Homesafe F1 Res 44 Quick Manual

F1 Res 44 Horizontal Side Wall
Details below are taken from data supplied by the head manufacturer.
Up to 4.9 x 6.1 metres coverage from 1 head

Temperature Range

Installation Data

Thread K
Size Factor
mm
15mm 63
Minimum Spacing of 4.3 Metres
Max Spacing
3.6 x 3.6
4.3 x 4.3
4.9 x 4.9
4.9 x 5.5
5.5 x 5.5
4.9 x 6.1
3.6 x 3.6
4.3 x 4.3
4.9 x 4.9
4.9 x 5.5
4.9 x 6.1

Features

1 Residential
2 Quick Response
3 3mm Glass bulb
4 Pressure Rated 1200 kPa
5 Tested to 3445 kPa
6 Tread Size 1/2" NPT
7 Minimum Density of 2.03 LPM per square metre
Listings & Approval
1. Listed by Underwriters Laboratories, and certified by UL for Canada (cULus)
2. NYC MEA 258-93-E

Product Description

The F1 Res Horizontal Sidewall sprinklers (Figs.1 and 2) are equally attractive when above ceiling piping
cannot is used.
The 3mm glass-bulb pendent sprinklers, with a K-Factor of 63, permit the efficient use of residential
water supplies for sprinkler coverage in residential fire protection design.
The low flow F1 Res sprinklers are specially engineered for fast thermal response to meet the
sensitive fire protection application needs of the latest residential market standards
(UL 1626 Standard effective 7/12/02).
Upon fire conditions, rising heat causes a sprinkler's heat-sensitive glass-bulb to shatter, releasing the
waterway for water flow onto the deflector, evenly distributing the discharged water to control a fire.
68° C or 79° C
Maximum Maximum
Pressure Ambient
kPa Temperature
38° C
1200
66° C
Ceiling to LPM
Deflector
45.4
53
60.6
101 - 152mm
68.1
72
87.1
53
60.6
152 - 305mm 64.4
75.7
87.1
Call 07 824 8005 To Order
Escutcheon F2
Sprinkler Length
62 mm
Pressure
kPa
52
71
92
116
129
189
71
92
104
143
189
RRP
$ 40.00
Plus GST
