- Page 1 BOXER PASTURE TOPPER WB ● BL ● BLG USER MANUAL P. de Heus en Zonen Greup B.V. Stougjesdijk 153 3271 KB Mijnsheerenland The Netherlands Tel: +31 (0) 18 66 12 333 E-mail: info@boxeragri.nl...
- Page 2 ENG | ENGLISH TRANSLATION OF THE ORIGINAL MANUAL BOXER PASTURE TOPPER | User manual September 2019...
-
Page 3: Table Of Contents
CONTENTS USING THE PASTURE TOPPER BOXER FM100, BL120, WB500 AND WB600 ........4 SAFETY INSTRUCTIONS ....................... 5 PUTTING INTO OPERATION/OPERATING INSTRUCTIONS ............7 WORKING METHOD AND USE OF THE BOXER PASTURE TOPPER ..........8 STORAGE, MOVING AND DEPLOYABILITY ................... 9 MAINTENANCE, REPAIRS ...................... -
Page 4: Using The Pasture Topper Boxer Fm100, Bl120, Wb500 And Wb600
The working width is determined by the BOXER PASTURE TOPPER type. • The BOXER PASTURE TOPPER can be used for all types of grass fields, etc. without stones, etc., that may injure people and that may cause machine damage. The BOXER PASTURE TOPPER requires the following power:... -
Page 5: Safety Instructions
The following safety instructions and the instructions given in the BOXER manual must be observed: • The capacity and the stability of the machine to which the BOXER PASTURE TOPPER will be connected must be adjusted to the BOXER PASTURE TOPPER on the basis of 540 rpm (PTO). - Page 6 • Never leave the tractor if the cutting blades are still rotating!!! • Only work if the mowing machine can be seen (if required, turn on the tractor’s rear lights). Page 6/14 BOXER PASTURE TOPPER | User manual September 2019...
-
Page 7: Putting Into Operation/Operating Instructions
Check that all bolted connections have been sufficiently tightened every week. • After the points above have been checked, the BOXER PASTURE TOPPER can be connected to the machine mechanically. When connecting mechanically, the machine must be maneuvered slowly to the attachment system. -
Page 8: Working Method And Use Of The Boxer Pasture Topper
• No people may stand between the tractor and the vehicle. • After every working day, the BOXER PASTURE TOPPER must be cleaned carefully so that no grass and/or sand residue remains stuck to the system anywhere and hardens. •... -
Page 9: Storage, Moving And Deployability
STORAGE, MOVING AND DEPLOYABILITY When storing the BOXER PASTURE TOPPER, make sure that the blades are free of any obstacle. Do not stand on the machine when moving it. The power take-off must be fastened securely to the frame to prevent the possibility of a hand getting caught. -
Page 10: Maintenance, Repairs
When replacing the blades, make sure that the same blade lengths are installed to prevent imbalance!!! • After every working day, the BOXER PASTURE TOPPER must be cleaned carefully so that no grass and/or sand residue remains stuck to the system anywhere and hardens. -
Page 11: Disposal And The Environment
DISPOSAL AND THE ENVIRONMENT If the BOXER PASTURE TOPPER is no longer suitable for further use, the wheel must be removed and the universal joint oil must be drained. Each of the sorted materials must be offered separately to the relevant authorities/companies. -
Page 12: Figures
FIGURES Page 12/14 BOXER PASTURE TOPPER | User manual September 2019... -
Page 13: Technical File
TECHNICAL FILE The technical file, detailed drawings, structural calculations and original CE declaration of conformity are available for inspection at the office of the supplier/manufacturer. Page 13/14 BOXER PASTURE TOPPER | User manual September 2019... -
Page 14: 10. Ce Declaration Of Conformity
Directive de la 2006/42/CE et consultées pour vérification UNI:EN 13524:2004, EN 754. UNI:EN 1553:2001 Mijnsheernland , 19/08/2019 De gevolmachtigde: Der Bevollmächtigte: The legal representative : Le représentant légal: Page 14/14 BOXER PASTURE TOPPER | User manual September 2019...
