Summary of Contents for J.E. Adams 8670-5WB

  • Page 2: Table Of Contents

    Typical Timer Settings………………………. . 15 • Programming the Remote Start System…………………16 • Maintenance……………………………………………... 17 • Parts Breakdown………………………………………... 18-20 o 8670-5WB…………………….……………… 18 o 8778A-1………………………..……………... 19 o 22002-51A……………………………………. 20 • Schematics……………………………………………….. 21 o S8670-5WB………………………...…………. 21 • Troubleshooting…………………………………………. 22 8670-5WB Manual – 10/2006...

  • Page 3: Product Information

    Key number can be found on the tag that comes attached to the keys. There may be more than one key number depending on unit. Please keep this information with your records. MODEL#:_________________________________________ SERIAL#:_________________________________________ KEY NUMBER(S):_________________________________ DATE PURCHASED:_______________________________ DISTRIBUTOR:___________________________________ J.E. Adams Industries 1025 63 Ave. S.W. Cedar Rapids, IA 52404 1-800-553-8861 www.jeadams.com 8670-5WB Manual – 10/2006...

  • Page 4: Specifications

    2.1 @ 125 (MAX PSI) TEMPERATURE RANGE: -10 DEGREES F TO 100 DEGREES F. MOTOR: • 1.5 HP, 1725 RPM • CAPACITOR START • NEMA 56 FRAME • AUTOMATIC THERMAL OVERLOAD. NO LUBRICATION REQUIRED ON MOTOR OR COMPRESSOR. 8670-5WB Manual – 10/2006...

  • Page 5: Requirements

    GASOLINE DISPENSING PUMP. ELECTRICAL SERVICE: • Dedicated service required o 120V single phase o 20 amp service o 60Hz cycle • Minimum service wire size: o Less than 100ft run: 12Ga o 100ft – 200ft run: 10Ga 8670-5WB Manual – 10/2006...

  • Page 6: Installation

    ELECTRICIAN to ensure all local and national electrical codes are adhered to. 1. This unit is designed to be used with the J.E. Adams 6025 hose reel base. 2. Using the 6025 footprint dimensions shown in Figure 1, locate and install mounting studs.
  • Page 7 Figure 1: Installation footprint for 6025 hose reel base 8670-5WB Manual – 10/2006...
  • Page 8 Figure 2: Mounting and routing detail 8670-5WB Manual – 10/2006...
  • Page 9 Figure 3: Electrical installation detail 8670-5WB Manual – 10/2006...
  • Page 10 Figure 4: Cabinet and hose reel base dimensions 8670-5WB Manual – 10/2006...

  • Page 11: Timer Setup

    Coins to start is the amount of coins needed to activate the timer and can be set from one to seven coins in increments of one coin. Refer to Table 1 (page 14) for switch settings. 8670-5WB Manual – 10/2006...

  • Page 12: Idx Setup

    Coins to start is the amount of coins needed to activate the timer and can for a total run time of 3 minutes. be set from one to seven coins in increments of one coin. Refer to Table 1 (page 14) for switch settings. 8670-5WB Manual – 10/2006...

  • Page 13: Infitec Setup

    15 coins in increments of one coin. Refer to Table 1 (page 14) for switch settings. Figure 7: Infitec timer setup Figure 7 shows an Infitec timer set for 2 coins to start and a total run time of 240 seconds (4 minutes). 8670-5WB Manual – 10/2006...

  • Page 14: Timer Settings Chart

    IDX Timers: Time Per Coin (In Seconds) Infitec Timers: Total Run Time (In Seconds) Time Per Coin (In minutes) 0.1 x Coins to Start Table 1: Timer Settings Chart Note: “X” indicates a switch in the “on” position 8670-5WB Manual – 10/2006...
  • Page 15 5-1/2 MIN $1.00 5-1/2 MIN 2, 8, 64, 256 Table 2: Typical Timer Settings Note: “*” denotes a configuration that is not possible with this timer. See Table 2 for the closest approximation to this time. 8670-5WB Manual – 10/2006...

  • Page 16: Programming The Remote Start System

    If the LED indicator begins to blink rapidly (about 4 times per second) you must repeat steps 3-5. 6. Test the system to verify proper operation. 7. Replace cover, making sure antenna is hanging straight down outside the cover. 8670-5WB Manual – 10/2006...

  • Page 17: Maintenance

    • Mild soap and water may be used to clean the decals. DO NOT use any harsh or abrasive cleaners or the decal surface may be damaged. 8670-5WB Manual – 10/2006...

  • Page 18: Parts Breakdown

    8670-5WB Manual – 10/2006...
  • Page 19 8670-5WB Manual – 10/2006...
  • Page 20 8670-5WB Manual – 10/2006...

  • Page 22: Troubleshooting

    Isolate timers from coin mech and remote start. If timer continues to run after the continuously and will !CAUTION! maximum possible timer setting, replace timer. If unit times out and turns off, coin not shut off Damaged timer/Coin mech mech or remote start may need to be replaced. 8670-5WB Manual – 10/2006...
