Quick Guide
MESI ABI MODULE
Ankle-Brachial Index Diagnostic Module
WHAT IS IN THE BOX?
4x MESI tubeless cuff unit
Model
CUFFMD
4x tubeless cuff - Medium
(LA, RA, LL, RL)
Before using the device for the first time, read the user manual carefully and follow
the recommendations here: www.mesimedical.com/support/mTABLET/IFU.
Advertisement
Table of Contents
Summary of Contents for MESI CUFFMD
- Page 1 Quick Guide MESI ABI MODULE Ankle-Brachial Index Diagnostic Module WHAT IS IN THE BOX? 4x MESI tubeless cuff unit Model CUFFMD 4x tubeless cuff - Medium (LA, RA, LL, RL) Before using the device for the first time, read the user manual carefully and follow...
- Page 2 1. Connect the cuff to the unit MESI tubeless cuffs are disconnected during storage and transportation. Before first use connect the cuff to the port on the MESI TUBELESS CUFF UNIT, as shown on the image below. Ensure that the cuff is securely connected.
- Page 3 ABISYS - 3/6 3. Add/select patient On your MESI mTABLET UNIT, select existing patient (1) or add a new one (2). 4. Choose the measurement After selecting the patient, please select the ABI measurement in the application menu.
- Page 4 ABISYS - 4/6 5. Select 3-cuff or 4-cuff measurement Select 3-cuff or 4-cuff measurement (when choosing 3-cuff measurement select right or left arm) and press OK. 6. Perform the measurement Observe the position indication on the cuffs and place them on appropriate arm or leg.
- Page 5 ABISYS - 5/6 7. Reviewing ABI measurement Go to: previous/next result Repeat the measurement Share for second opinion Discard result Navigation area Go to: Application screen Right and Left Ankle-Brachial Index Measurement result SmartArm™ automatic higher blood pressure result Show more: right and left leg blood pressure, right and left arm blood pressure Oscillation graphs...
- Page 6 ABISYS - 6/6 WARNINGS The MESI mTABLET ABI users must be adequately trained to use the device. Before the first use of the device, users must carefully read the entire instructions for use and follow the instructions for use of the connected equipment.
