Summary of Contents for Rousseau R2Q-JA16S
Page 1
Alineado con el lado de un gabinete RD02 de 30''An &+ Centrado bajo un gabinete RD02 de 30''An &+ RD02 RD02 (30''L &+) (30''L &+) See/Ver P4 See/Ver P4 See/Ver P5 See/Ver P5 See P6 for accessories / Ver P6 para los accesorios. rousseaumetal.com Page/Página 1/6 R2Q-JA16S 1-800-463-4271 7D00202QS...
Page 2
Under a 24''W RD02 cabinet Bajo un gabinete RD02 de 24''An 1/2" Remove accessories from the unit (if required) Retirar los accesorios de la unidad (si es necesario) Do not completly tight the screws. No ajustar los pernos completamente. Side view / Vista de lado Bottom view Vista desde abajo Completly tight the 4 screws...
Page 3
Under a 24''W RD38/39 Smart cabinet Bajo un gabinete infor. RD38/39 de 24''An 1/2" Remove accessories from the unit (if required) Retirar los accesorios de la unidad (si es necesario) Do not completly tight the screws. No ajustar los pernos completamente. Side view / Vista de lado Bottom view Vista desde abajo...
Page 4
Side aligned with a 30''W &+ RD02 cabinet Alineado con el lado de un gabinete RD02 de 30''An &+ Bracket is included with Storage unit RD48 or Keyboard/laptop tray RD47. Remove accessories from the unit El adaptador viene incluido con la unidad RD48 o con el soporte para teclado RD47. (if required) Retirar los accesorios de la unidad (si es necesario)
Page 5
Side aligned with a 30''W &+ RD02 cabinet Alineado con el lado de un gabinete RD02 de 30''An &+ 1/2" Bottom view Vista desde abajo Completly tight all screws (except if you install a drawer, see p.6). Ajustar todos los pernos completamente (salvo si se instala un cajón, ver p.6).
Page 6
Keyboard/laptop RD47 assembly Montaje del soporte para teclado/laptop RD47 IMPORTANT / IMPORTANTE Install keyboard and mouse tray RD47 before assembly the accessories bellow (see assembly guide R1A included with RD47 support). Instalar el soporte para teclado/laptop RD47 antes de montar los accesorios que siguen (ver la Guía de montaje R1A que viene con el soporte).
