APW Wyott HL-12A Specifications

The Adjustube® II is a tube-type, self-leveling, drop-in dispenser
field adjustable to a variety of china weights and diameters. To
change china patterns, simply adjust the spring rate and position
the stainless steel guide rods in the proper head guide holes.
Knurled lock nuts hold the rods securely in place, and the rods
form the guides for the dispensing head. When full tube
diameter is required, the rods store in the flanges and form
bumpers to protect the china.
APW Wyott's Lowerators® dispensing mechanism uses springs
attached to a sliding support bar that rides both inside and
outside the tube.
This design feature prevents a stack of dishware from sticking in
the down position, and releasing unexpectedly.
Adjustable extension springs (both 2.5 oz. per inch and 4.0 oz.
per inch) come with each tube for weight adjustment up to 100
pounds. Two size ranges are available: 3-1/2" –9-1/8" diameter
china and 9-1/4" –11-7/8" diameter china. The Adjustube® II
will also accept oval plates as well as oval platters up to 12
inches. Units have vertical storage of 25 1/2".
The dispensing head is stainless steel with five sets of reinforced
guide holes for smooth, even operation. China is always held
securely and at a consistent and convenient dispensing height.
APW Wyott's Adjustube® II offers maximum flexibility and
convenience in countertop dispensing of plates, cups, bowls,
glasses or other round dinnerware.
APW Wyott's Dispensers are backed by a 1 year parts &
labor warranty, including On-Site Service calls within 50
miles of authorized service technicians.
Rev. 1/1/2003
