Acer PD310 User Manual

Svga single chip 0.7” dlp projector.
Hide thumbs

Advertisement

Table of Contents

Precautions ........................................................................................... 2
Product Features ................................................................................... 3
Package Overview ................................................................................ 4
Product Overview ................................................................................. 5
Connecting the Projector ...................................................................... 7
Powering On/Off the Projector .............................................................. 8
Adjusting the Projected Image ............................................................... 10
On-Screen Display Menus ..................................................................... 14
Troubleshooting .................................................................................... 21
Changing the Lamp ............................................................................... 24
Specifications ........................................................................................ 25
Compatibility Modes .............................................................................. 26
1
English

Advertisement

   Related Manuals for Acer PD310

   Summary of Contents for Acer PD310

  • Page 1: Table Of Contents

    Table of Contents Usage Notice Precautions ... 2 Introduction Product Features ... 3 Package Overview ... 4 Product Overview ... 5 Installation Connecting the Projector ... 7 Powering On/Off the Projector ... 8 Adjusting the Projected Image ... 10 User Controls Panel Control &...
  • Page 2: Usage Notice

    English Usage Notice Do not look into the lens. The bright light may hurt your eyes. To reduce the risk of fire or electric shock, do not expose this product to rain or moisture. Please do not open or disassemble the product as this may cause electric shock.
  • Page 3: Introduction Product Features

    Introduction Product Features This product is a SVGA single chip 0.7” DLP  Projector. The outstanding features of it are listed as follows: True SVGA, 800 x 600 addressable pixels 3.3 lbs. (1.5 kgs) lightweight compact design  Single chip DLP technology XGA compression and VGA, SVGA re-sizing 130 Watts user replaceable P-VIP lamp...
  • Page 4: Package Overview

    English Package Overview This projector comes with all the items shown below. Check to make sure your unit is complete. Contact your dealer immediately if anything is missing. Projector Power Cord VGA Signal Cable Audio Cable Composite Video Cable S-Video Cable RCA to D-Sub Cable Carrying Case Remote Control...
  • Page 5: Product Overview

    Product Overview Panel Control Temperature Warning LED Main Unit Elevator Button Remote Control Receiver Focus Ring Zoom Lens Connection Ports HDTV/Component Video & Computer Input Connector Enter / Volume Mute Source Resync Four Directional Menu Select Keys (On/Off) Speaker Zoom Ring Audio Input S-video Input Connector...
  • Page 6: Remote Control

    English Remote Control Source Power / Standby Reset Resync Freeze Mute Menu Keystone Correction Volume ( + / - ) Four Directional Select Keys Enter Zoom In / Zoom Out...
  • Page 7: Installation Connecting The Projector

    Installation Connecting the Projector Digital Tuner Output Antenna RGB Port VGA Signal Cable RGB Port VGA Signal Cable To ensure the projector works well with your computer, please configure the display mode of your graphic card to make it less than or equal to 800 X 600 resolution.
  • Page 8: Powering On/off The Projector

    English Power On/Off the Projector Powering On the Projector 1. Remove the lens cap. 2. Ensure that the power cord and signal cable are securely connected. 3. The “Power/Standby” indicator will flash. button again to start on your projector. The startup screen will display and count down for 20 seconds and the Power/ Standby indicator will light solid amber.
  • Page 9: Powering Off The Projector

    Powering Off the Projector 1. Press the “Power/Standby” button to turn off the projector lamp. 2. After pressing the “Power/Standby” button, you will see a message “Power off the lamp?” on the on-screen display. Press the “Power/Standby” button again to confirm.
  • Page 10: Adjusting The Projected Image

    English Adjusting the Projected Image Adjusting the Projector Height The projector is equipped with an elevator foot for adjusting the projector height. To raise the projector: 1. Press the elevator button 2. Raise the projector to the desired display angle lock the elevator foot into position.
  • Page 11: Adjusting Projection Image Size

    Adjusting the Projector Zoom / Focus You may adjust zoom ring to zoom in / out. Rotate the zoom ring counter-clockwise to zoom in and clockwise to zoom out. To focus the image, rotate the focus ring until the image is clear. The projector will focus at distances from 3.3 feet to 39.4 feet (1m to 12m).
  • Page 12: User Controls Panel Control & Remote Control

    English User Controls Panel Control & Remote Control There are two ways for you to control the function: Remote Control and Panel Control. Power / Standby Refer to the “Power On/Off the Projector” section on page 8~9. Source Press “Source” to choose RGB, Digital RGB, S-Video and Composite sources. Reset When you press the “Reset”...
  • Page 13 Use the Panel Control Automatically synchronizes the projector to the input source, when you press this button while the OSD isn’t displayed. Four Directional Select Keys to select items. Use Menu Press “Menu” to open the on-screen display (OSD) menus and press select main menu .
  • Page 14: On-screen Display Menus

    English On-Screen Display Menus How to operate The Projector has a multilingual On-Screen Display(OSD) menus that allow you to make image adjustments and change a variety of settings. In computer source, the OSD will be the “Computer OSD”. In video source, the OSD will be the “...
  • Page 15: Color Temperature

    Image-I (Computer mode) Brightness Adjusting the brightness of the image. Press the to darken the image. Press the to lighten the image. Contrast The contrast controls the degree of difference between the lightest and darkest parts of the picture. Adjusting the contrast changes the amount of black and white in the image. Press the to decrease the contrast.
  • Page 16 English Image-I Brightness Contrast Color Image-I (Video mode) Brightness Adjusting the brightness of the image. Press the to darken the image. Press the to lighten the image. Contrast The contrast controls the degree of difference between the lightest and darkest parts of the picture.
  • Page 17: Horizontal Position

    Image-II (Computer mode) Frequency “Frequency” is for changing the display data frequency to match the frequency of your computer’s graphic card. When you experience a vertical flickering bar, use this function to make an adjustment. Tracking Choose “ Tracking” item to synchronize the signal timing of the display with that of the graphic card.
  • Page 18: Keystone Correction

    English Image-I Keystone 16:9 / 4:3 Image-II (Video mode) Keystone Correction Adjust image distortion caused by tilting the projector. (±16 degrees) 16 : 9 / 4 : 3 You can select this function to fit your desired aspect ratio type. Color Temperature Adjust the color temperature.
  • Page 19 Computer / Video mode Language Management Image-I Image-II Volume Stereo / Mono Treble Mute Bass Audio Volume Press the to decrease the volume. Press the to increase the volume. Treble The treble setting controls the higher frequencies of your audio source. Press the to decrease the treble.
  • Page 20: Menu Location

    English Image-I Menu Location Projection Signal Type Management Menu Location Choose the Menu location on the display screen. Projection Front-Desktop The factory default setting. Rear-Desktop When you select this function, the projector reverses the image so you can project behind a translucent screen.
  • Page 21: Appendices Troubleshooting

    Appendices Troubleshooting If you are experiencing trouble with the projector, refer to the following. If the problem persists, please contact your local dealer or our service center. Problem: No image appears on screen. Ensure all the cables and power connections are correctly and securely connected as described in the “Installation”...
  • Page 22 English 4. Follow above steps 1~2. Click on the “Advanced Properties ” button. 5. Select the “Change” button under the “Monitor” tab . 6. Click on “ Show all devices ”. Then select “ Standard monitor types ” under the “ Manufactures ” box; choose the resolution mode you need under the “...
  • Page 23 Problem : The screen is outstretched when displaying 16:9 DVD. The projector itself will automatically detect 16:9 DVD and adjust the aspect ratio by digitization to full screen with 4:3 default setting. If the projector is still outstretched, you will also need to adjust the aspect ratio by referring to the following: Please select 4:3 aspect ratio type on your DVD player if you are playing a 16:9 DVD.
  • Page 24: Changing The Lamp

    English Changing the lamp The projector will detect the lamp life itself. It will show you a warning message “ Lamp is running out of standard lifetime. Be sure to replace the lamp as soon as possible.” When you see this message, change the lamp as soon as possible.
  • Page 25: Specifications

    Specifications Light Valve - Single Chip DLP Lamp - 130W User Replaceable P-VIP Lamp Number of Pixels - 800 pixels(H) X 600 lines(V) Displayable Color - 16.7M colors Projection Lens - F2.2~2.4 f=28.51~34.21mm with 1.2 x zoom & focus Projection Screen Size - 20”~300”...
  • Page 26: Compatibility Modes

    English Compatibility Modes (ANALOG) H . F r e q u e n c y V.Frequency ( k H z ) ( H z ) * compression computer image.
