Infuser

Hydrogen

Inhalator

MANUAL

Drinking Hydrogen water

breathing Hydrogen gas

• The Hydrogen Infuser & H2 Inhaler produces 100 ml

Hydrogen gas per minute for preparation of hydrogen-rich

beverages or for inhalation of Hydrogen with a nasal

inhaler. With the corresponding Hydrogen quirler can

fully saturated hydrogen water (1.6 mg/l) be produced

in 90 sec. For this other Hydrogen boosters need at least

600 seconds!

• Since the hydrogen drink produced does not come into

any contact with electricity and electrodes, other drinks

such as juices, milk, soups can also be enriched with

hydrogen in a few seconds.

• Inhaling 100 ml/minute (1/3 inhaling - 1/3 pause - 1/3

exhaling) creates within 10 minutes a litre of pure

hydrogen energy in your body. This is the true power

nap, whether in the office, while watching TV or while

sleeping. Hydrogen inhalation and the drinking of

hydrogen-rich water has been a megatrend in Japan

since 2016.

Table of Contents

Need help?

Do you have a question about the Hydrogen Infuser & H2 Inhalator and is the answer not in the manual?

Questions and answers

Summary of Contents for Aquavolta Hydrogen Infuser & H2 Inhalator

Page 1 Drinking Hydrogen water & breathing Hydrogen gas • The Hydrogen Infuser & H2 Inhaler produces 100 ml Hydrogen gas per minute for preparation of hydrogen-rich beverages or for inhalation of Hydrogen with a nasal Infuser Hydrogen inhaler. With the corresponding Hydrogen quirler can fully saturated hydrogen water (1.6 mg/l) be produced &...
Page 2: Table Of Contents
3. Intended purpose 4. Scope of delivery 5. Overview H2-Generator 6. Generator accessories 7. Commissioning 1 8. Commissioning 2 9. Commissioning 3 10.Commissioning 4 11.Preparing to inhale 12.Inhalation operation 13.Assembly of the Infuser 14.The quirler bottle 15.Not just water! 16.Maintenance signals 17.Filter change 18.Please note 19.Safety instructions...
Page 3: Intended Purpose
Intended purpose The hydrogen generator produces 100 ml of purest hydrogen gas per minute and can be used for two functions Production of hydrogen-rich beverages Inhalation of hydrogen...
Page 4: Scope Of Delivery
Scope of delivery The larger of the two packages contains the hydrogen generator with inhalation accessories. The smaller package contains the hydrogen infuser (quirler) with the accessories for the production of hydrogen-rich beverages. The infuser only works if it is connected to the hydrogen generator.
Page 5: Overview H2-Generator
Overview H2-Generator 1. Switching sensor 2. Window for function control 3. Tank cap of refill tank for double distilled water 4. Hydrogen outlet nozzle with cap 5. Valve for O2 outlet 6. Connecting socket for H2-water quirler 7. Socket for mains plug...
Page 6: Generator Accessories
Generator accessories 1. Nose inhaler 2. Mains cable 3. Power supply unit 4. Connecting cable 5. Water collector 6. Water filter...
Page 7 Commissioning 1 Screw on the water refill tank and fill with double distilled water up to the line marked on the left. Then insert the water filter and turn the cover of the water tank back in.
Page 8: Commissioning 2
Commissioning 2 2. Plug the adapter of the power supply unit into the lower right socket and connect the power plug to the power supply unit and a 220 volt socket. A blue flashing light on the switch sensor indicates that a test of the device functions is being carried out.
Page 9: Commissioning
Commissioning outlet with flip-cap outlet to be pulled 3. Open the flip-cap above the H2 outlet. Then open the O2 valve by pulling it upwards a little.
Page 10 Comissioning 4  Very important! Do not interrupt this process! 4. Gently shake the unit 4-5 times to remove any remaining air bubbles from the unit. Then press the sensor switch for 5 seconds to start the activation mode. The activation process takes 2 hours. Meanwhile the blue sensor lamp flashes.
Page 11: Preparing To Inhale
Preparing to inhale 1. Insert the curved short hose of the water collector into the open H2 outlet. 2. Firmly push the end of the nasal inhaler onto the second outlet of the water collector. 3. Tighten the nasal inhaler on the back of the head as shown on the right.
Page 12: Inhalation Operation
Inhalation operation Pressing shortly on the sensor button starts the release of hydrogen into the nasal inhaler. The sensor lights up blue. Press again to stop. After two hours the device stops automatically. So you can work, watch TV, play cards and even sleep. If there is not enough water in the device, it beeps and a red LED light lights up.
Page 13: Assembly Of The Infuser
outlet must always be open when quirling! 2 – Quick guide Infuser mode: inlet 1. Fill the drink exactly up to the 400 ml mark. 2. Tighten the lid and release the H2 Pouring- / input socket. drinking outlet 3. Connect the H2 input socket to the infusions tube H2 output of the inhaler.
Page 14 The Hydrogen Infusor quirler bottle The water or other desired non-carbonated drink (tea, juice, milk etc.) is filled exactly up to the 400 ml mark (1) into the quirler bottle. The lid of the quirler is turned to the indicated position (2). The quirler is then connected to the hydrogen generator using the short hose (3) from the quirler accessories.
Page 15: Not Just Water
The Aquavolta® Hydrogen Infuser, on the other hand, produces hydrogen from the purest laboratory water with a purity of almost 100%. The liquid quirled with hydrogen in the Infuser has thus...
Page 16: Maintenance Signals
1. Maintenance signals 2. Maintenance signals Maintenance signals • Water level warning: The LED is permanently red and a beep sounds. Please refill the tank with double distilled water. • Water in the supply line to the nasal inhaler or quirler: The LED blinks red and a beep sounds.
Page 17: Filter Change
Filter change • If the LED flashes blue, the filter must be changed. • First switch off the device at the switching sensor. • Unscrew the cover of the water tank and replace the removable filter. • Screw in the water tank cover again and briefly press the sensor button.
Page 18: Please Note
Please note: 01. Please use only original filters for replacement. 02. Only pour double distilled water (laboratory water) into the tank. 03. The nasal inhaler must not be used by the same person for more than 1 month and must be replaced at the latest then. 04.
Page 19: Safety Instructions
Safety instructions 01. Before switching on, the valve for the O2 outlet must be pulled upwards. 02. Only use the unit in a ventilated room and keep heat away from it. 03. Make sure that the power plugs are firmly plugged in. 04.
Page 20: Core Technology: Pem Electrolysis
Core technology: PEM electrolysis...
Page 21 Security technology - Pressure sensor Even at the slightest risk of too much hydrogen escaping, the generator immediately switches off automatically. If the nasal inhaler blocks or if you put just a little bit too much water into the infuser, hydrogen production stops until the operating error is corrected.
Page 22 The quirler for perfect galenic H • A unique cavitation-promoting high-speed vortex technology ensures that the hydrogen saturates much faster in the liquid than with other techniques. • The hydrogen is drawn into the water by a tornado-like vortex, which reduces large bubbles to microbubbles.
Page 23: Transfer Of Hydrogen
Transfer of hydrogen If hydrogen is dissolved in water, it can easily penetrate food and prevent and even reverse oxidation processes when storing and transporting. In the process, the food placed in such water becomes more electron-rich, as can be measured by a significantly lower redox potential.
Page 24: Technical Data
Technical Data Hydrogen Infuser & H – Inhalator  • Hydrogen output: 100 ml/minute (+/- 10 %) • Hydrogen purity (certified): > 99.995 % • Process water: Double distilled water or laboratory water. < 5 μs/cm • Input voltage of the external power supply: Alternating current 100-240 V /50 - 60 Hz •...
