Professional Audio
ASG-8
USER MANUAL
CN
EN
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Godin ASG-8 and is the answer not in the manual?

Questions and answers

Summary of Contents for Godin Godin ASG-8

  • Page 1 Professional Audio ASG-8 USER MANUAL...

  • Page 2: Table Of Contents

    Introduction Features Thank you very much for your choice of loudspeaker product for your application! In order to feel assured that you have gained a good grasp of every feature provided by your new unit, owner’s manual should be read in its entirety.

  • Page 3: Using The Unit Safely

    USING THE UNIT SAFELY INSTRUCTIONS FOR THE PREVENTION OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS About WARNING and CAUTION Notices About the Symbols Used for instructions intended to alert the This symbol alerts the user to important user to the risk of death or severe injury WARNING instructions or warnings.
  • Page 4 USING THE UNIT SAFELY ALWAYS OBSERVE THE FOLLOWING WARNING CAUTION Try to prevent cords and cables from becoming Protect the unit from strong impact. (Do not drop it!) entangled. Also, all cords and cables should be placed so they are out of the reach of children. Never climb on top of, nor place heavy objects on the Do not force the unit’s power-supply cord to share an unit.
  • Page 5 USING THE UNIT SAFELY ALWAYS OBSERVE THE FOLLOWING IMPORTANT NOTES IMPORTANT NOTES  When moved from one location to another where the Power Supply: Use of Batteries temperature and /or humidity is very different, water droplets  Do not connect this unit to same electrical outlet that is being (condensation) may form inside the unit, you must allow it to used by an electrical appliance that is controlled by an inverter stand for several hours, until the condensation has completely...

  • Page 6: Panel Controls

    PANEL CONTROLS PANEL CONTROL LAYOUT...

  • Page 7: Panel Control Description

    PANEL CONTROL DESCRIPTION PANEL CONTROL DESCRIPTION PANEL CONTROL DESCRIPTION 1. Channel Input 13. Master Volume The 1/4” input accepts all types of passive or active acoustic pickups. Set the overall level of the Loudbox Artist with the Master Volume. Plug a balanced mic into the XLR input for vocal or instrument use. In general put the Master Volume as high as possible (2 o’clock to 5 o’clock) to achieve the cleanest sound.
  • Page 8 19. Foot Switch Plug a Fishman dua foot switch into this jack for remote access to Channel Mute and Effect BMute. 20. Phones Out When you plug in stereo headphones here, the speakers shut off. This output monitors Channels 1 & 2 and the Aux input, so you can play along with pre-recorded music through the headphones.

  • Page 9: Specifications

    Specifications ASG-8 Item No Type 2-way active portable speaker Power 150W RMS Impedance 4Ω Frequency Range 60-20k Hz (-10dB ) 121dB MAX SPL@1m COMBO * 2（MIC） 1/4 inch TS *2（GUITAR） Inputs 1/8 inch AUX/Bluetooth4.0 stereo * 1 Foot Switch* 1 Output phones out* 1 MIX D.I.
  • Page 10 FCC STATEMENT Changes or modifications not expressly approved by the party responsible for compliance could void the user's authority to operate the equipment. NOTE: This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to Part 15 of the FCC Rules.
