Summary of Contents for Gestton EG-2204
- Page 1 Wireless Microphone System EG-2204 UHF 4-Channel GROUP FREQ LEVEL RF AF 819.500 LOCK RECEIVER 【 使用说明书 】 Operating Instructions...
- Page 2 Attached a pair of UHF antennas to the antenna input jacks, the antenna ② 2. Receiver Controls and Functions are normally positioned in the shape of a “V” (both 45°from vertical) for EG-2204 Front panel best reception. EG-2204 Rear panel Keep antennas away from noise sources such as computer, digital ③...
- Page 3 Wireless Microphone System Wireless Microphone System 2, Receiver Controls and Functions Figure 2: Rear Panel Receiver Features: ① Rugged metal chassis with soft-touch controls. ② Total 300 selectable frequencies and preset 10 interference-free groups. ③ Up to 16 simultaneous transmitting units. ④...
- Page 4 Wireless Microphone System Wireless Microphone System Figure 3: Figure 4: ① Microphone: Pick up the sound. ② Microphone in-use indicator: Lights when the microphone is turned on (for speech) and flashes when the battery level is low. LCD Window: Liquid Crystal Display ③...
- Page 5 Wireless Microphone System Wireless Microphone System VOL (volume): Selecting “VOL”(highlights), push the Control Knob Figure 5: once to enter the edit mode, rotate the knob to scroll through the available choice for the function. The volume level is providing a 20dB range. Then push the knob to save “YES' or “NO'.
- Page 6 Wireless Microphone System Wireless Microphone System 5， Specifications Transmitters Setup EG-2204 4-Channel Receiver ① Turn on one transmitter. Frequency setup: To let the transmitter IR receiving window face to the one ② of receiver IR data transfer windows, then press “SYNC” button, the Main Frame Size EIA-Standard 19"...
- Page 7 Wireless Microphone System EG-2204D Conferencing Microphone Carrier Frequency Range UHF 620--850 MHz Fixed-charge back plate, permanently Element polarized condensers Harmonic radiation ＜-65dBm Bandwidth 30MHz Max. Deviation Range ±45KHz Input Connector 4-pin mini-XLR connector RF Power Output 15mW Battery Rechargeable battery Current Consumption 100mA, typical Battery Current / Life...
