Summary of Contents for Roger ME-12
- Page 1 Roger Access Control System ME-12 mounting bracket User Manual Product version: 1.0 Document version: Rev. A...
- Page 2 2. I NSTALLATION ME-12 bracket consists of front panel for MD70 attachment and base for wall mounting. Prior to installation the bracket must be disassembled. The inclination of front panel (30, 45 or 60º) is adjusted by selection of holes dedicated to front panel and base assembly (fig. 2).
- Page 3 ME-12 User manual.doc 2017-10-11 Mounting bolts Fig. 2 Arrangement of front panel and base assembly holes Mounting hole Mounting hole Mounting hole Mounting hole Fig. 3 Arrangement of MD70 mounting holes...
- Page 4 ME-12 User manual.doc 2017-10-11 Fig. 4 Arrangement of connection cable 3. O RDERING INFORMATION Product Description ME-12 MD70 mounting bracket MD70 Graphic touch panel with Mifare Classic/Desfire/ NFC reader 4. P RODUCT HISTORY Product version Released Description ME-12 v1.0 06/2017...
- Page 5 Weight of the equipment is specified in the document. Contact: Roger sp. z o.o. sp.k. 82-400 Sztum Gościszewo 59 Tel.: +48 55 272 0132 Fax: +48 55 272 0133 Tech.
