Grizzly T21546 Instructions

Specifications
locking Device ... Combination Dial w/Key assist
T21546:
overall Dimensions ...13
Weight ...................................................22 lbs.
T21547:
overall Dimensions .. 15"W x 12
Weight ..................................................32 lbs.
Combination
Key
Figure 1. Model t21546 shown.
If you need help with your new safe, call our Tech
Support at: (570) 546-9663.
TIP
To prevent the possibility of condensation
inside the safe that could damage the con-
tents, keep a desiccant inside the safe.
Copyright © DECEMBEr, 2009 By grizzly inDustrial, inC. rEvisED april, 2012 (st).
WARNINg: NO pORTION OF ThIS MANUAL MAy BE REpRODUCED IN ANy ShApE
OR FORM WIThOUT ThE WRITTEN AppROvAL OF gRIzzLy INDUSTRIAL, INC.
⁄ "W x 10 ⁄ "D x 10"h
7 1
8 2
⁄ "D x 11
1
4
Combination
Dial
#ts12425 printED in China
MODEL T21546/T21547
COMBINATION SAFE
grizzly cannot replace lost or stolen keys.
please contact your local locksmith if this
happens.
⁄ "h
7
8
To open and lock your safe:
1. rotate the combination dial two rotations past
the first combination number, then stop on it
the third rotation, as illustrated in Figure 2.
1
st
3 Rotation
rd
Figure 2. sequence of dial rotations.
2.
turn the dial counterclockwise past the sec-
ond combination number, then stop on it the
second rotation.
3. rotate the dial clockwise and stop on the
third combination number.
4.
orient the key so that the notch in the thumb
tab is facing up, then insert it into the key-
hole.
5. turn the key clockwise until it stops to with-
draw the locking bolts from the cabinet frame,
then open the door.
6.
When finished, close the door and turn the
key counterclockwise until it stops to engage
the locking bolts and lock the door. disengage
the locking tumblers and prevent unlocking
the door with the key.
INSTRUCTIONS
NOTICE
# 2 #
nd
2 Rotation
nd
3 #
rd
1 Rotation
st
