FUJISOL SaltPool Installation And Operation Manual

Salt generator for aboveground pools

Advertisement

Quick Links

SALT GENERATOR FOR
ABOVEGROUND POOLS
For
Pool Water
that Feels
Silky
On Your
Skin!
Installation and Operation Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the SaltPool and is the answer not in the manual?

Questions and answers

Summary of Contents for FUJISOL SaltPool

  • Page 1 SALT GENERATOR FOR ABOVEGROUND POOLS Pool Water that Feels Silky On Your Skin! Installation and Operation Manual...
  • Page 2 IMPORTANT SAFETY INSTRUCTIONS • When using electrical equipment, basic safety precautions should always be exercised, including the following: READ AND FOLLOW ALL INSTRUCTIONS • Disconnect all AC power during installation. • Do not permit children to use this product. • A green colored screw is located inside the wiring compartment, against the back panel. To reduce the risk of electric shock, this terminal must be connected to the grounding means provided in the electric supply service panel with a continuous copper wire equivalent in size to the circuit conductors supplying the equipment.
  • Page 3: Table Of Contents

    TABLE OF CONTENTS OPERATION SPS........................ 4 Water Chemistry..................5-9 Controls....................10-11 Maintenance..................11-12 INSTALLATION Mounting..................... 13 Plumbing.....................13 Wiring......................14 TROUBLESHOOTING Troubleshooting..................15 WARRANTY Warranty..................... 16...
  • Page 4: Sps

    OPERATION • The SPS is an automatic chlorine generation system for pool & spa sanitation designed specifically for above ground pools. The operation requires a low concentration of salt (sodium chloride) in the pool water at levels low enough that it normally cannot be tasted. SPS automatically sanitizes your pool by converting the salt into free chlorine, which kills bacteria and algae in the pool, through a process called electrolysis.
  • Page 5 IDEAL CHEMICAL LEVELS Salt 3200 to 4000 ppm Free Chlorine 1.0 to 3.0 ppm 7.2 to 7.6 Cyanuric Acid (Stabilizer) 50 to 100 ppm Total Alkalinity 80 to 120 ppm Calcium Hardness 200 to 400 ppm Metals 0 ppm Saturation Index -.2 to .2 -.5 to .5 SATURATION INDEX •...
  • Page 6 Calcium Total °C °F Alkalinity • How to use: Measure pool pH, temperature, calcium hardness, and total alkalinity. Use the chart above to determine Ti, Ci,and Ai from your measurements. Insert values of pH, Ti, Ci and Ai into the above equation. If Si equals .2 or more, scaling and staining may occur.
  • Page 7 • The ideal salt level is between 3200-4000 ppm. (parts per million) with 3600 ppm being the optimal level. Calculate the number of gallons in the pool and add salt according to the chart on page 8. • A LOW salt level will reduce the efficiency of the SPS and result in low chlorine production.
  • Page 8 POUNDS AND (Kg) OF SALT NEEDED FOR 3600 PPM • Gallons and (Liters) of Pool water 6,000 8,000 10,000 12,000 14,000 16,000 18,000 CURRENT SALT LEVEL (22,500) (30,000) (37,500) (45,000) (52,500) (60,000) (67,500) (82) (109) (136) (163) (190) (218) (245) (78) (103) (129)
  • Page 9 STABILIZER (CYANURIC ACID) • Always test for stabilizer (cyanuric acid) level, when testing for salt. This test should be done at least once per month. Use the chart below to determine how much stabilizer must be added to raise the level to 80 ppm . POUNDS AND (Kg) OF STABILIZER (CYANURIC ACID) NEEDED FOR 80 ppm •...
  • Page 10: Controls

    CONTROLS SPS aboveground Salt Generators have an Auto control system with a very simple operation. • DESIRED LEVEL: There are 10 LEDS, each LED is 10%, chose the “desired level %” by pressing Min to decrease or Max to increase. The SPS will produce chlorine according to the “Desired Level %”...
  • Page 11 INDICATOR LED • POWER: When LED is on the SPS has input power. • NO FLOW: When illuminated, the flow switch has detected no flow and SPS is NOT generating chlorine. A flashing LED indicates that the flow is restored, but there will be a 60 second delay before generation is reestablished.
  • Page 12 SERVICING AND CLEANING THE CELL • Turn off power to the SPS before removing the CELL. • Once removed, look inside the cell and inspect for scale formation (light colored crusty or flaky deposits) on the plates and for any debris that has passed through the filter and gotten caught on the plates.
  • Page 13: Mounting

    MOUNTING THE SPS CONTROL...
  • Page 14: Plumbing

    SPRING START-UP • DO NOT turn SPS on, until the pool water chemistry has been balanced to proper levels. INSTALLATION • The SPS electrolytic cell and flow detection switch will be damaged by freezing water, similar to other pool components that require proper winterization. In areas of the country that experience severe or extended periods of freezing temperatures, be sure to drain all water from the pump, filter, and supply and return lines before any freezing conditions occur.
  • Page 15: Wiring

    HOSE PIPE INSTALLATIONS (-HP Option) • Install the cell and flow switch as shown in the diagrams below. Always make sure that the flow switch is after the cell. When using the hose adaptors, remove the O-ring from the pipe union tailpiece and install them in the hose tailpieces. Tighten all union nuts BY HAND for a watertight seal.
  • Page 16: Troubleshooting

    TROUBLESHOOTING “Power” LED not on Check to make sure 120V AC input power is connected to the control. Verify input voltage with a voltmeter. If there is input power, the fuse may have blown. The board is protected by a 5 amp mini ATO fuse located on the circuit board above the cell connector. “No Flow”...
