- Page 1 MirrorEye MP System manual No. SM0974205 A 09 Set MirrorEye MP; Art. No. 0415005 Set MirrorEye MP RHD + S; Art. No. 0415015 Set MirrorEye MP LHD + S; Art. No. 0415025 05/2019 English...
- Page 2 This can cause deformation of the enclosure or damage to MirrorEye set, Art. No. 0415005 internal components. • Repairs may only be undertaken by Stoneridge/Orlaco. • The equipment must be assembled as shown in this manual. • If there have been alterations or changes to this equipment that have not been specifically approved by Stoneridge/Orlaco, use of this equipment is not permitted.
-
Page 3: Table Of Contents
System manual Contents Page Checking Field of view 1. UNECE R46 regulation Remark 2. Introduction Before driving it’s mandatory 2.1. Surveillance camera for the operator of the vehicle 3. System descriptions to check if the legally prescribed field of 3.1. System view Set MirrorEye MP view is displayed on the monitor. -
Page 4: Introduction
System manual 2. Introduction The MirrorEye system is a camera monitoring system, designed to replace conventional class II and class IV rear-view mirrors on vehicles. The MirrorEye MP system complies with the regulations as described in R46R6. System Description 1,5m The function of the MirrorEye system is to provide the operator with the legally required class II, IV fields of view. -
Page 5: System Descriptions
System manual 3. System descriptions Set MirrorEye MP, Art. No. 0415005 System overview Camera MirrorEye MP Left side Art. No. 0106045 Camera MirrorEye MP Right side Art. No. 0106055 Monitor 12,3” Monitor 12,3” Driver side Passenger side Art. No. 0212505 Art. -
Page 6: System View Set Mirroreye Mp Rhd + S
System manual Set MirrorEye MP RHD + S , Art. No. 0415015 System overview Camera MirrorEye MP Left + S Art. No. 0106065 camera Camera MirrorEye MP Right Art. No. 0106055 Monitor 10” Art. No. 0224000 Monitor 12,3” Monitor 12,3” Driver side Passenger side Art. -
Page 7: System View Set Mirroreye Mp Lhd + S
System manual Set MirrorEye MP LHD + S , Art. No. 0415025 System overview Camera MirrorEye MP Left Art. No. 0106045 camera Camera MirrorEye MP Right + S Art. No. 0106075 Monitor 10” Art. No. 0224000 Monitor 12,3” Monitor 12,3” Driver side Passenger side Art. -
Page 8: Mirroreye Set Layout
System manual Center lens, Center lens, class IV class IV Ocular Reference Point A Pillar A Pillar Ocular Reference Point A Pillar Seat rails Center lens 3.4. MirrorEye set Layout, See Figure 5 1. Camera MirrorEye Left Side; 2. 12.3” Monitor unit, Driver Side; 3. -
Page 9: Mirroreye Installation
Stoneridge-Orlaco is not responsible for any errors in the calibra- tion of the distance lines. The distance lines must be assessed during vehicle installation approval. -
Page 10: Cabin Wire Harness Electrical Connections
System manual 4. Cabin Wire Harness electrical connections The MirrorEye MP Set must be connected by trained electricians. Under no circumstances should you make connections that are not described in this manual. Cabin Wire Harness ME 2.4m; Art. No. 0391000 3 = Power (KL30) 3 = Power (KL30) 1 = CAN 1H... -
Page 11: Dimensions
System manual 5. Dimensions 45,2 149,5 30,2 70,5 Class II 190 x 110mm Class IV 95 x 110mm Monitor 12,3” MirrorEye Camera MirrorEye MP Left side/Right side 5p Molded male Connector Units in mm 37,5 M5 (8x) 13,5 Surveillance monitor Monitor 10”... -
Page 12: Drilling Template
System manual 6. Drilling template Bracket Drilling template MirrorEye MP Left, SCALE 1:1 ∅9 Mounting holes for bolts M8 Units in mm Figure 9 SM0974205 A 09... -
Page 13: Technical Specifications
System manual 7. Technical specifications 7.1. Technical specifications Art. No. 0415005; Set MirrorEye MP Camera Units Camera MirrorEye MP Left Camera Mirror Eye MP Right Article numbers 0106045 0106055 Camera module Two image sensors for Class II/IV view, 1.4MP. Video stream Uncompressed over Coax cable (3Gbps). -
Page 14: Set Mirroreye Mp Rhd + S
System manual 7.2. Technical specifications, Art. No. 0415015; Set MirrorEye MP RHD + S Camera Units Camera MirrorEye MP Left + S Camera Mirror Eye MP Right Article numbers 0106065 0106055 Camera module Two image sensors for Class II/IV view, 1.4MP. Two image sensors for Class II/IV view, 1.4MP. -
Page 15: Set Mirroreye Mp Lhd + S
System manual 7.3. Technical specifications, Art. No. 0415025; Set MirrorEye MP LHD + S Camera Units Camera MirrorEye MP Left Camera Mirror Eye MP Right + S Article numbers 0106045 0106075 Camera module Two image sensors for Class II/IV view, 1.4MP. Two image sensors for Class II/IV view, 1.4MP. -
Page 16: Potential Faillures
System manual 8. Potential failures: Symptom Action driver 1. Black screen 1. Driver should stop the vehicle in a safe manner, as soon as possible. 2. Blue screen 2. Driver should stop the vehicle in a safe manner, as soon as possible. 3. -
Page 17: Monitor Led Status Indicator
System manual 8.1. Monitor LED status indicator The 12,3” monitor has a red LED status indicator. See Figure 10. This LED will be activated in the following situations: • MirrorEye Monitor in reset. • MirrorEye video stream failure. • MirrorEye Monitor TFT panel failure. •... -
Page 18: Menu
System manual 9.1. Menu Driver side Settings Panning menu Panning Night vision Enable automatic panning Monitor Calibrate steering sensor Distance lines Trailer wheelbase (mm) Status* Trailer lenght (mm) Exit Trailer width (mm) Default manual panning angle Night vision menu IR light intensity (%) Monitor menu Auto brightness Day brightness... -
Page 19: Status Menus
System manual 9.2. Status menus Example of system information MirrorEye camera Example of system information MirrorEye monitor Example of system information Camera modules Example of system information Vehicle Example of system information System monitor Example of system information System dump SM0974205 A 09... -
Page 20: Maintenance And Cleaning
12. General terms and conditions Stoneridge/Orlaco Products BV is not liable for damage resulting from inadequate servicing, incorrect usage or alterations made to the equipment without informing the manufacturer in writing. -
Page 21: Revision History
System manual 13. Revision History Revision A 01. First issue, May 2019. Revision A 02. Specifications + article numbers changed, January 2020. Revision A 03. New issue, February 2020. Revision A 04. LED indicator added, March 2020. Revision A 05. Text Surveillance camera added, March 2020. Revision A 06. - Page 22 Our systems give the end user a view on each blind spot and will create comfort and improved working conditions. Our active approach will support market demands and innovations and will lead to enthusiastic ambassadors in the market; our customers. For more information: www.Stoneridge.com and www.orlaco.com www.stoneridge.com www.orlaco.com...
