Acnodes APM 5084 Specifications

» Specifications
Material:
6mm Aluminum (Front panel bezel)
1.2mm Steel (Rear case)
LCD Panel:
Display Size 8.4 inch diagonal (170.4H x 127.8V)
Resolution 800 x 600, VGA
Ratio: 4:3
Display Color 262,144 color
Brightness 220 cd/m2
Contrast Ratio 250 : 1 (Typical) Pixel Pitch 0.203 x 0.203
m m
Viewing Angle 60 / 60 / 60 / 40 (L / R / U / D)
LCD MTBF. 50,000 hrs
Touch Screen (optional item):
Resistive-type:
Thickness 1.8mm, Light transmission 75%, Durability 35
Million, Controller Interface Serial / USB
Capacitive-type:
Thickness 3mm, Light transmission 85%, Durability 225
Million
Controller Interface Serial / USB
Optional Video Input:
Video Input : S-Video and Composite
Input Connectors : RCA, S-video
Power Adpater:
External type,110 ~ 220 VAC at 50 or 60Hz via
AC adapter (12V), 12V DC Output,
Adapter size : 108(W)x64(H)x30Dmm, UL & CE
Optional DC Power:
48V / 24V / 12V DC Power
Input Range:
10~36V(DC-12V, DC-24V model)
36~75V (DC-48V model)
DC power Output : DC 12V
Voltage Accuracy: +/- 1% (Max.)
Safety : Continuous short circuit protection
On Screen Control:
OSD Control Brightness, Contrast, Phase & Color,
H & V position, Auto-tune & Recall
20957 Currier Road Suite #D
Walnut, CA 91789
tel: 909.598.7388, fax: 909.598.0218
APM 5084
8.4" 800 x 600 TFT LCD
Aluminum front bezel
Panel / VESA mount ready
» Features
» Panel mount LCD monitor,
» 8.4" 800x600 TFT LCD display
» OSD (On Screen Display) function
» VESA-mount or wall-mount ready
» 15-pins VGA connector, optional for s-video / composite
» External 110/220VAC power adapter
Video Signal Input:
Input Video Signal: Analog RGB
Video Level: Analog: 0.7Vp-p
Sync Type: Separate H/V, Composite H/V
Input Connector: D-Sub 15 pin VGA analog
Video Input Connector:
Input Connector: D-Sub 15 pin VGA analog
Input Connectors : RCA, S-video (optiopnal)
Mounting Type:
VESA-mount, Panel mount,
Wall-mount & Bracket mount
Environmental:
Operating Temperature: -0 to 50°C
Storage Temperature: -10 to 60°C
Humidity:
5 - 90%, non condensing
Shock:
10G peak acceleration, ( 11ms duration)
Vibration:
5~500Hz/1G RMS
Product Weight:
Weight: 2.0 kg/4.5lbs
Dimension:
Dimension 250(W ) x 183(H) x 43(D) mm
Certification:
FCC, CE
» Ordering Guide
APM 5084:
8.4" 800x600 panel mount LCD monitor with Aluminum front
bezel
» Options
APM 5084T: 8.4" with RS-232 resistive-type touch screen
APM 5084TU: 8.4" with USB reistive-type touch screen
© Copyright 2007 Acnodes, Inc.
All rights reserved. Product description and product specifications
are subject to change without notice. For latest product information,
please visit Acnodes' web site at www.acnodes.com.
43mm depth
