Summary of Contents for vita VA68890
- Page 1 ASSEMBLY GUIDE Westwood Arbor VA68890 VER 1.9 11/10/20...
- Page 2 1-800-282-9346 hello@wearevita.com WWW.WEAREVITA.COM 8am - 5pm EST...
-
Page 3: In This Guide
IN THIS GUIDE PARTS LIST TOOLS YOU WILL NEED - PRODUCT DIMENSIONS STEP 1 AND 2 STEP 3 AND 4 STEP 5 AND 6 (TEMPORARY INSTALLATION) STEP 7 (PERMANENT INSTALLATION) -
Page 4: Parts List
PARTS LIST PREASSEMBLED ARCH - 12009 - X2 PRE-ASSEMBLED SIDE PANEL - 12008 - X2 ARCH RAFTER - 12007 - X6 METAL GROUND STAKES - 12006 - X4 BRACES - 12005 - X4 SCREW A - 20037- 1 1/2IN (3.8CM) - X12 - TO ATTACH RAFTERS TO ARCH SCREW B - 20064 - 1 1/4IN (3.18CM) - X8 - ATTACH GROUND STAKES TO POSTS SCREW C - 20068 - 2IN (5CM) - X4 - TO ATTACH THE FLAT PART OF THE BRACES TO ARBOR POSTS SCREW D - 20069 - 3IN (7.6CM) - X4 - TO ATTACH THE SWOOP PART OF THE BRACE TO ARBOR... -
Page 5: Tools You Will Need
TOOLS YOU WILL NEED PRODUCT DIMENSIONS 59in (149.8cm) (7.6cm) 85.5in 78in 81.5in (217.2cm) (198.1cm) (207cm) 59in (149.8cm) 42in (106.6cm) (7.6cm) 13.5in (34.3cm) 47in 17.5in (119.3cm) (12.7cm) (44.5cm) - Page 6 12009 - X2 12008 - X2 20070 - X8...
- Page 7 20068 - X4 20069 - X4 12005 - X4 Brace should in the center of the post. Screw in first, then 20037 - X12 12007 - X6...
- Page 8 20064 - X8 12006 - x4 Temporary Installation Carefully push arbor stakes into desired ground area...
- Page 9 Permanent Installation For a permanent installation, measure four 8in holes in diameter, 44 1/2in (113cm) apart by 15 1/2in apart (39.4cm), from center to center. Dig each hole 14in (36cm) deep. Fill excavated holes with mixed concrete 44 1/2in 15 1/2in (113cm) and carefully lift arbor (39.4cm)
