GRC Series Storage Rack
TOOLS REQUIRED FOR ASSEMBLY
Electric Hand Drill, Phillips Head Bit, 3/8" Magnetic Hex
Driver Bit. 3/8" Open end wrench.
BEFORE ASSEMBLING THE WORKBENCH
Read through the assembly instructions to familiarize
yourself with the order in which the parts are
assembled.
We suggest that you clear & vacuum the area where
the bench is to be assembled.
It is important that the bench is assembled in the
same sequence as instructed.
HARDWARE
All assembly hardware is provided.
Universal
End Panel
Top/Bottom Pan
Back Panel
Upright Frame
Shelf
GR Shelf Clip
Upright Frame
Universal
Top/Bottom Pan
Advertisement
Summary of Contents for IGMI GRC Series
- Page 1 GRC Series Storage Rack TOOLS REQUIRED FOR ASSEMBLY Electric Hand Drill, Phillips Head Bit, 3/8" Magnetic Hex Driver Bit. 3/8” Open end wrench. BEFORE ASSEMBLING THE WORKBENCH Read through the assembly instructions to familiarize yourself with the order in which the parts are assembled.
- Page 2 Upright Top Begin by choosing your assembly location Indication Punch carefully. As the entire rack will be quite cumbersome to move once partially assembled. You will be required to access the back of the rack sections to install the back panels. Keep this in mind when choosing where to begin your assembly.
- Page 3 Optional End Panels. Install the end panels by positioning the panel as shown and resting the weight of the panel on the ground. With 2 people, lift the panel slightly off the ground to catch the formed steel hooks into the square holes in the upright.
- Page 4 Install the shelf clips (16 per unit) into the upright slots as shown in the illustration. Lower the shelf onto the GR shelf clips. Continue by positioning the remaining shelf clips at the desired Shelf height for your remaining shelves. Lower the remaining shelves onto the clips.
