Summary of Contents for PIKE Technologies CrushIR 181-1 Series
- Page 1 Installation and User Guide CrushIR 15 Ton Hydraulic Press...
- Page 3 PIKE Technologies, Inc. nor the rights of others. PIKE Technologies Inc. does not assume any liability arising out of any infringements of patents or other rights of third parties.
-
Page 4: Table Of Contents
Contents Introduction Design Diagram Unpacking Your Accessory Packing list Installation Graphic Diagram Precautions Maximum Force Safety Specifications Cleaning Procedures Voltage Ratings Power Supply Definitions Labels Replacement Parts List... -
Page 5: Introduction
CrushIR™ provides excellent reproducibility and efficient operation. Its adjustable open port design allows for easy insertion and removal of the pellet press and heated platens, both available from PIKE Technologies. The PIKE CrushIR includes a transparent protective shield making it safe for operation in a busy laboratory environment. -
Page 6: Unpacking Your Accessory
Unpacking Your Accessory In order for you to quickly verify receipt of your accessory, we have included a packing list. Please inspect the contents of the shipping box carefully. Contact PIKE immediately if any discrepancies are found. The CrushIR is packed in a wooden shipping box. Remove screws from the box to take off the cover of the shipping box. -
Page 7: Installation
Installation Using the 3/16” hex wrench, fully loosen the hydraulic fluid retaining screw located at the right, upper side of the CrushIR. NOTE: THE CrushIR WILL NOT FUNCTION UNLESS THIS SCREW IS LOOSENED. WARNING - ALWAYS CLOSE THE FLUID RETAINING SCREW TO TRANSPORT OR TILT THE CrushIR. Install the hydraulic press arm onto the CrushIR by pushing it over the bar and then rotating it clockwise into its locked position. -
Page 8: Precautions
Precautions Maximum Force The CrushIR can deliver up to 15 tons of force. Do not exceed the maximum force rating of the pellet press. For example, the PIKE Evacuable Pellet Press has a maximum force rating of 10 tons. Carefully review the user manual for your pellet press to find its maximum force rating. -
Page 9: Power Supply Definitions
Power Supply Symbol Definitions DC Direct Current AC Alternating Current Equipment protected throughout by Double or Reinforced Insulation Special Handling Requirements for KBr Powder Read and follow the MSDS sheet recommendations for the KBr Powder prior to use. Observe all safety precautions and procedures while handling the KBr powder and finished pressed pellets. -
Page 10: Replacement Parts List
Replacement Parts and Options The following parts and options may be ordered for the CrushIR accessory: Part Number Description 076-1000 DC Power Supply 181-0028 Press Handle 410-0058 3/16” Hex Wrench Other PIKE products available for work with the Hydraulic Press 160-8010 KBr Powder 100g 161-1900... - Page 11 PN 350-181110-06 P a g e...
