**Keep all packaging materials after opening. Gobo must be returned in same box / packaging.**
SETUP GOBO
1.
Plug gobo into outlet using power cord provided. It is pre-loaded with your design/color.
2.
Place gobo projector on a table and point it where you want to project the image, such as a wall.
Use the bracket to adjust the angle. See example picture below.
SPECIAL PROGRAMMING WITH REMOTE
If you need to align or rotate your image, locate the remote control provided. Point remote at the back of the
gobo projector. Press the "Speed" button, and then press "Fade/Snap" to rotate the image right or left. When
your image is lined up how you would like, press the "Manual" button to lock it in place
Press "BLACK OUT" to
turn gobo off/on.
SETUP VIDEOS: www.YouTube.com/RentMyWedding PHONE: 1-800-465-8020 WEB: www.RentMyWedding.com
PRO GOBO – SETUP INSTRUCTIONS
PLEASE HANDLE WITH CARE – PROJECTORS ARE FRAGILE!
.
Press "Speed" for rotation.
Press "Fade/Snap" to change
direction of rotation.
Press "Manual" to stop
rotation.
.... ...Continued on Reverse Side
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for Chauvet DJ PRO GOBO
Summary of Contents for Chauvet DJ PRO GOBO
- Page 1 PRO GOBO – SETUP INSTRUCTIONS **Keep all packaging materials after opening. Gobo must be returned in same box / packaging.** PLEASE HANDLE WITH CARE – PROJECTORS ARE FRAGILE! SETUP GOBO Plug gobo into outlet using power cord provided. It is pre-loaded with your design/color.
- Page 2 ADJUST PROJECTION IMAGE 1. Twist focus knob to the left or right until the image is in focus Twist knob to adjust the focus of the projection. YOU’RE DONE! RETURN INSTRUCTIONS 1. To return gobo with other rental items: Put gobo back in the plastic case. Place plastic case back in cardboard shipping box with other rental items.
