X3 Captains Choice Electronic with Block Off
SKU(s): Red (301DC0012), Black (301DC0013), Platinum (301DC0014), Yellow
(301DC0015), Orange (301DC0061), White (301DC0062), Blue (301DC0063)
INCLUDED PARTS
(1) Electronic Captains Choice
with Block Off.
(1) Electronic Harness
REQUIRED TOOLS
T-30 Torx
Spring Puller
Flat Head Screwdriver
Rev_022221
Advertisement
Table of Contents
Related Manuals for Evolution Powersports X3
Summary of Contents for Evolution Powersports X3
- Page 1 X3 Captains Choice Electronic with Block Off SKU(s): Red (301DC0012), Black (301DC0013), Platinum (301DC0014), Yellow (301DC0015), Orange (301DC0061), White (301DC0062), Blue (301DC0063) INCLUDED PARTS REQUIRED TOOLS (1) Electronic Captains Choice T-30 Torx with Block Off. Spring Puller (1) Electronic Harness...
- Page 2 Installation Step 1: Remove rear valance covering the OEM exhaust muffler. Step 2: Using a heavy-duty spring tool, remove the 4 springs holding the muffler to the race bypass pipe. Step 3: Remove the 4 bolts and nuts securing the muffler to the frame of the machine and remove muffler.
- Page 3 Step 3: Make cable and antenna connections to the receiver box. Rev_022221...
- Page 4 Step 4: Mount Receiver in the location shown below using the supplied Velcro. Make sure the area is clean and warm – use a hair dryer to warm up the plastic prior to installation if it is below 70 deg F. See picture below. Step 5: Zip tie power cable so it will not interfere with steering or braking functions Step 6: Route cable to the exhaust valve actuator along the inside of the vehicle frame, then to the actuator.
- Page 5 Thank you for choosing Evolution Powersports products. If you require further assistance, please call our Tech Support @ (715) 247-3862 Note: This product is exempt from the emission standards and related requirements of 40 C.F.R. § 1051 as provided by 40 C.F.R. § 1051.620, and California law [e.g., vehicle code§§ 27156 and 38391]. This product...
