mount 3/32” T-Handle Socket Head Screw on Mini-Hitch Swivel Mount 4MM T-Handle Socket Head Shoulder Screw on Swing-Away Ear Assembly 3MM T-Handle... -
Page 15: Functioning
Functioning 10.0 Features of the ARMS260-AR 10.1 d Li • r id i • • & d d r • 110 d r • • • • S 0 r d • Mounting Options 10.2 There are many mounting options available: 10-I •... -
Page 16: Installation Instructions
Installation Instructions 11.0 Installing ARM260 Rod to Arm Rest Track 11.1 Pri r 1/4- 0 x 5/8” Step 1: d S r (B1) r Step 2: r i i d ir d 230in-lbs of torque to hold in place. Step 3: Loosen the 1/4-20 x 3/4”... -
Page 17: Installing Joystick Mount To Lateral Rod
Installation Instructions 11.0 Installing Joystick Mount to Lateral Rod 11.2 Loosen the M5 x 0.8 x 14mm Socket Head Screws (F1) on the Swing-Away Ear Step 1: Assembly (F). Step 2: Install the Lateral Rod (A) into the Swing-Away Ear Assembly (F). rior to inser ng the Lateral Rod (C), remove the End Cap (C1). - Page 18 Installation Instructions 11.0 Step 4: #10-24 x 1/2” 90in-lbs of torque to lock in place Step 5: then reapply the End Cap (C1) to the Lateral Rod (A). NOTICE Tighten the set screws with the client in the chair and make any final adjustments necessary.
-
Page 19: Installing Joystick To The Mount
Installation Instructions 11.0 Installing Joystick to the Mount 11.3 Step 1: Step 2: 2.9nM of torque Step 3: CAUTION Ensure that all screws are tightened evenly on the hardware. Threads can strip out and cause damage to the hardware if not tightened properly. -
Page 20: Flip-Down Mount
Installation Instructions 11.0 Flip-Down Mount 11.4 Check that the #10- cket Ca C t et c e Step 1: hte the c e a te t e that the ee e ca e a e a e a e th a a e c ck Check the the fl... -
Page 21: First Time Use
12.2 It is important that the customer is fully aware of the installation of the ARMS260-AR, how to use it, and how it can be adjusted to fit the client comfortably. As a dealer, proceed as follows: the c t... -
Page 22: Maintenance
Maintenance 13.0 SAFETY For joystick maintenance guidelines refer to the device’s user manual. Maintenance 13.1 Check every 6 months that screws are tightened back to their torque specifications. Gently tighten any screws that may have become loose. Maintain that the hardware is clean and free of dust. ... -
Page 23: Notes
NOTES 14.0... - Page 24 Stealth Products, LLC. • info@stealthproducts.com • www.stealthproducts.com +1(800) 965-9229 | +1(512) 715-9995 | 104 John Kelly Drive, Burnet TX 78611 P120D533 Revision Date 2019-12-17...
