The electricity used by compressors for air accounts for approximately
by the entire factory. Also, 70% of the air consumed in the process is used for air blowing. SMC
blow guns have minimal pressure loss compared with conventional models, so they can achieve
equivalent performance at lower pressures and with less volume of air consumption. As a result,
it is possible to achieve a
VMG
Series
Courtesy of Steven Engineering, Inc.-230 Ryan Way, South San Francisco, CA 94080-6370-Main Office: (650) 588-9200-Outside Local Area: (800) 258-9200-www.stevenengineering.com
Page 1
Blow Gun reduction reduction in power consumption with the SMC “Blow gun” + “S coupler” + “Coil tube” ∗ 10% reduction with the “Blow gun (VMG)” only Amount of electricity used in a factory Actuators Air leakage DOWN Coolant Air blow Air blow Others Conventional model...
Page 2
Energy Saving Pneumatic System Proposal Energy Saving Effects When the yearly total working hours spent on air blowing amounts to 8,300 hours, use of conventional models results in power consumption costs totaling 194,220 yen. When using the SMC system (Blow gun + S coupler + Coil tube), however, the yearly cost is reduced to 155,625 yen, for a total yearly saving of 38,595 yen, or 20% of the...
Page 3
SMC helps you work toward a revolutionized production system with a focus on saving-energy. Example of Improvement Review the air-blow job and change to the SMC blow gun, S coupler and coil tube to create a larger effec- tive area. After improvement Before improvement Filter...
Recommended system in Blow Gun, Coil Tube and S Coupler Selection accordance with the distance Energy saving effects are enhanced through the appropriate blow gun model selection in accordance with the distance from the target object. Recommended system Distance Blow gun Nozzle size Fitting Coil tube...
Page 5
Variations One-touch fitting type Nozzle type Low noise nozzle Mono-porous nozzle (ø2) 90 to 100 dB ø1 x 4 low noise nozzles 80 dB or less Note) Supply pressure: 0.5 MPa Measured at a 45 degree angle according to JIS B 8379 ∗...
Page 6
Blow Gun RoHS Series How to Order VMG 1 1 02 01 Blow gun Standard type Nozzle Symbol Type Nozzle model Nozzle size Series Without nozzle Resin body lever type ø1 KN-R02-100 ø1.5 KN-R02-150 Male thread nozzle ø2 KN-R02-200 Piping entry KN-R02-250 ø2.5 Bottom...
Page 7
Series Blow Gun Construction Component Parts Description Material Note Body L Body R Main valve Valve guide Aluminium alloy Chromated Aluminium alloy Anodized Nozzle holder Port Aluminium alloy Anodized Only for VMG12 Elbow Cover Stainless steel Stainless steel Ring Arm L Arm R !1 !0 Stainless steel...
Page 8
Series Dimensions VMG11/Piping entry: Bottom Note) Reference dimensions after installation Rc 1/4 Nozzle Width across flats 117.5 Rc, NPT, G 1/4, 3/8 S coupler plug One-touch fitting S coupler plug mounting mounting mounting KK4P-02MS KQ2H KK130P-02MS (Series VMG12/Piping entry: Top Rc, NPT, G 1/4, 3/8 Width across flats Rc 1/4...
Page 9
Series Blow Gun Dimensions: Nozzles/Series Male thread nozzle: (mm) Width across flats Nozzle size Connection A ∗ Model Connection thread thread KN-R02-100 ø1 R 1/4 31.4 25.4 KN-R02-150 ø1.5 R 1/4 KN-R02-200 ø2 R 1/4 30.5 24.5 KN-R02-250 ø2.5 R 1/4 30.1 24.1 ∗...
Page 10
Series Specific Product Precautions 1 Be sure to read this before handling. Piping Selection Warning Caution 1. Check the specifications. 3. Wrapping of pipe tape The products in this catalog are designed to be used in When screwing together pipes and fittings, etc., be certain that compressed air systems only.
Page 11
Series Specific Product Precautions 2 Be sure to read this before handling. Air Supply Handling Caution Warning 1. To prevent lurching of the nozzle due to air 1. Install air filters. pressure, confirm that the nozzle is not Install air filters at the upstream side of blow gun. Choose the filtration degree of 5 µm or finer.
These safety instructions are intended to prevent hazardous situations and/or Safety Instructions equipment damage. These instructions indicate the level of potential hazard with the labels of “Caution,” “Warning” or “Danger.” They are all important notes for ∗1) safety and must be followed in addition to International Standards (ISO/IEC) and other safety regulations.
