Summary of Contents for Numa R Series
- Page 1 Installation Manual Series R...
- Page 2 Series R COSMIC, ORBIS, BANARAS, ALAMKARA Congratulations on your purchase of India’s finest Back-Lit mirrors by NUMA. World class engineering, materials and state of the art design will enable you to enjoy your mirror for many years to come. We realize that the marketplace offers many choices and we thank you for selecting NUMA for your mirror needs.
- Page 3 NUMA will not be mounted, please take corrective professional. responsible for any damage action on-site.
- Page 4 Top Mirror Line 12mm Top Frame Line Location of Electrical Point (Mirror centre unless otherwise customized) Bottom 12mm Frame Line Bottom Mirror Line Mark mirror & frame lines. Make sure the marking is completely horizontal. The frame is smaller than the mirror by 12mm (0.5inch) on all 4 sides Ensure electrical outlet in the wall matches the outlet provided in our framing system.
- Page 5 Fix the frame onto the wall using rated anchors. Once the frame is affixed, kindly complete electrical wiring. Please note a grounding wire (green) is provided with the system. Ensure that the mirror is perfectly vertical Insert packing if necessary For longer or heavier mirrors, additional holes maybe be provided for anchoring onto the wall After electrical wiring is complete, kindly switch on to make sure the LEDs are turning...
- Page 6 Using a set of suction cups, position the mirror carefully over the mounting frame, such that the angular mating part on the mirror, rests on the top of the angular surface on the mounting frame. The mirror extends 12mm or 0.5 inch from the mounting frame on all 4 sides.
- Page 7 DeFogger Mirror De-Fogger Connector provision in the rear-frame The DeFogger/DeMister is mounted on the mirror; Before mounting the mirror, it is necessary to connect the wiring/terminals of the de-fogger with the appropriate connector on the rear-frame. CAUTION Risk of electrical shock Electrical wiring to be done by certified electrician only.
- Page 8 Magnets Please note that strong magents are provided with each frame to adhere the mirror to the rear- frame. You will find them below the brackets; kindly place them above the brackets after installation of the rear frame and before you hang the mirror. The adhesion strength of these magnets is very high and please take proper care when you are placing or removing the mirror;...
- Page 9 Sealing Frame after wiring. To avoid steam or water vapor from entering the mirror, flexible silicone sheet is provided (red color) onto the rear frame. For electrical outlet, kindly punch a hole through this silicone sheet, wherever required and after completion of wiring, apply silicone such as Anabond 666 around the wire to seal the excess space.
