Christie NAS-S2 Instruction Sheet

Configuring for gdc sr-1000 imb
Hide thumbs Also See for NAS-S2:
1
2
3
4
5

Advertisement

Table of Contents

Configuring Christie
NAS-S2 for GDC
SR-1000 IMB
This document describes the steps for configuring the Christie NAS-S2 as the content storage device
for the GDC SR-1000 Standalone Integrated Media Block
To perform configuration changes on the GDC IMB, you must have Maintenance level permissions.
Affected products
These instructions apply to the following product.
•
Christie NAS-S2 (P/N: 108-502108-XX)
Prerequisites
The following components are required.
•
GDC SR-1000 Standalone Integrated Media Block
Overview of configuration steps
Understand the required steps for connecting the Christie NAS-S2 as a storage device for the GDC
IMB.
•
Set the Christie NAS-S2 IP address to a different subnet than the GDC IMB. For more
information, see Changing the IP address of the NAS-S2 (on page 2).
•
Delete all Christie content files from the NAS-S2. For more information, see Deleting Christie
content files (on page 3).
•
Configure the ETH1 port of the GDC IMB to an IP address compatible with the Christie NAS-S2.
For more information, see Configuring the ETH1 port on the GDC IMB (on page 4).
•
Configure the GDC IMB to use the Christie NAS-S2 as a storage device. For more information,
see Configuring storage (on page 5).
Christie NAS-S2 Configuration for GDC IMB Instruction Sheet
020-102909-02 Rev. 1 (01-2019)
Copyright
2019 Christie Digital Systems USA, Inc. All rights reserved.
©
(GDC IMB).
™
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NAS-S2 and is the answer not in the manual?

Questions and answers

Related Manuals for Christie NAS-S2

Summary of Contents for Christie NAS-S2

  • Page 1 Delete all Christie content files from the NAS-S2. For more information, see Deleting Christie content files (on page 3). • Configure the ETH1 port of the GDC IMB to an IP address compatible with the Christie NAS-S2. For more information, see Configuring the ETH1 port on the GDC IMB (on page 4). •...
  • Page 2 Configuring Christie NAS-S2 for GDC SR-1000 IMB Changing the IP address of the NAS-S2 Configure the IP address of the Christie NAS-S2 to be on a different subnet than the GDC IMB. This example sets the IP address of the Christie NAS-S2 to 10.10.10.101.
  • Page 3 10.10.10.101:8080/. Deleting Christie content files Before using the Christie NAS-S2 to store content for the GDC IMB, it is important to delete any pre- loaded files or content files previously ingested for use with the Christie IMB-S2. Content files used by the Christie IMB-S2 are stored in the /Content/cinemalib share folder. Use the NAS-S2 web interface to delete the cinemalib folder by temporarily connecting a computer to the Christie NAS-S2 device.
  • Page 4 4. Under IMB Ethernet 1, configure an IP address compatible with the IP address of the Christie NAS-S2. The IP address of the IMB Ethernet 1 port must be different than the IP address of the Christie NAS-S2, but must be on the same subnet (for example, 10.10.10.102).
  • Page 5 7. Click the Dashboard tab. 8. To reboot the GDC IMB, click Restart. Files ingested by the GDC IMB are stored in the /Content share folder on the Christie NAS-S2. Verifying device communication After the GDC IMB establishes a connection with the Christie NAS-S2, the available and total storage space on the Christie NAS-S2 is displayed on the Dashboard.
