Summary of Contents for ADDAC System ADDAC604
- Page 2 ADDAC604 Assembly Guide September.2020 ADDAC SYSTEM page 2...
- Page 3 ADDAC604 Assembly Guide STEP 1: Start by separating the pcbs and trim the excess material with cutting pliers like shown below. ADDAC SYSTEM page 3...
- Page 4 ADDAC604 Assembly Guide STEP 2: Next locate the 3 pin male and female pinheaders and use a pliers to remove the middle pin like shown below. STEP 3: Locate the remaining pinheaders and place them like shown below. Then proceed to solder all pins on both boards.
- Page 5 ADDAC604 Assembly Guide STEP 4: Next locate and solder the 2x5 power connector, notice the hole orientation marking on the pcb. STEP 5: Proceed by placing the spacer. ADDAC SYSTEM page 5...
- Page 6 ADDAC604 Assembly Guide STEP 6: Next locate all 6 plastic shaft trim pots and flatten out their legs with the help of some pliers, like shown below. ADDAC SYSTEM page 6...
- Page 7 ADDAC604 Assembly Guide STEP 7: Next place all parts in the pcb. All pots are B103 but notice that 2 of them have the MID STOP indent. Once all parts are in the pcb proceed to place the front panel, tighten the nuts and then solder all pads.
- Page 8 ADDAC604 Assembly Guide STEP 8: Next solder the jumper pinheader, start by trimming the pot pad with a cutter then solder the pinheader. finish by removing the black plastic and trim the excess pin length ADDAC SYSTEM page 8...
- Page 9 ADDAC604 Assembly Guide STEP 9: Place the bottom screw. ADDAC SYSTEM page 9...
- Page 10 ADDAC604 Assembly Guide Congratulations you’re all done! Happy patching! ADDAC SYSTEM page 10...
-
Page 11: Assembly Guide
For feedback, comments or problems please contact us at: addac@addacsystem.com ADDAC604 ASSEMBLY GUIDE Revision.01 September.2020...
