Summary of Contents for De Heus BOXER AGRI PI 135
- Page 1 ROTARY HARROW PI 135 ● PI 175 ● PI 200 USER MANUAL P. de Heus en Zonen Greup B.V. Stougjesdijk 153 3271 KB Mijnsheerenland The Netherlands Tel: +31 (0) 18 66 12 333 E-mail: info@boxeragri.nl...
- Page 2 ENG | ENGLISH TRANSLATION OF THE ORIGINAL MANUAL ROTARY HARROW | User manual February 2021...
-
Page 3: Table Of Contents
CONTENTS USING THE ROTARY HARROW ....................4 SAFETY INSTRUCTIONS ....................... 5 PUTTING INTO OPERATION/OPERATING INSTRUCTIONS ............6 WORKING METHOD/USE ......................7 STORAGE/MOVING ........................8 MAINTENANCE/REPAIRS ......................9 DISPOSAL AND THE ENVIRONMENT ..................10 TECHNICAL FILE ........................11 FIGURES ........................... 12 ROTARY HARROW | User manual February 2021... -
Page 4: Using The Rotary Harrow
USING THE ROTARY HARROW For tractors Types: Boxer PI135, PI175 and PI200 The Boxer rotary harrow must be connected to the tractor or a comparable piece of equipment (hereinafter called the machine) using a three-point mounting frame. The working width is determined by the rotary harrow type. The rotary harrow can be used on sand and clay to turn and level without waste residue or stones. -
Page 5: Safety Instructions
SAFETY INSTRUCTIONS The following safety instructions and the ones given in the BOXER manual must be observed: • The capacity and stability of the machine to which the rotary harrow will be connected must be adjusted to the rotary harrow on the basis of 540 rpm (PTO). •... -
Page 6: Putting Into Operation/Operating Instructions
PUTTING INTO OPERATION/OPERATING INSTRUCTIONS Before connecting the rotary harrow to the machine mechanically, the following must be checked: • Whether the machine has sufficient capacity in all situations that may arise such as swerving or turning to be safely fitted with the rotary harrow. •... -
Page 7: Working Method/Use
WORKING METHOD/USE Prior to use, the safety instructions given in 2 must be observed. • Take care that the shaft with universal joint is as level as possible when in the working position. • Check the safeguards of the top link pins and lifting rod pins. •... -
Page 8: Storage/Moving
STORAGE/MOVING When storing the rotary harrow, make sure that the tines are free of any obstacle and are positioned straight on the surface. Do not stand on the machine when moving it. Page 8/12 ROTARY HARROW | User manual February 2021... -
Page 9: Maintenance/Repairs
MAINTENANCE/REPAIRS • Maintenance and repairs must be done by a competent person. • When replacing the tines, make sure that the same tine lengths are installed. • After every working day, the rotary harrow must be cleaned carefully so that no soil residue remains stuck anywhere on the system and hardens. -
Page 10: Disposal And The Environment
DISPOSAL AND THE ENVIRONMENT If the rotary harrow is no longer suitable for further use, the oil must be drained. Each of the sorted materials must be offered separately to the relevant authorities/companies. Page 10/12 ROTARY HARROW | User manual February 2021... -
Page 11: Technical File
TECHNICAL FILE The technical file, detailed drawings, structural calculations and original CE declaration of conformity are available for inspection at the office of the manufacturer/supplier. Page 11/12 ROTARY HARROW | User manual February 2021... -
Page 12: Figures
FIGURES A - Third fastening point B - Sideway openings C - Leveling roller D - Side guard E - Rotor with blade Page 12/12 ROTARY HARROW | User manual February 2021...
