Summary of Contents for Eurotops FR-8806
- Page 1 English SC889/ FR-8806 NON-CONTACT INFRARED BODY THERMOMETER User manual PLEASE READ THE MANUAL BEFORE YOUR FIRST USE. KEEP THIS MANUAL SAFE FOR FUTURE REFERENCE!
- Page 2 Advice for first use For stable and reliable results, it is essential to check the Non-contact Body IR thermometer and adjust as needed with the following steps: 1st step : Take the temperature of a person using a conventional thermometer and get the test result, 37.5°C (99.5°F) for example.
- Page 3 ➢ When problems occur with the device, please contact the retailer, don't repair it by yourself. Importance ➢ Make sure move away the hair, perspiration etc. on the forehead before measuring. ➢ This device must only be used in an ambient temperature between 16°C (60.8 °F) and 35°C (95.0°F), the best ambient temperature is 25°C(77°F), do no use it in extreme conditions of >35°C(95.0°F) or <16°C(60.8*F).
- Page 4 Usages of the thermometer ➢ Body temperature : Measure the body temperature for monitoring person's fever, women's ovulatory period and so on. ➢ Skin temperature : Measure the temperature of people surface skin. ➢ Object temperature : Measure object surface temperature, such as tea cup, cake, food etc. ➢...
- Page 5 Configuration 1. IR Sensor 2. LCD Display 3. MODE Button 4. Down Button 5. Up Button 6. Set Button 7. ON/ Scan Button 8. Battery Cover LCD Indicator Surface Mode Body Mode Ambient Temperature Mode Digital Readout Smile or Cry Indicator Battery Indicator Buzzer on/ off Indicator Memories...
- Page 6 10-2. Measuring operation Aim towards the forehead (see the diagram below for the positioning), from a distance of 1-3cm (0.4- 1.2 in), press the measuring trigger, the temperature is displayed Immediately. Making sure there is no hair, perspiration, cosmetic or cap covered on the forehead. If it can't measure the forehead temperature due to perspiration or other factors, please take the temperature behind the ear lobe, make sure there is no hair, perspiration, cosmetic or cap covered.
- Page 7 NOTE: Body mode is for body temperature, and the Surface mode is for object surface temperature, please make sure use the Body mode when taking body temperature. 10-3-3. SET button: Adjust the settings of the device, (Please turn to the instructions of the SET button in details as followings) 10-3-4.
- Page 8 Surface mode. 12-2. LCD display "LO": The device tells you that the aim object temperature is out of the measuring range, either below 35*C(95.0°F) in Body mode or below 0°C(32°F). 14-3. Reasons for “HI" and "LO", and suggestions to solve: Possible reasons Maintenance Suggestions Testing results affected by hair,...
- Page 9 This symbol indicates that electrical and electronic devices are collected selectively. The symbol shows a waste container crossed out with an X symbol. Imported by EML – trading name Prodis, 1 rue de Rome 93110 Rosny-sous-Bois-France/ Made in PRC Marketed by EUROTOPS VERSAND GMBH D-40764 LANGENFELD, Germany...
