PEN00042-03
DUMP TRUCK
HD785
-5
4254
SERIAL NUMBERS
and up
WARNING
Unsafe Use of this machine may cause serious injury or
Death.Operators and maintenance personnel must read
this manual before operating or maintaining this machine.
This manual should be kept near the machine for
reference and periodically reviewed by all personnel
who will come into contact with it .
NOTICE
Komatsu has Operation & Maintenance Manuals written
in some other languages. if a foreign language manual
is necessary, contact your local distributor for
availability.
