Summary of Contents for NexPower NH-100AX-1 Series
- Page 1 PLEASE READ THIS MANUAL CAREFULLY BEFORE INSTALLING OR USING THE MODULES INSTALLATION MANUAL Thin-Film Photovoltaic Module NH-100AX-1 series (NH-100AX-1_5A/ NH-100AX-1_4A/ NH-100AX-1_3A) NexPower Technology Corp. Ver. EU-E...
-
Page 2: Table Of Contents
Table of Contents 1. INTRODUCTION ................1 2. WARNING AND SAFETY..............1 3. LIMITATIONS ON USING NH-100AX-1 SERIES PV MODULE ..2 4. SITE SELECTION AND TILT ANGLE..........4 5. INSTALLATION .................. 4 5-1 Limitation of Installation................4 5-2 Mounting Method ..................5 5-3 Mounting Structure.................. -
Page 3: Introduction
Do NOT artificially concentrate sunlight onto the PV module. Do NOT connect the NH-100AX-1 series PV module with any other type of PV module. Do NOT cut the cable attached on PV module then connect to another type of cable or connector. -
Page 4: Limitations On Using Nh-100Ax-1 Series Pv Module
3. LIMITATIONS ON USING NH-100AX-1 SERIES PV MODULE Please read these limitations carefully before installing or using the modules. To stay within the warranty conditions of the NexPower NH-100AX-1 series PV modules, it is essential to install the PV module with the following guidelines. - Page 5 Inverters with galvanic isolation (transformer type) and grounded negative pole of the solar generator strings; or, Specifically-designed transformer-less inverters (e.g. Sunways AT series). Please refer to Chapter 4 ~ Chapter 7 for more detailed information. NH-100AX-1 series Ver. EU-E...
-
Page 6: Site Selection And Tilt Angle
The PV module must be sited where no shading occurs between the hours of 10 AM and 2 PM. iii) If the PV module is mounted horizontally, tilting angle must be more than 40 degrees, and front row of PV array must not shade PV module. NH-100AX-1 series Ver. EU-E... -
Page 7: Mounting Method
Do not damage the rear surface of PV modules while fastening PV modules by bolts. Bolt Washer Frame Structure member Spring Washer Washer Fig.2 Mounting method – bolt B - Clamps & Fixing Plates The PV module can be mounted by using clamps and fixing plates (Fig. 3, 4). NH-100AX-1 series Ver. EU-E... -
Page 8: Mounting Structure
(no breaks in the rack). When selecting the material for the assembly system, pay attention to the electrochemical series (avoidance of contact corrosion between different materials). Mounting position is depended on installation method: NH-100AX-1 series Ver. EU-E... - Page 9 To keep the warranty validated on NexPower NH-100AX-1 series PV modules, it is essential to install the PV module according to the following guidelines. i) The clamp position (C) is from the end of the module to the centerline of the clamp or fixing plate.
-
Page 10: Wiring
It is recommended to multiply the Voc listed on the module label by a factor of 1.25, and make sure the system voltage must not exceed a maximum of 600V. Otherwise it will void the warranty. 6-2 Parallel Wiring Fuse Fig.8 Parallel connections NH-100AX-1 series Ver. EU-E... -
Page 11: Inverter Selection
6-3 Inverter Selection To stay within the warranty conditions of the NexPower NH-100AX-1 series PV modules, it is essential to select inverters with the following features. Inverters with galvanic isolation (transformer type) and grounded negative pole of the solar generator strings;... - Page 12 Grounding Grounding method - B Fig.10 Ground method of the PV array The negative pole of solar generator strings connected to the inverter must also be grounded (Fig. 11). Otherwise it will void the warranty. NH-100AX-1 series Ver. EU-E...
-
Page 13: Maintenance
PV module. No responsibility is assumed by NEXPOWER for any infringement of patents or other rights of third parties which may result from use of the module. -
Page 14: Appendix 1 - Mechanical Specifications
9. APPENDIX 1 - Mechanical Specifications Items Specification Length [mm] 1414 Width [mm) 1114 Thickness [mm] 35.3 Weight [kg] 20.5 (Front View) (Back View) A-A Section B-B Section (Cross-section View) NH-100AX-1 series Ver. EU-E... -
Page 15: Appendix 2 - Electrical Specifications
NEXPOWER Technology Corporation. Except to the extent expressly permitted by applicable law, no contents in this manual may be used, copied, modified, translated, distributed or otherwise utilized without the prior written consent of NEXPOWER Technology Corporation.
