HomePro
RF Home Automation
FEATURES
• Allows computer and appropriate software to control
Z-Wave RF devices through an RS232 port.
• Complete with RS232 connector cable and 9V power adaptor.
PRODUCT DESCRIPTION
The ZCS201 RS232 Interface allows you to communicate
from any RS232 port to control Z-Wave enabled products.
ACT does not provide any computer software for this product.
This product is intended to be used with third party software
developed using the Z-Wave dll which is available in the
Z-Wave™ Developers Kit.
NOTE: A third party software provider may elect to update the
firmware with future versions of the Z-Wave API library, or request
that ACT update the firmware (added charge). If the version of the
Z-Wave API Library or Z-Wave developers Kit used is needed, see
ACT's web site for current ZCS201 product information, or call your
sales representative.
HomePro wireless radio frequency products utilize Z-Wave™
technology to communicate and inter-operate, and are compatible with
other Z-Wave™ enabled products.
ZCS201 has non skid feet for placement on horizontal surfaces.
Includes External Power Supply.
ORDERING INFORMATION
Specify:
ZCS201 - RS232 to Z-Wave Interface, with 230V Power Supply
SPECIFICATIONS
Electrical
Power
Signal (Frequency)
Range
Mechanical
Dimensions
Weight
User Interface
Environmental
Operating Temperature Range
Specifications may change without notice to improve product performance.
HomePro
by ADVANCED CONTROL TECHNOLOGIES, INC.
External Power Supply included - 230 VAC to 9 VDC Power Supply
(200mA) with 2.1mm power plug, center (+) positive.
868.42 MHz
Up to 30 meters (line of sight) between the ZCS201 Interface and
the closest Z-Wave enabled product.
13.98cm W x 10.17cm D x 3.49cm H (5.505" W x 4.005" D x 1.375" H)
Approx. 227 grams ( 8 oz.)
Computer and appropriate software
0-40
C (32-105
F) For Indoor Use Only
O
O
0745-01
1
ZCS201
RS232 to Z-Wave Interface
Power Supply Included
RS232 Equipped with
DB-9 Connector)
ZCS201 Specifications
P/D 111208
Advertisement
Table of Contents
Summary of Contents for HomePro ZCS201
- Page 1 (200mA) with 2.1mm power plug, center (+) positive. Signal (Frequency) 868.42 MHz Range Up to 30 meters (line of sight) between the ZCS201 Interface and the closest Z-Wave enabled product. Mechanical Dimensions 13.98cm W x 10.17cm D x 3.49cm H (5.505" W x 4.005" D x 1.375" H) Weight Approx.
- Page 2 INSTALLATION INSTRUCTIONS: Connect the ZCS201 to an RS232 port on the computer. Connect the provided power supply to the ZCS201 (required for proper operation). Make sure the antenna is straightened to a vertical position for best possible results. Insert the third party software CD into the computer and follow the instructions on the screen.
