Summary of Contents for Anchor APEX 80
- Page 1 alloy chain slings and fittings...
- Page 2 Chain slings SANS7593, SANS50818-6 and EN818-4 Working load limits using Grade 80 short link chain 1 Leg 2 Leg 3 and 4 Leg chain angle between the legs angle between the legs endless endless Ø 0° choke basket reeving 60° 90°...
- Page 3 Typical chain sling configurations nip angle angle not more than 90° one leg choke hitch endless basket endless reeving two leg choke hitch three leg four leg choke hitch...
- Page 4 Sling hook c/w safety latch - eye type EN1677-2 product dimensions weight code chain size [mm] [mm] [mm] [mm] [mm] [mm] [mm] [kg] SSE7-8 7 / 8 25.0 95.0 26.0 32.5 13.0 18.0 SSE10-8 37.0 114.0 37.0 33.0 17.0 22.0 SSE13-8 43.0 148.0...
- Page 5 Sling hook c/w safety latch - clevis type EN1677-2 product dimensions weight code chain size [mm] [mm] [mm] [mm] [mm] [kg] SCC7-8 7 / 8 84.0 34.0 21.0 18.0 SSC10-8 103.0 34.0 27.0 22.0 SSC13-8 124.0 50.0 42.0 29.0 SSC16-8 143.0 60.0 46.0...
-
Page 6: Connecting Link
Foundry hook - eye type EN1677-2 product dimensions weight code chain size [mm] [mm] [mm] [mm] [mm] [mm] [mm] [kg] FDE7-8 7 / 8 18.0 119.0 33.0 61.0 12.0 25.0 FDE10-8 21.0 144.0 38.0 74.0 14.0 33.5 FDE13-8 27.0 170.0 48.0 84.0 19.0... - Page 7 Short link chain Grade T(8) EN818-2 product size links dimensions break weight Ø code load Ø [mm] [mm] [mm] [mm] [kg/mtr] APX7-8 7 / 8 47.0 21.0 25.9 6.28 1.08 APX10-8 33.3 10.0 30.0 37.0 12.80 2.22 APX13-8 25.6 13.0 39.0 48.1 21.60...
- Page 8 Fram Oblong master link for 1 & 2 leg slings EN1677-4 product working dimensions weight code load limit [mm] [mm] [mm] [kg] ML22.B.6 170.0 90.0 22.0 ML25.B.6 10.7 190.0 103.0 25.0 ML28.B.6 12.9 209.0 113.5 28.0 ML32.B.6 17.1 270.0 140.0 32.0 ML38.B.6 28.1...
- Page 9 Sling hook c/w safety latch - eye type EN1677-2 product dimensions weight code chain size [mm] [mm] [mm] [mm] [mm] [mm] [mm] [kg] SSE8-10 25.0 98.0 30.0 37.0 11.0 18.0 SSE10-10 34.0 120.0 35.0 39.0 16.0 26.0 SSE13-10 42.0 153.0 50.0 52.0 19.0...
- Page 10 Short link chain Grade V(10) EN818-2 product size links dimensions break weight Ø code load Ø [mm] [mm] [mm] [mm] [kg/mtr] APX8-10 41.6 24.0 28.8 10.0 1.50 APX10-10 33.3 10.0 30.0 36.0 16.0 2.22 APX13-10 25.6 13.0 39.0 46.8 26.8 3.73 APX16-10 20.8...
-
Page 11: Product Information
Product information Product Benefits Independently tested Markings on all fittings size grade manufacturer’s mark batch number grade mark on load pins Markings on chain grade uniform load manufacturer’s mark batch number ... - Page 12 Safe use and maintenance Limitations on the use of the sling due to f. Never tie knots in the chain. Always make sure the chain isn’t twisted before putting it under tension. environmental conditions or hazardous applications g. Never load a hook on its tip or wedge a hook into a lifting point.
