Active Ingredients
Copper (as elemental):
Silver:
Other Ingredients:
Total Ingredients:
This product is toxic to aquatic organisms.
Store in closed, original container in a cool dry place. Do not store in direct sunlight. Dispose of packaging in
household garbage or recycling stream.
It is a violation of federal law to use this product in a manner inconsistent with its labeling. This product will
assist in controlling bacteria and algae in pools and spas by augmenting the bactericidal and algicidal activity of
primary disinfectants such as chlorine or bromine. See owner's manual inside box for full installation
procedures, maintenance instructions and detailed directions for use. Ensure hardness, pH, alkalinity and TDS
are within acceptable levels. Excessive amounts of algae or bacteria must be controlled prior to installation. Run
the pump a minimum of 8 hours per day. A residual of 0.5ppm chlorine or bromine (equivalent to one 3" tablet
every week or two) should be maintained to break down organics. Once the copper concentration has reached
the required level of 0.2 – 0.4 ppm, maintain 0.5 – 3 ppm of free available chlorine in pools and 0.5 – 5 ppm of
free available chlorine in spas. Shock may be required in cases of extreme weather conditions or increased
bather loads resulting in high contaminants. Regulated pools must follow provincial, state or municipal
guidelines. Before draining a treated pool, spa, hot tub, or fountain, contact your local sanitary sewer and storm
drain authorities and follow their discharge instructions. Do not discharge treated pool or spa water to any
location that flows to a gutter, storm drain or natural water body unless discharge is allowed by state and local
authorities.
REGISTRATION NUMBER 29954 PEST CONTROL PRODUCTS ACT
COMMERCIAL MODEL A-850 COPPER ION RELEASING DEVICE HELPS PREVENT ALGAE GROWTH IN SWIMMING POOLS AND SPAS
A maximum of 151,400L (40,000 Gal) of water can be treated with the ClearBlue Ionizer
NOTICE TO USER: This control product is to be used only in accordance with the directions on this label. It is an offence under
the Pest Control Products Act to use this product in a way that is inconsistent with the directions on the label. The user assumes
the risk to persons or property that arises from any such use of this product.
Read the label and the installation and operation manual before using
85.04%
5.00%
9.96%
100%
ENVIRONMENTAL HAZARDS
STORAGE AND DISPOSAL
DIRECTIONS FOR USE
EPA MASTER LABEL
EPA REG. No. 90859-2
EPA EST. No. 90859-CAN-1
Manufactured by ClearBlue Ionizer Inc.
3045 Southcreek Rd. Unit 45
Mississauga ON L4X 2E9
Tel. (866) 704-8404
support@clearblueionizer.com
www.clearblueionizer.com
MADE IN NORTH AMERICA
KEEP OUT OF REACH OF CHILDREN
CAUTION
NOTICE TO USER: This control product is to be used
only as directed on this label. Read entire label along
with installation and operation manual before use.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the 90859-2 and is the answer not in the manual?

Questions and answers

Summary of Contents for Clearblue 90859-2

  • Page 1 COMMERCIAL MODEL A-850 COPPER ION RELEASING DEVICE HELPS PREVENT ALGAE GROWTH IN SWIMMING POOLS AND SPAS A maximum of 151,400L (40,000 Gal) of water can be treated with the ClearBlue Ionizer NOTICE TO USER: This control product is to be used only in accordance with the directions on this label. It is an offence under the Pest Control Products Act to use this product in a way that is inconsistent with the directions on the label.
  • Page 2: Table Of Contents

    Table of Contents Electrical Requirements ..............................3 Installation Instructions for Pools ..........................4 Install the Tee ................................4 Cut plumbing and glue in the tee .......................... 4 Install the Mineral Cell .............................. 5 Install the System Controller ............................. 5 System Controller Configuration ........................... 6 Ion/Action .................................
  • Page 3: Electrical Requirements

    Thank you for purchasing a ClearBlue Ionizer. This device will assist in controlling bacteria and algae in pools and spas by augmenting the bactericidal and algicidal activity of primary disinfectants such as chlorine or bromine. Once the copper concentration has reached the required level of 0.2 – 0.4ppm, maintain 0.6 –...
  • Page 4: Installation Instructions For Pools

    Installation Instructions for Pools The ClearBlue Ionizer system install requires three components that are included in the kit. You will also need a hacksaw or reciprocating saw, PVC primer and PVC glue that are not included. System Controller Clear PVC Tee...
  • Page 5: Install The Mineral Cell

    Install the Mineral Cell Once the PVC glue has dried, you can install the Mineral Cell by threading it into the tee. Teflon tape is not needed. Tighten the cell until it is hand tight. Orient the bars such that the water will flow between the two bars (or as close as possible with no leaking).
  • Page 6: System Controller Configuration

    When the cell cable is plugged into the controller and the housing is completely threaded into the tee with the two electrode bars under water, the ‘Ionizing’ light will illuminate or flash blue. If the ‘Ionizing’ light is flashing red, make sure that the cell is plugged in all the way and the two electrode bars are completely under water.
  • Page 7: Calculating Pool Volume

    DO NOT REDUCE CHLORINE/BROMINE CONCENTRATION UNTIL COPPER LEVEL REACHES 0.2PPM Calculating Pool Volume The ClearBlue controller settings are based on the volume of water in your pool or hot tub. Please use the calculations below to determine your water volume.
  • Page 8: Ion/Action And Large Dose Setting From Gallons

    Ion/Action and Large Dose Setting from Gallons The model number is on the back of the controller. Model Ion/Action and Large Dose Setting Calculation Example ���� ������ ������������ ���� �������������� ������ �������������� A-400 �� ���� = ���� �� ���� ��, ������ �������������� 2,500 gal max ��, ������...
  • Page 9: Topside Control Option (Hot Tubs Only)

    Topside Control Option (Hot Tubs Only) Topside control found on some hot tubs Topside Ionizing Indicator When the mode of the controller is set to “Ion/Action” and the “Ionizing” light is illuminated on the controller, the area in the center of the topside control will illuminate in blue. Topside Large Dose Function Press the center of the logo to engage the “Large Dose”...
  • Page 10: Pool And Water Maintenance

    Opening your Pool When you open your ClearBlue mineral pool, you can follow the instructions of your pool builder or pool store. They may recommend an opening kit with products designed to condition the water and get you swimming as quickly as possible.
  • Page 11: Water Parameters

    Metal removers, sequestering agents and some stain removers conflict with ClearBlue. If one of these products is used, it will remove the ClearBlue minerals and neutralize minerals for up to 6 weeks. Unplug or power off the ClearBlue controller for at least 4 weeks after using these products to prevent unnecessary wear to the cell.
  • Page 12: Closing The Pool

    Closing the Pool When closing your pool, you can follow the closing instructions from you pool store or pool service. If they recommend a closing kit, take note if there is a stain and scale or other sequestering product used as part of the closing.
  • Page 13: Troubleshooting

    Troubleshooting Problem Possible Cause Solution The ‘Ionizing’ light is flashing red The cell is not plugged in all the way Make sure the cell cable is completely plugged into the controller The electrodes are not under water Make sure the electrode bars are completely under water.
  • Page 14: Specifications

    Average 6 months (2,160 “on” hours) Warranty The ClearBlue Ionizer controller is covered by a 5-year limited warranty. The mineral cells are designed to wear down and they do not have a warranty, however, they will be replaced free of charge if there is an obvious defect.
