OPERATION MANUAL
SK90
Electric Pressure Washer
Read this manual carefully before use and keep it for future reference. Failure to do so
may result in injury, property damage and may void the warranty.
Products covered by this manual may vary in appearance, assembly, inclusions,
specifications, description or packaging.
V 3.1

Advertisement

Table of Contents
loading

Related Manuals for NORSE SK90

Summary of Contents for NORSE SK90

  • Page 1 OPERATION MANUAL SK90 Electric Pressure Washer Read this manual carefully before use and keep it for future reference. Failure to do so may result in injury, property damage and may void the warranty. Products covered by this manual may vary in appearance, assembly, inclusions, specifications, description or packaging.

  • Page 2: Table Of Contents

    English SK90 Contents Contents Quick Start Guide Drawing from a barrel Parts Guide Maintenance General Cleaning Detergent Looking After your Product Post Operation / Storage Safety Symbols Safety and Warning Information Troubleshooting Technical Data Disposal Regulations CE Certification © NØRSE...

  • Page 3: Quick Start Guide

    English SK90 Quick Start Guide The following steps describe the quickest method to get your pressure washer up and running. However, it is essential you fully read this manual to ensure you are familiar with the general safety features, precautions and functions necessary to operate the product.

  • Page 4: Drawing From A Barrel

    English SK90 When using detergent, attach the detergent bottle directly onto 1. Unwind the power cord the end of the fixed spray nozzle until it “clicks” and turn to lock in completely and plug the place. cable into a 240 volt outlet.

  • Page 5: Parts Guide

    English SK90 Parts Guide 1. Power washer unit 9. High pressure hose 2. Handle 10. Quick connector filter 3. Manual 11. Screw pack 4. Extension lance 12. Quick hose connector 5. Fixed spray nozzle 13. Rotary brush 6. Detergent bottle 14.

  • Page 6: Maintenance

    English SK90 Maintenance • A clogged or partially clogged nozzle can cause significant reduction of water pressure coming out of the nozzle and/ or cause the unit to pulsate while spraying. • Turn the unit off. • Turn off the water supply to the unit.

  • Page 7: Detergent

    English SK90 Detergent The following cleaning procedure will ensure that you achieve the most beneficial results in the shortest amount of time. Use the detergent nozzle to apply detergent. Some cleaning tasks can be completed with water alone, but for most tasks the removal of dirt becomes more effective if a detergent is used.

  • Page 8: Looking After Your Product

    English SK90 Looking After your Product 1. This pressure washer is not meant to pump hot water. Never connect to a hot water supply. 2. Never operate the unit for more than one minute without spraying water. This will cause a heat build- up that can damage the pump.

  • Page 9: Safety Symbols

    English SK90 To lock the trigger of the spray gun, make sure power is off (O), aim the spray gun away from you and push the lock button up, after doing so, squeeze or pull the trigger to make sure it is locked and will not move.
  • Page 10 English SK90 WARNING: The electrical supply connection must be made by a qualified person and comply with IEC 60364-1. The electric supply to this machine should include either a residual- current device / circuit breaker that will interrupt the supply if the current to earth exceeds 30 mA for 30 ms.

  • Page 11: Troubleshooting

    English SK90 Troubleshooting Symptom Possible Cause(s) Corrective Actions 1. Clean detergent bottle with warm water No detergent 1. Detergent bottle is clogged suction 2. Replace detergent bottle 1. Unit is pressurised 1. Clean water inlet Pressure washer 2. Plug is not connected correctly or 2.

  • Page 12: Disposal Regulations

    English SK90 Disposal Regulations Do not dispose of electrical machines as unsorted municipal waste, use separate collection facilities. Contact your local government for information regarding the collection systems available. If electrical machines are disposed of in landfills or dumps, hazardous substances can leak into the groundwater and get into the food chain, damaging your health and well-being.

  • Page 13: Ce Certification

    The undersigned: Michael S McQuaide As authorised by: Union Mart Ltd Declares that Description: Electric Pressure Washer Identification code: NØRSE SK90 Conforms to the following European Directives: (2006/42/EC)(2006/95/EC)(2004/108/EC)(2011/65/EU) And are manufactured in accordance to the following standards or standardised documents:...
