92 U-CONTROL UCA222 User Manual
Specifications
Line In
Connectors
Input impedance
Max. input level
Line Out
Connectors
Output impedance
Max. output level
Digital Output
Socket
Output format
Phones Out
Socket
Output impedance
Max. output pegel
RCA, unbalanced
approx. 27 kΩ
2 dBV
RCA, unbalanced
approx. 400 Ω
2 dBV
Toslink, optical cable
S/PDIF
1/8" TRS stereo jack
approx. 50 Ω
-2 dBu, 2 x 3.7 mW @ 100 Ω
USB 1.1
Connectors
Digital Processing
Converter
Sample rate
System Data
Frequency response
THD
Crosstalk
Signal-to-noise ratio
type A
16-bit converter
32.0 kHz, 44.1 kHz, 48.0 kHz
10 Hz to 20 kHz, ±1 dB @
44.1 kHz sample rate
10 Hz to 22 kHz, ±1 dB @
48.0 kHz sample rate
0.05% typ. @ -10 dBV, 1kHz
-77 dB @ 0 dBV, 1 kHz
A/D 89 dB typ. @ 1 kHz,
A-weighted
D/A 96 dB typ. @ 1 kHz,
A-weighted
