Summary of Contents for intensity IMCH-036KC-3
- Page 1 MINI CHILLER Tons. IMCH-036KC-3 / IMCH-060KC-3 INSTALLATION & OWNER´S MANUAL intensity.mx MAN-IO-IMCH-0615...
- Page 2 Never inspect or service the unit by yourself. CONTENTS PAGE Ask a qualified service person to perform this work. Do not dispose this product as unsorted municipal waste.Collection of such waste separately for special treatment is necessary. Keep far away from high-frequency equipment. Keep away from the following places: a place where it is full of oil gas;...
- Page 3 After a long use, check the unit stand and fitting for 2. ATTACHED FITTINGS damage. If damaged, the unit may fall and result in injury. To avoid oxygen deficiency, ventilate the room sufficiently if equipment with burner is used together with the air conditioner.
- Page 4 Cooling Heating Compressor Differential Pressure Switch 17 Thermistor For Water Outlet 4-Way Valve 10 High Pressure Switch 18 Thermistor For Water Inlet Accumulatior 19 Automatic Discharge Valve 11 Low Pressure Switch Air Side Heat Exchanger 12 Discharge Gas thermistor 20 Expansion Tank Electronic Expansion Valve 13 thermistor For Outdoor Temperature 21 Circulating Pump...
- Page 5 5.3 Moving and installation 5.2 Installation space (Unit:mm) Since the gravity center of the unit is not at its physical center, so please be careful when lifting it with a sling. Never hold the inlet of the outdoor unit to prevent it from deforming.
- Page 6 6. WATER PIPE INSTALLATION The choice and installation of components is the responsibility of the (see drain valves). The connection piping should be supported in installer who should follow good working practice and current such a way as to avoid it weighing on the unit.It is recommended legislation.
- Page 7 6.5 Minimum and Maximum water flow rates A (mm) Table 6-1 B (mm) C (mm) Water flow rate(m Item D (mm) Model Minimum Maximum E (mm) F (mm) IMCH-036KC-3 1.54 1.89 Water inlet/outlet (Ø) R5/4 IMCH-060KC-3 2.63 3.22 Auto-water replenishing (Ø) G1/2 Security discharge (Ø) G1/2 6.6 Water quality control...
- Page 8 i. All low positions of the water system should be provided with 6.10 Basic requirements of connection of chilled drainage ports, to drain water in the evaporator and the system water pipes completely; and all high positions should be supplied with discharge valves, to facilitate expelling air from the pipeline.
- Page 9 Thermal head min.- max. Water circuit pressure (bars) Max.storage temperature 7.1 Ethylene glycol solutions Water and ethylene glycol solutions used as a thermal vector in the place of water reduce the performance vector in the place of water reduce the performance values given in the following table. Freezing point (°C) Percentage of ethylene glycol in weight 0.98...
-
Page 10: Frequency
Do not use water pipes to earth the unit. upstream with a suitable device to protect against short-circuits and leakage to earth, isolating the installation from other equipment. 9.1 The Specification of Power Table 9-1 MODEL IMCH-036KC-3 IMCH-060KC-3 PHASE 1-PHASE 1-PHASE POWER FREQUENCY AND VOLT... - Page 11 9.2.3 Electrical power connections 9.2 Electrical connections 9.2.1 To complete the electrical connections Remove the inspection panel by unscrewing the five screws. Residual Current Circuit-breaker AC 208/230V 60Hz NOTE: The outdoor units must be installed with an Residual Current Circuit-breaker near the power supply and must be effectively earthed.
- Page 12 Remote cooling/heating SWITCH 2 If switch2 is closed, the unit will shift to heating mode forcibly; If switch2 breaks the unit will shift to cooling mode forcibly. NOTE Remote shutdown and Remote cooling/heating is optional function. Factory default has no remote cooling/heating. When the remote control and wire controller used at the same time, the unit will carry out the last command of arbitrary terminal.
- Page 13 Icon Description Outside heat source running icon(Reserved) Cooling mode icon This icon will be constantly light when customers choose cooling mode. Heating mode icon This icon will be constantly light when customers choose heating mode. Water pump mode icon This icon will be constantly light when customers choose water pump mode. Force cooling icon This icon will be constantly light when customers choose force cooling mode.
- Page 14 10.2.2 Control panel operation description 2 Timing off setting Long press “ ” for 3s in the main interface to enter 1. ON/OFF function interface. Press “ ” circularly to enter timing off The first time to powered on the unit, function.
-
Page 15: Table Of Contents
Table.10-1 Query orders Content Remark Frequency Display operating frequency when the unit is in cooling mode and heating mode. Mode 0-Power off 1-water pump 2-cooling 3-heating 4-force cooling 5-force heating Wind speed level 0-Power off (1-7) Total capacity requirements Capacity before revised(Force cooling displays 5) Capacity requirements after revised Capacity after revised (Force cooling displays 5) Temp. -
Page 16: Model
The water circuit MUST BE EMPTIED AND SHUT OFF POWER (when draining after heat pump operation take care as the water may be hot) or antifreeze must be added in the proportion recommended by the manufacturer. 11. MAIN PARAMETERS Model IMCH-036KC-3 IMCH-060KC-3 17.0(3.8~18.0) Capacity (kW) 10.0(2.9~10.5) Cooling...
