Linkable solar led fence light

Advertisement

Available languages

Available languages

Quick Links

FOR FIRST TIME USE: SOLAR LIGHT NEEDS TO CHARGE IN FULL SUNLIGHT FOR 8 -12 HOURS WITH THE SWITCH IN
THE "ON" POSITION TO FULLY CHARGE THE RECHARGEABLE BATTERY.
IF INSTALLING MORE THAN 1 LIGHT, YOU MUST LINK YOUR LIGHTS FIRST BEFORE INSTALLATION BEGINS. YOU MAY
LINK UP TO 20 LIGHTS. AFTER THE LIGHTS ARE LINKED YOU MAY BEGIN THE INSTALLATION PROCESS.
The intelligent solar LED motion activated light measures the corresponding available battery power through the current voltage point of
the battery, adjusts the energy and lumen output, and maximizes the lighting time.

Tools Required

Pencil
Phillips-head
Screwdriver
1

Marking the location

Mark the location where you want to mount the light xture (Part C) .
Measure the width of two holes on the back of the solar fence
light to align holes for the 2 screws (Part A) on the surface. The
distance between the two holes is 4.7in. (120mm).
Drill two holes.
2

Mounting the light

wall anchors
Part
Insert the
(
Part
Insert the screws (
A) and leave at least 1/4in. (6.3mm) of the
Part
screws (
A) outside of the surface for holding the solar fence light.
Mount the light on the screws (
on the back of the light over the screw heads.

TROUBLE SHOOTING

If light does not turn on, remove battery,
wipe both ends with a clean, dry cloth
and reinstall battery. Check the battery
to ensure that it is making secure
contact with the terminals.
If this does not work, replace with a
new battery.
WARNING:
Do not dispose of lithium batteries in municipal waste stream or by re as batteries may explode. Do not open, short circuit, or destroy
batteries. Dispose of batteries in accordance with Local, State, and Federal regulations. Do not mix old and new batteries. Do not mix alkaline,
standard (carbon-zinc), or rechargeable (nickel cadmium, nickel metal hydride or lithium ion) batteries .
©
Wal-Mart Stores, Inc.
Hyper Tough is a registered trademark of
Wal-Mart Stores, Inc. All Rights Reserved.
Distributed by/Distribuido por
Wal-Mart Stores, Inc.,
Bentonville, AR
MADE IN COUNTRY/HECHO EN COUNTRY
TM
Electric drill
drill bit size:
ø7.5mm (3/10 in.)
B) so they are ush with the surface.
Part
A) by placing the keyholes
Slide the power switch to the "OFF" position. Use a
Phillips head screwdriver to remove 7 screws
from the light. Set 7 screws to the side. Remove
old battery and replace with a new 3.7V, 2000 mAh lithium
(18650) rechargeable battery. Replace the battery
cover by aligning it properly and replacing it with
7 screws removed earlier. Slide the power
switch to the "ON" position.
For optimum performance, allow light xture to charge
in full sunlight for 8-12 hours.
For assistance with assembly or instruction, parts and customer service, call: U.S.A. & Canada only: 1-844-551-0680
8am – 5pm Monday – Friday, Central Standard Time Or email: Customerservice@qx-usa.com
INSTRUCTIONS

INSTALLATION

Hardware Included

(A)
Screw X 2

Parts

A
B

REPLACING THE BATTERY

LINKABLE SOLAR LED FENCE LIGHT
ITEM: Q01DA0429-08
(B)
Wall Anchor X 2
(C)
Light Fixture X 1
4.7in.
x
x
C
Screws
Power Switch
Battery
A
Battery Cover
10/22/2019
E
