- Page 1 MAESTRO Series Wi-Fi Kit B1018 INSTALLATION INSTRUCTIONS, USER/SERVICE MANUAL...
- Page 3 MAESTRO WiFi B1018...
- Page 5 MAESTRO WiFi B1018...
- Page 7 DRAWINGS The drawings are provided at the beginning of the manual 1 - INDEX 1 - INDEX ....................1 2 - OVERVIEW ..................1 3 - SYMBOLS ..................2 3.1 - Symbols used ..............2 4 - GENERAL WARNINGS ..............3 5 - INSTALLATION OF THE Wi-Fi CARD .......... 6 5.1 - Part identification ..............6 5.2 - Position of the connection cable ........7 5.3 - Choosing the interface installation position ....7...
-
Page 8: Symbols Used
If the manual is either damaged or lost, please request another copy from OLIMPIA SPLENDID USA Technical Support at 800-408-5196 or download directly from www.olimpiasplendidusa.com . -
Page 9: General Warnings
Raised hand Indicate actions that should never be performed. DANGER Indicates that the operation described can cause physical harm to the user unless performed in compliance with factory approved safety regulations. 4 - GENERAL WARNINGS The factory warranty does not cover issues related to: • Improper installation • Extraordinary weather conditions or acts of God • Tampering by unauthorized personnel This unit is specifically designed for use as comfort cooling in applications that meet the unit’s specifications. Any other use is considered improper and possibly dangerous. - Page 10 Components removed from the unit must be kept away from children to ensure their safety. The installation must be performed by qualified personnel. Important: Follow all instructions in this manual. OLIMPIA SPLENDID USA WILL NOT BE HELD LIABLE FOR ANY DAMAGE TO PERSONS OR PROPERTY RESULTING FROM THE FAILURE TO COMPLY WITH FACTORY RECOMMENDED INSTRUCTIONS CONTAINED IN THIS MANUAL.
- Page 11 • The Maestro Wi-Fi kit must be installed in a unit located near enough to the wireless router to ensure a strong signal. The Maestro app may disconnect if the Wi-Fi signal is too weak. • In order to use the Wi-Fi card, the user’s smartphone must be able to communicate via Bluetooth, Wi-Fi or data network connection based on its location in relation to the unit. • The quality of the connection to a wireless network may be affected by the presence of electromagnetic interference.
- Page 12 5 - INSTALLATION THE WI-FI CARD 5.1 - Part identification (Figure A) A. Circuit board B. Enable contact (if not used, leave the connector with the wire bridge, as supplied) C. Function LEDs D. Connector CN1 E. Connector CN5 F. Wi-Fi module G. Bluetooth module H.
- Page 13 5.2 - Position of the connection cable Connect the communication cable provided in the kit to the appropriate connector on the card (A) depending to the model of your unit. • Maestro Pro connect the cable to connector CN5 (E). • Maestro Smart connect the cable to connector CN1 (D). 5.3 - Choosing the interface installation location “MAESTRO SMART” MODEL The compartment for the B1018 board is located at the rear of the unit in the upper left, follow the instructions below to access it: a.
-
Page 14: Dry Contact
“MAESTRO PRO” MODEL The compartment to install the B1018 card is located behind the front of the unit in the upper right, follow the instructions below to access it: a. Disconnect the power supply to the unit. b. Open the supply air grill (11) and remove the two screws (10). (Fig c. -
Page 15: App Download And Installation
7 - APP DOWNLOAD AND INSTALLATION The OLIMPIA SPLENDID MAESTRO APP can be downloaded for free from the Google Play Store and iPhone App Store. • Go to the Play Store or App Store to download the operating systems supported by Android and IOS. • The OLIMPIA SPLENDID MAESTRO APP may be subject to change without notice, to improve its functionality and performance. -
Page 16: Technical Data
8 - FAULT CODE DIAGNOSTICS Blue LED LED 1 LED 2 LED 3 LED 4 Description on the WiFi (green) (red) (yellow) (yellow) module Communication Flashing issues between the Wi-Fi card and unit Wi-Fi network configuration OK, Flashing Flashing but there is NO internet connection Wi-Fi network NOT Flashing... - Page 17 OlimpiA Splendid USA, inc. 66 White Street - 5th floor New York, NY, 10013, USA https://www.olimpiasplendidusa.com/ customerservice@olimpiasplendidusa.com...
