Users guide and maintenance
manual for the generating sets
Model(s) : G270
Control device : Intellisys
Doosan purchased Bobcat Company from Ingersoll-Rand Company in
2007. Any reference to Ingersoll-Rand Company or use of trademarks,
service marks, logos, or other proprietary identifying marks belonging
to Ingersoll-Rand Company in this manual is historical or nominative
in nature, and is not meant to suggest a current affiliation between
Ingersoll-Rand Company and Doosan Company or the products of
either.
Réf. GPAO : 33501190701NE
Réf. constructeur : 33501190701
Revised (10-12)

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the G270 and is the answer not in the manual?

Questions and answers

Related Manuals for Ingersoll-Rand G270

Summary of Contents for Ingersoll-Rand G270

  • Page 1 Control device : Intellisys Doosan purchased Bobcat Company from Ingersoll-Rand Company in 2007. Any reference to Ingersoll-Rand Company or use of trademarks, service marks, logos, or other proprietary identifying marks belonging to Ingersoll-Rand Company in this manual is historical or nominative...
  • Page 3 Users guide and maintenance manual All generating sets General considerations Safety instructions Réf. constructeur : MUE-IR A Réf. GPAO : 33522051901 - 1 -...

  • Page 4: Table Of Contents

    1. Preamble ..........................4 1.1. Introduction ........................4 1.1.1 General recommendations..................4 1.1.2. Structure of the reference material ................5 1.2. Pictograms and their meanings..................5 1.3. Safety instructions and regulations ................7 1.3.1 General advice......................7 1.3.2 Risks related to feed gas (concerns gas sets)............. 9 1.3.3 Risks related to exhaust gases and fuels..............
  • Page 5 Attached documents User manual for the control unit User and maintenance manual for the engine User and maintenance manual and spare parts catalogue for the alternator Wiring diagrams (supplied with the electrical generating set) Genset parts catalog. - 3 -...

  • Page 6: Preamble

    1. P REAMBLE 1.1. Introduction 1.1.1 General recommendations Thank you for choosing an electrical generating set from our company. This manual has been designed to help you operate and maintain your electrical generating set correctly. Read the safety instructions carefully in order to prevent any accident, incident or damage. These instructions must always be followed.

  • Page 7: Structure Of The Reference Material

    1.1.2. Structure of the reference material The reference material delivered with the generating sets enables you to get to know the equipment, operate it and maintain it, both on a daily basis and periodically. The reference material for the engines and alternators fitted to the sets consists of engine user and maintenance manuals (from the manufacturer) and alternator user and maintenance manuals (from the manufacturer).
  • Page 8 Warning, rotating or moving parts (risk of Lifting point required getting caught in the machinery) Stacking point required Warning, corrosive product Naked flames and Warning, risk of explosion unprotected lights prohibited. No smoking Exctinction by water Entry prohibited to non- prohibited authorised persons When on a trailer,...

  • Page 9: Safety Instructions And Regulations

    1.3. Safety instructions and regulations THESE SAFETY PRECAUTIONS ARE IMPORTANT If you do not understand or have any questions about any point in this manual, contact your dealer who will explain it to you or give you a demonstration. A list of risks and precautionary measures to take follows.
  • Page 10 Disconnect the battery and pneumatic starter (if there is one) before carrying out any repair, to prevent the engine from starting accidentally. Fit a panel over the controls to prevent any attempt at starting. Do not modify the engine. Only use the correct techniques for turning the crankshaft to rotate the crankshaft manually.

  • Page 11: Risks Related To Feed Gas (Concerns Gas Sets)

    1.3.2 Risks related to feed gas (concerns gas sets) WARNING – DANGER The gas is explosive. It is forbidden to smoke, go near or create sparks when the tank is being filled and near to the generating set. Request the user technical notes and LPG or NG safety data sheets from your gas supplier.

  • Page 12: Risks Related To Toxic Products

    1.3.4 Risks related to toxic products WARNING – DANGER The corrosion inhibitor contains alkali. This substance should not come into contact with the eyes. Avoid any prolonged or repeated contact with skin. It should not be swallowed. In the event of skin contact, wash thoroughly with water and soap. In the event of contact with eyes, rinse immediately with plenty of water for at least 15 minutes.

  • Page 13: Risks Related To Electrical Networks

    Good ventilation is required for your generating set to work properly. Without ventilation, the engine will quickly reach an excessive temperature that could lead to accidents or damage to the equipment and surrounding items. Do not take off the radiator cap when the engine is hot and the coolant is pressurised due to risk of burns.

  • Page 14: Dangers Presented By Electric Currents (First Aid)

    1.3.7 Dangers presented by electric currents (first aid) First aid In the event of an electric shock, cut off the voltage immediately and activate the set's emergency stop. If the voltage has not yet been cut off, move the victim out of contact with the live conductor as quickly as possible.

  • Page 15: Recommendation For The Operator And Environment

    1.3.9 Recommendation for the operator and environment Operating personnel should be aware of the safety and operating instructions. These will be regularly updated. Operating should be monitored, directly or indirectly, by someone designated by the operator who is familiar with the installation and dangers and problems regarding products stored and used in the installation.

  • Page 16: Identifying Sets

    1.4. Identifying sets generating sets and their components are identified by means of identification plates. The precise rules for identifying each major component (engine, alternator etc.) are set out in each manufacturer's documents contained in this manual. Examples of identification plates generating set Engines - 14 -...
  • Page 17 Alternator - 15 -...

  • Page 18: Installation

    2. I NSTALLATION 2.1. Unloading 2.1.1 Safety during unloading In order to unload generating sets from their transport mountings, under optimum conditions of safety and efficiency, you should check that the following points are being followed correctly. - Suitable lifting vehicles or equipment for the work. - Slings positioned in the rings provided for this procedure or lifting arms resting fully underneath the frame cross beams.

  • Page 19: Fork Lift Truck

    2.1.3.2 Fork lift truck - position the arms of the fork lift under the frame, making sure that only the cross beams are resting on the arms. - lift and handle the equipment carefully. - set down the generating set in its unloading position. It is recommended to use a fork lift truck with arms that are longer than the width of the frame - 17 -...

  • Page 20: Installation Of Mobile Site Sets

    3. I NSTALLATION OF MOBILE SITE SETS 3.1 Specific arrangements An area will be reserved to install the generating set. Its should be flat and strong enough so that the generator does not sink into it. It could be made of concrete or even large planks fitted together.

  • Page 21: Road Trailer

    4. R OAD TRAILER 4.1 Trailer linkage Before attaching the trailer, check the trailer hook on the tow vehicle; it should fit the trailer ring perfectly. WARNING – DANGER Trying to tow a trailer with a non-matching device (bar, wires, cords, etc.) could lead to serious accidents.

  • Page 22: Check Before Towing

    4.2 Check before towing Before towing carry out the following checks: - wheel torquing - lock trailer hook - tyre pressure - light signals working - cover doors closed - parking brake off - front wheels and rear supports lifted. - tightening and fixing the draw bar arms locking levers - brake test for "road"...

  • Page 23: Implementation For Installation

    4.5 Implementation for installation Procedures to be carried out: - check that the ground is strong enough for the assembly not to sink into it - using the front wheel, position the set as horizontally as possible - engage the handbrake. - lower the rear trailer supports and lock them - 21 -...

  • Page 24: Battery Maintenance

    5. B ATTERY MAINTENANCE WARNING – DANGER install the battery so that it has the correct ventilation never place the battery close to a flame or fire use only insulated tools never use sulphuric acid or acid water to top up the electrolyte level. PROCEDURE FOR TESTING STARTER BATTERIES TEST TYPE PROCEDURE...

  • Page 25: Fuel And Consumables

    6. F UEL AND CONSUMABLES All specifications (product features) are given in the engine and alternator maintenance manuals attached to this manual. 6.1 Circuit capacities – Mitsubishi engines Engines S4L2-SD S4Q2 (series SL) (series SQ) (series SS) CIRCUIT AND TANK CAPACITY MODEL G 16...

  • Page 26: Circuit Capacities - John Deere Engines

    6.2 Circuit capacities – john Deere engines Engines CIRCUIT AND TANK CAPACITY G 66 MODEL G 44 G 77 G 110 G 130 G 160 G 200 LUBRICATION (in litres) 13.5 13.5 21.5 21.5 31.5 COOLING 16.1 23.6 20.2 27.3 25.8 25.8 (in litres)

  • Page 27: Circuit Capacities - Volvo Engines

    6.3 Circuit capacities – Volvo engines ENGINES TWD 740 TAD 740 TAD 1032 TAD 1242 TAD 1631 CIRCUIT AND TANK CAPACITY MODEL G 220 G 270 G 330 G 440 G 550 LUBRICATION (in litres) COOLING (in litres) 41.9 36.9 37.3 FUEL (in litres)
  • Page 31 User’s manual Ingersoll Rand Control unit Intellisys Level 1 1.06F Réf. constructeur Réf. GPAO : 33502013801...

  • Page 32: Safety S S Ymbols

    SAFETY S S YMBOLS Caution : danger Caution, refer to the publications supplied with the Genset Protective clothing required. Caution : risk of electric shock Eye and hearings protection necessary Caution : toxic substances Periodic maintenance required Caution : pressuried fluids Check battery charge Caution : high temperature (risk of burning) Recommended Lifting point...

  • Page 33: Presentation

    PRESENTATION ENGLISH Control u u nit Generating set programmable control- Panel l l ight i i ndicator Lighting for wall mounted or free stan- ding panel Emergency S S top The genset shuts down immediately and the control unit goes into STOP mode MICS A A MPG Device for electrical value display...
  • Page 34 F F O O R R E E W W O O R R D D Control u u nit u u pgrade: The software compatibility is ensured with the old interface boards, meaning it is possible to reprogram, on site, an interface board having a software index 1.01B with a software having an index 1.04D and 1.05E.
  • Page 35 CONTENTS Safety s s ymbols ................................... . Presentation .

  • Page 36: Presentation A A Nd T T Echnicals C C Haracteristics

    PRESENTATION A A ND T T ECHNICALS C C HARACTERISTICS 1. Oil pressure fault/shutdown (red LED on). 2. Water Tº fault/shutdown (red LED on). 3. Overcranking fault/shutdown (red LED on). 4. Overspeed fault/shutdown (red LED on). 5. Genset on load or ready to take the load (green LED on). 6.
  • Page 37 1 - F F eatures ! Display module (DM) ! Interface board available in 2 versions (CB, CB12) depending on customer optional equipment. ! Option 3 module, option 4 module and option 5 module (OPT 3 3 45) ! Block building system enabling multiple combinations. Note: DM required in all combinations 2 - D D isplay m m odule (Fig.
  • Page 38 5 - O O ption 3 3 , 4 4 a a nd 5 5 m m odules ( ( OPT345) ! Modular case, dimensions : 160x90x58 ! Programming specific to each module (dip-switch) ! 8 allocated inputs and 10 programmable outputs on option 3 for remote volt free contacts ! 8 programmable inputs and 10 programmable outputs on option 4 , with 24 preprogrammed options ! Specific programming of some entries 6 - A A lternator c c urrent i i nput...
  • Page 39 16 - O O ptions c c onnected t t o t t he i i nterface Option description CB12 external start-up command auto predisposition + external command 3ph+neutral or 1ph+N mains connection battery charger (3 possible ratings) water heater (3 poss. depending on supply V) hooter RS485 for monitoring or remote management...

  • Page 40: Precautions

    1 1 . . F F O O R R E E W W O O R R D D 1.1. P P recautions " The control unit is connected to various AC voltage sources (alternator, mains, ...). While the generating set is idle, any work inside the control equipment is strictly forbidden as some parts of the electric and elec- tronic equipment stay live (mains voltage available).
  • Page 41 1.5. C C ontrol u u nit f f irst p p ower-u u p If the battery is connected and the electrolyte level correct, control unit powers up automatically and the initialisation screen below appears. ! This screen is visible for eight seconds. All LEDs are lit and will go out after 3 seconds except the Power button LED.
  • Page 42 If neither Enter nor Exit is pressed, the " overview " screen appears after three minutes. There, the time and date will be those of the pre- vious screen (before going automatically to the " overview " screen). Note : Not until the appearance of the " overview " screen will it be possible to start the generating set, however all engine protection shut- downs stay active (example: appearance of a fault).
  • Page 43 ! In this operating mode, any event appearance (alarm, fault, external command, ...) is signalled on screen. However, the generating set is stopped and automatic start-up is not possible. ! When the generating set is running and whatever the current mode (Auto, T T est, M M anu), press the Stop Ph./ph.

  • Page 44: Test Mode

    Example of " overview " screen in Test mode Fuel Level(%) 5 5 0 0 There are two minutes and thirty seconds of operation left before the generating set stops and the control unit goes into Auto mode. E.Speed(RPM) 2 2 4 4 Batt.

  • Page 45: Voltages

    4 4 . . V V I I E E W W I I N N G G T T H H E E E E L L E E C C T T R R I I C C A A L L V V A A L L U U E E S S 4.1.

  • Page 46: Currents

    4.2. C C urrents To view the various AC currents, press the A button successively. The values are expressed in true root mean square Amps. Depending on the client's needs (type of electrical installation), several screens are possible: ! 3 phase with neutral (3ph+N) ! 3 phase without neutral (3ph) ! 2 phase (2ph+N) ! 1 phase (1ph+N)
  • Page 47 5 5 . . V V I I E E W W I I N N G G T T H H E E E E N N G G I I N N E E P P A A R R A A M M E E T T E E R R S S To view the engine parameters, press the Engine button successively.
  • Page 48 All these LEDs are identified by an ISO symbol. The last two LEDs are flashing lights. The " general fault " LED flashes on appearance of any fault and the " general alarm " LED flashes on appearance of any alarm. "...
  • Page 49 ! If a fault appears on screen 3, the message on the second line disappears from the screen, the message on the first line slides down to the second line and the fault message takes the first line. ! If a third fault appears on screen 4, the message on the second line disappears from the screen, the message on the first line slides down to the second line and the third fault message takes the first line.
  • Page 50 - ATS toggle delay: Mains*Stand-by and Stand-by*Mains, and closure confirmation of the Mains and Stand-by contactors- Motorised C/B opening and closure - Engine cooling down time in Auto mode - Operating time in Test mode - Delayed shutdown on water temperature fault or overload/short-circuit fault - Appearance of commands ;...

  • Page 51: Introduction

    APPENDIX - SOFTWARE VERSION 1.05E OR LATER: "INTERNATIONAL" LANGUAGE 1 - I I ntroduction Software version 1.05E or later used with interface boards CB and CB12 enable you to use the Intellisys in a language which is different from the four standard languages already implemented.
  • Page 52 The Ampere is the unit if measurement of the currents output by the alternator (screen display: Amps). (Amps) ! Press the Hz key to display the generating set frequency and running hours and minutes. (Symbol 1) (Hz) Hz is the abbreviation for Hertz. Symbols 1 and 2 are represented in the table below. 50.2 (Symbol 2) (Symbol 2)

  • Page 53: Other Symbols

    All the symbols related to the engine parameters are represented in the table below. Symbol number Pictogram Description Symbol 3 Fuel level in daily tank (fuel pump) Symbol 4 Engine speed (galvanometer) Symbol 5 Battery voltage (generating set battery) Symbol 6 Engine oil pressure (oil can) Symbol 7...
  • Page 54 ! Spark plug preheating (symbol 11) If the generating set is ready to be started on an external command and if the "spark plug preheating" parameter is set to 1 (Factory menu), a symbol representing a solenoid appears on the screen during the spark plug preheating period prior to the first startup and also between two startup attempts.
  • Page 55 The alarms and faults are displayed in the same way as for versions 0.01B and 1.04D: Up to two codes (max.) displayed on screen Fault takes priority over alarm Faults are reset in order of appearance For more details, refer to paragraph 8. All the alarms and faults which can appear on the Intellisys screen are listed in the table below.a.
  • Page 56 Wording Alarm Fault Generated on MTU engine general alarm 52-0 impossible module 5 QST30 engine overspeed impossible 53-1 module 5 QST30 engine general fault impossible 54-1 module 5 QST30 engine general alarm 55-0 impossible module 5 Engine oil high level 56-0 impossible module 4...
  • Page 59 Use and maintenance manual Volvo Generating set and industrial engines 4 - 6 litre (non-EDC) TAD 740 GE / 1032 GE / 1630 GE / 1631 GE - TWD 740 GE / 1210 GE / 1232 GE / 1630 GE Réf.
  • Page 60 Preface Volvo Penta industrial engines are used all over the world, in both mobile and stationary applications, in all conceivable service conditions. This is not a coincidence. After 90 years of manufacturing engines, the name Volvo Penta has come to symbolise reliability, technical innovation, first class perform- ance and long life.
  • Page 61 Contents Safety Information ..........2–5 Maintenance schedule ........21–22 Safety Information ..........2 Maintenance schedule ........21 Introduction ............6–7 Maintenance ............ 23–45 Responsibility for the environment ....... 6 Engine, general ..........23 Running-in ............6 Lubrication system ..........26 Fuel and oil types ..........

  • Page 62: Safety Information

    Safety Information Read this chapter carefully. It concerns your safety. This chapter describes how safety information is presented in the Instruction Manual and on the engine itself. It also gives a general account of basic safety precautions to be taken when maintaining the engine. Check that you have the correct Instruction Manual before you read on.
  • Page 63 Safety Information Safety precautions for operation and maintenance Daily checklist Starting lock Make a habit of checking the engine and engine com- If the instrument panel does not have an ignition partment visually before operating (before the engine switch, the engine compartment must be lockable to is started) and after operating (after the engine has prevent unauthorised persons from starting the en- been stopped).
  • Page 64 Safety Information Safety precautions for operation and maintenance (cont.) Lifting the engine Batteries When lifting the engine, use the lifting eyes installed The batteries contain and give off oxyhydrogen gas, on the engine. Always check that lifting equipment is especially during charging. This gas is easily ignited in good condition and is strong enough for the lift (en- and highly flammable.
