SB01 Mounting Bracket Installation Sheet
EN DE ES FR IT NL
1A
A
4A
EN: Installation Sheet
Features
The SB01 is a flexible mounting bracket for several UTC Fire & Security
detectors. It has the following features:
• Horizontal adjustment +45°, 0°, -45°.
• Vertical adjustment 0°, -5°.
•
Wall (A) and ceiling (B) mounting.
•
Safety adjustment blocking and mounting inside the detector.
•
Completely enclosed wiring.
•
Throughput wiring is possible.
Mounting
See Figures 1A n to 6A or 1B n to 6B.
Optional
The ST400 tamper switch can be used as a wall and/or ceiling tamper.
