Specification

Inputs and Outputs

• 6.35 mm / 1/4" TS dual-mono line outputs
• 6.35 mm / 1/4" TRS headphone output
• 3.5 mm / 1/8" TRS stereo audio input
• MIDI DIN In and Out
• 3.5 mm / 1/8" TS Analogue clock sync In and Out
• Class compliant MIDI over USB B connection
• 6.35 mm / 1/4" TRS expression pedal input
• 6.35 mm / 1/4" TS sustain pedal input

Enclosure and Display

• Road-ready steel and aluminium enclosure with economical stained bamboo end cheeks
• 1.54-inch large OLED display for instant visual feedback at all times of playing/editing

Power

• Power: DC-9.0V – 1.5A centre-positive

Editor Software

• Free MODALapp software editor available for macOS, Windows, iOS and Android
• MODALapp can also be run within your Digital Audio Workstation (DAW), with VST3 and
AU versions available
Dimensions (L x W x H)
• 555 x 300 x 100 mm / 21.9" x 11.8" x 4"
Weight
• 5.6 kg / 12.4 lbs
