Carex Day-Light Sky Quick Start Manual

• Choose the two-light setting for light therapy, and the
one-light setting for lower intensity ambient or task light.

Day-Light Sky Benefits

The Day-Light Sky brings the light of a springtime morning into
your home or office. Using your Day-Light Sky on a regular
basis during the fall, winter and spring months will not only
help to keep your mood and energy level up, but it will also
pleasantly brighten your home or office.
Whether used as a task light, reading lamp, or for enjoyable
ambient light, your Day-Light Sky can be put to good use for
much more than your regular 20-30 minute light therapy
session each morning.

Day-Light Sky Features

Your Day-Light Sky is designed with versatility and
convenience in mind.
• You can adjust the light to the optimal height and angle for
your light therapy session.
• Choose the two-light setting for light therapy, and the one-
light setting for lower intensity ambient or task light.

Specifications

UL and C-UL Listed
• Enclosure size: 13.7 in x 10.38 in x 2.75 in
(26.2cm x 35.2cm x 7.2cm)
• Height: Max: 27.25 in / 69.2 cm
Mid 26.25 in / 66.6 cm
Min: 25 in / 63.5 cm
• Weight of Light: 8.2 lbs. / 3.7 kg
• LED Bulbs: 192 Instant start LED's
• Lens Material: High-impact polycarbonate
• UV Output: 100% Free
• Two Settings: 10,000 LUX - Therapy
5,000 LUX - Task
• Color Temp: 4,000 Kelvin
• Warranty: Five-year limited warranty
1. Light Head
2. Adjustable arm
3. Adjustable button
4. On/Off/Setting Switch
5. Base Plate
6. Air Vents

Before Using Your Sky

Check package contents to ensure that all parts listed are
enclosed and in good condition.
• Day-Light Sky Unit
• Removable base plate
• Grounded power cord
• 1 Philips screw
• #2 Philips screwdriver
• Instruction guide
Contact your dealer if any product parts are missing or
damaged.

Warning

Your Day-Light has been packed with the light head turned at
a 90˚ angle. The light head can only be rotated counter
clockwise 90˚ from this position to the position for use and
back to the packing position. Turning the light head beyond
this range will damage your Day-Light.

Disclaimer

The Day-Light Sky is an innovative light supply system and is
not a listed medical device in the USA.

Assembling your Day-Light Sky

The base plate ensures your Day-Light Sky will stand in a
stable position.
Lay your Day-Light Sky
1.
in the packing position
Lay your Day-Light Sky in the packing position with the
with the lens facing
lens facing upward.
upward.
Position your Day-Light Sky base into the recessed
groove on the base plate with the front of the base
plate facing forward. Align the hole in the base with
Position your Day-
the hole in the Day-Light Sky.
2.
Light Sky base into the
recessed groove on
the base plate with
Using the included Philips #2 screwdriver, insert and
the front of the base
tighten the single Philips screw securely into the light
plate facing forward.
Align the hole in the
base. Do not over tighten.
base with the hole in
the Day-Light Sky.
4. Carefully lift the assembled unit and stand it upright.
Using the included
Philips #2 screwdriver,
3.
insert and tighten the
single Philips screw
5. Turn the light head counter clockwise 90° for
securely into the light
therapeutic or task lighting.
base. Do not over
tighten.
4. Carefully lift the assembled unit and stand it upright.
4. Carefully lift the
5. Turn the light head counter clockwise 90° for therapeutic
assembled unit and
or task lighting.
stand it upright.

Light Settings

There are two light intensity settings on your new Day-Light
5. Turn the light
Sky – a high intensity and low intensity setting.
head counter
High Intensity Setting — Light Therapy
clockwise 90° for
10,000 LUX of light is emitted at a distance of 12"/30 cm from
therapeutic or task
the lamp. This is the recommended dosage for 20-30 minute
lighting.
daily light therapy sessions.
Low Intensity Setting – Task or Ambient Lighting
This may be used for everyday lighting or task lighting where
a comfortable light level is required.

Adjusting Light Angle and Height

For optimum light therapy results, you will need to adjust
your Day-Light Sky so that:
• The light shines down at an angle of about 15°; and
• Your eyes are approximately in the center of the light.
Adjustable button

To Adjust Angle and Height of the Light

There are two adjustment buttons on the arm of your
Day-Light Sky. Each silver button, when pressed, allows
you to move the light head or arm to several different
positions.
When you wish to adjust the height or angle of the light
head, press the appropriate adjustment button while
holding the light head to move it to desired position.
To maintain the position, release the adjustment button
to lock the arm in position.
By removing your hand from the light head and allowing
it to engage, the head will properly and gently settle to
the engaged position.
To set the angle of the light at approximately 15° use the
best combination of adjustments of the light head based
on your position from the lamp and your height.
When not using your Day-Light Sky for light therapy, you
can easily reposition the light head to use as a task lamp
over or near your work space.
Correct Position for Therapy
The lamp head angle should be set around 15⁰ from 90⁰
vertical and the lamp head height adjusted so that your
eyes are approximately in the center of the light. The
light should down on your eyes, do not stare at the light.
Sit 12"/30 cm from the light. You can comfortably read or
have breakfast at this distance. Moving the lamp farther
away can still provide a therapeutic benefit (up to about
24"/60 cm), but treatment times may be longer as the
LUX levels reaching your eyes decrease.
