- Page 1 O&M Manual Revision 4.4 PF8000 Type PF8000 TypeB utomatic Rising kerb Maximum Span: 5 Metres Duty Cycle: 100% Instructions For: PF8000...
-
Page 2: Introduction And Warnings
PF8000 Introduction and Warnings This equipment is part of a large range of traffic flow products. They are designed to be easy to install, as all settings and internal wiring has been completed in our factory. Any of the instructions in this manual should only be carried out by a qualified service engineer or a competent person. - Page 3 This article describes how your equipment will be delivered to you, specifications on the transportation used and advice including health & safety on movement of the equipment. The kerb should ALWAYS! be in the lowered position before any movement commences, this ensures that the kerb does not distort or get damaged.
- Page 4 PF8000 Blocker Overview PARKING FACILITIES POWERUNIT 0.75KW 8L VERT TANK (TYPE B) Comprising of: UP100 K3P0-01 FOR MANIFOLDS 1013 AND ALL CETOP INTERFACES. NEW UP100 HOUSING SEALKIT FITS K1,K2,K3 AND K4 HOUSINGS. FIXING KIT UP100 FOR METAL TK NEW UP100 RETURN FILTER 150MIC FILTERS OIL INTERNALLY.
- Page 5 PF8000 Guide to Physical Installation Installation may be broken down into the following stages: · Excavation of Blocker pit. · Installation of 100mm conduit for hoses and signal cable. · Construction of sump pit ( if required ) · Installation of drainage pipes.
- Page 6 PF8000 Physical Installation Cont... 2. See reference drawings for visual guide to previous page Earth wall Concrete Pad laid after dig (for blocker to sit on) Drain Ground Excavated Blocker Lowered into hole Backfill concrete around (Base Poured) eye bolts used to level blocker...
- Page 7 PF8000 Manual Release Guide Please use the following instructions to operate the kerb manually, the following is assuming you have powered down the unit and opened the HPU cabinet door: As Pictured above use the “Emergency lower valve” to release the blocker. Please ensure you have...
-
Page 8: Technical Data
PF8000 Technical Data The PF Rising Kerb Kerb is essentially a hinged Kerb rising above the road surface to prevent unauthorised access. We manufacture all sizes from 2m up to 5m but can double up to span roads up to 12m wide. We also offer a single kerb with the attack face on both sides if required. - Page 9 Wiring Diagram (Illustration) PF8000 STOP LOWER RAISE LOWER PROX RAISE PROX SPARE GREEN EARTH...
-
Page 10: Programmable Logic Controller
PF8000 Wiring/Programming Description Programmable logic controller The above diagram shows how to navigate through the menu system on the PLC. This should only be done by qualified or competent personnel. Built in options on PLC Time clock 7 Day, 24 hr time clock can be used to hold open the rising kerb at any time of the day or night. - Page 11 PF8000 Wiring/Programming Description PLC Guid de and Inf formation Memo ory Card f for PLC only to be e used if upgrade Software e required refer t to manufa acturer fo or details. Overv view Image e Of PLC (Programm...
-
Page 12: Loop Detector Settings
PF8000 Loop Detector Settings... - Page 13 PF8000 Loop Detector Settings...
- Page 14 PF8000 Loop Detector Settings...
- Page 15 PF8000 Troubleshooting Guide (electrical) Troubleshooting Guide (Mechanical) Error Cause Correction Kerb keeps going up Check and reset limit Limit switch fault and down switches Check turn buckle Oil or grease turn buckle Kerb creaking Loss of voltage Check motor supply;...
- Page 16 PF8000 Troubleshooting Guide (electrical) Error Cause Correction Door switch stop circuit Press door switch in and not making check PLC screen Check proximity Blank Screen on PLC Both open and close distances, check if both proximity switch lights are lit on proximity detecting switches.
- Page 17 PF8000 Hydraulic Oil Spec...
- Page 18 PF8000 Hydraulic Hose Specifacation...
-
Page 19: Installation/Commissioning Check List
PF8000 Installation/Commissioning Check List System Operation - The user FULLY understands How to operate the system with all control devices How to isolate the power to the automation system How to manually release the system in event of power failure... -
Page 20: Service Log
PF8000 Service Log This Manual must be completed in accordance with the guidelines below, at any point service/repair work is carried out on the product. This is to achieve two things; 1. To keep a history of the product for yourself and your supplier/manufacturer. -
Page 21: Commissioning Certificate
PF8000 Commissioning Certificate We certify that the system covered by this certificate has been commissioned satisfactorily. Contract Reference Completion Contract Title Engineers Installing Installation Commenced Commissioning Works Description Part/Whole Certificate Handover Date Part 3.The system(s) designed and installed in accordance with the following documents:... - Page 22 PF8000 Maintenance Before carrying out any maintenance to the installation, disconnect the mains power supply. Maintenance Checks should be carried out every 3 months. This can alter dependant on usage. • The pivot points must be inspected and lubricated regularly and the pivot pins (if fitted) removed and inspected and replaced if necessary.
- Page 23 We hereby certify that the machinery stipulated below complies with all relevant provisions of the EC Machinery Directive and National Laws and Regulations adopting this Directive. Manufacturer Parking Facilities Ltd & European Unit 1 Kingsbury Link Industrial Estate Agent: Trinity Road...
- Page 24 PF8000 Specification CE Rated 340mm / 500mm / 800mm Height Available in Half-Width Sizes 2-5 Metres Length Power Requirements 240V 10 Amp MCB 50Hz Weight Capacity Maximum 12 Tonnes on Standard Kerbs Galvanised & MMA Flexgrip Paint (Top Plate) Finish Operation Time 4.0-6.0 Seconds...
