ORiNOCO 11b USB Client
Wireless Networks
User Guide

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ORiNOCO B11FNF-USB and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Proxim ORiNOCO B11FNF-USB

Summary of Contents for Proxim ORiNOCO B11FNF-USB

  • Page 1 ORiNOCO 11b USB Client Wireless Networks User Guide...
  • Page 2 ORiNOCO 11b USB Wireless Networks User Guide Copyright  2003 Proxim Corporation, Sunnyvale, CA. All rights reserved. Covered by one or more of the following U.S. patents: 5,231,634; 5,875,179; 6,006,090; 5,809,060; 6,075,812; 5,077,753. This user guide and the software described in it are copyrighted with all rights reserved. No part of this publication may be reproduced, transmitted, transcribed, stored in a retrieval system, or translated into any language in any form by any means without the written permission of Proxim Corporation.

  • Page 3: Table Of Contents

    NFRASTRUCTURE ......................10 OAMING CHAPTER 3 INSTALLATION ................12 ..................12 YSTEM EQUIREMENTS ..................12 NSTALLATION ROCEDURE NOCO 802.11 USB C ..........17 LIENT NSTALLATION CHAPTER 4 PROXIM CLIENT UTILITY ............20 ..................20 ROXIM LIENT TILITY ....................21 TATUS ..................22 ONFIGURATION .......................23 URVEY ..................23 ETWORK NFORMATION ONFIGURING...
  • Page 4 ORiNOCO 11b USB Wireless Networks User Guide APPENDIX A GLOSSARY ................35 APPENDIX B SPECIFICATIONS AND SUPPORT ..........36 .........................36 ADIO ................36 NVIRONMENTAL AND HYSICAL .............37 ECHNICAL UPPORT ONTACT NFORMATION APPENDIX C REGULATORY INFORMATION ..........38 U.S. FCC S ..................38 TATEMENTS IC S ..................39 ANADA TATEMENTS...

  • Page 5: Chapter 1 Introduction

    ORiNOCO 11b USB Wireless Networks User Guide Chapter 1 Introduction The ORiNOCO 11b USB Client provides high-speed (11 Mbps) wireless Internet access and networking for a USB-enabled desktop anywhere, anytime. The USB Client is a Plug-and-Play device that connects to and draws power from a computer’s USB port. When installing the USB Client, you do not need to open the desktop, worry about device conflicts, or search for a vacant ISA or PCI slot.

  • Page 6: Applications

    ORiNOCO 11b USB Wireless Networks User Guide Systems (NOS) including Windows 98/2000/ ME/XP. Supports an easy Plug-and-Play installation. Includes integrated dual diversity antennas that provide a wide coverage area. Provides greater flexibility to locate or move networked PCs. Includes an LED indicator that reports on current wireless activity. Applications This Wireless USB Adapter offers a fast, reliable, cost-effective solution for wireless client access to the network.

  • Page 7: Product Package

    ORiNOCO 11b USB Wireless Networks User Guide Product Package The Wireless USB Adapter includes the following items. If any of the items are missing or damaged, please contact your local reseller. One Gold or Silver ORiNOCO 802.11b USB Adapter One USB Cable One ORiNOCO Installation CD-ROM containing installation software, a management utility and this user manual in Portable Document Format (PDF) for Windows 98/2000/ME/XP.
  • Page 8 ORiNOCO 11b USB Wireless Networks User Guide 1.4.2 Interoperability and Security The Wi-Fi standard certified at 2.4 GHz ensures the wireless interoperability with other Wi-Fi (802.11b) certified devices. The ORiNOCO 11b USB Client supports the following security standards (features vary based on model): Cisco Client Extension compatibility (including LEAP) Wired Equivalent Privacy (WEP) encryption using 64 bit or 128 bit encryption...

  • Page 9: Chapter 2 Network Planning

    ORiNOCO 11b USB Wireless Networks User Guide Chapter 2 Network Planning ORiNOCO wireless products look and operate similar to Ethernet products. The only difference is that a radio replaces the wire between communicating devices. This means that all of your existing applications that operate over Ethernet will work with the ORiNOCO 11b USB Client without any special wireless networking software.

  • Page 10: Access Point Infrastructure

    ORiNOCO 11b USB Wireless Networks User Guide Figure 2-1 Peer-to-Peer Group The ORiNOCO 11b USB Client can communicate with Peer-to-Peer Groups that support the 802.11b wireless standard. Access Point Infrastructure Many companies have an existing Ethernet or wired LAN infrastructure and want to be able to extend that capability to wireless nodes.

  • Page 11: Roaming

    ORiNOCO 11b USB Wireless Networks User Guide Desktop PC Desktop PC Server Workstation Ethernet Desktop PC with Access Point Wireless device Desktop PC with Access Point Wireless device Laptop with Wireless device Laptop with Desktop PC with Desktop PC with Wireless device Wireless device Wireless device...
  • Page 12 ORiNOCO 11b USB Wireless Networks User Guide Server Desktop PC Desktop PC Desktop PC Ethernet Access Point Access Point Desktop PC with Desktop PC with Wireless device Wireless device BSS2 BSS1 Laptop with Laptop with Wireless device Wireless device Figure 2-3 Roaming in an Extended Service Set (ESS) 2.3.2 Guidelines for Roaming All 802.11b Access Points that a client will roam between must have the same...

  • Page 13: Chapter 3 Installation

    C:\WINDOWS\OPTIONS\INSTALL\ or C:\WINDOWS\OPTIONS\CABuS\. Windows 98/ME users may need the Windows CD or Cabinet files to complete the installation of the USB Client. Proxim recommends that you do not proceed with the installation until you have confirmed that you have one of these Windows installation media available.
  • Page 14 ORiNOCO 11b USB Wireless Networks User Guide 3.2.2 Installation Instructions Follow these steps to install an ORiNOCO 11b USB Client in a Window 98 SE, Windows ME, Windows 2000, or Windows XP computer. Turn on the computer and logon to Windows, if applicable. Insert the ORiNOCO Installation CD into the computer’s CD-ROM drive.
  • Page 15 ORiNOCO 11b USB Wireless Networks User Guide Figure 3-3 License Agreement for ORiNOCO 11b USB Client Installation Choose a destination location for the ORiNOCO 11b USB Client installation files. You may use the default path or click Browse to specify a different location. After you are done, click the Next button.
  • Page 16 ORiNOCO 11b USB Wireless Networks User Guide Be patient while the software is installed on your computer. Figure 3-5 Software Setup in Process Click Finish to close the Software Setup Wizard when prompted. Figure 3-6 Installation Completed Connect the ORiNOCO 11b USB Client to the computer’s USB port. Find an available USB Series "A"...
  • Page 17 ORiNOCO 11b USB Wireless Networks User Guide Connect the cable’s “A” plug into your computer’s USB Series "A" port. Figure 3-7 Connect ORiNOCO 11b USB Client to Computer 10. Follow any on-screen instructions to complete the installation. 11. The ORiNOCO 802.11b USB should now be successfully connected. Figure 3-8 ORiNOCO 802.11b USB Connected ♦...

  • Page 18: Orinoco 802.11B Usb Client Un-Installation

    ♦ If you do not have an Access Point, use the Proxim Client Utility to set the card to Peer-to-Peer Ad Hoc mode. To open the utility, click the icon in the Windows Taskbar. If you check the “Auto Run”...
  • Page 19 ORiNOCO 11b USB Wireless Networks User Guide Select Remove and then click the Next button to perform the un-installation. When prompted, click OK to remove the Proxim Wireless LAN. Figure 3-10 Uninstall ORiNOCO 11b USB Client Be patient while the card is uninstalled from your computer.
  • Page 20 ORiNOCO 11b USB Wireless Networks User Guide Figure 3-12 Un-installation and Maintenance Completed Chapter 3 Installation...

  • Page 21: Chapter 4 Proxim Client Utility

    ORiNOCO 802.11b USB Client using Windows XP Zero Configuration. Proxim Client Utility The Proxim Client Utility (PCU) icon will appear in the Windows Taskbar (also known as the System Tray) each time your computer is restarted. Click the PCU icon to launch the utility.

  • Page 22: Card Status Tab

    After installation is completed, click the PCU and you will see the screen below. Card Status Tab Figure 4-3 Proxim Client Utility Shows Card Status This screen displays information about the USB Client’s wireless connection, including the client’s Firmware Version, MAC Address, Frequency Domain and ESSID.

  • Page 23: Card Configuration

    The USB Client and its AP must use the same WEP key to communicate with each other. KEY Format: You can enter WEP Keys as ASCII Characters (0~9, a~z, A~Z) or Hexadecimal numbers (0~9, A~F, a~f). Chapter 4 Proxim Client Utility...

  • Page 24: Site Survey

    The green light on the right bottom of the screen means the radio is on. Click the Disable Radio button to turn off the radio when necessary. The light will turn to red in off mode. Click Hide to shrink the screen to tray icon. Chapter 4 Proxim Client Utility...
  • Page 25 ORiNOCO 11b USB Wireless Networks User Guide Figure 4-6 About Mode Shows Network Information 4.5.2 Radio Disabled The ORiNOCO 802.11b USB Client is on disabled mode. Click Enable Radio to turn on the radio. Figure 4-7 Radio on Disable Mode Chapter 4 Proxim Client Utility...

  • Page 26: Configuring Your Wireless Networking Settings With Windows Xp Wireless Utility

    Start > Settings > Network Connection to configure the ORiNOCO 802.11b USB Client. Select the wireless network connection that corresponds to the USB Client and you will see a screen that displays information about the wireless connection status and signal level, as shown in Figure 4-9. Chapter 4 Proxim Client Utility...
  • Page 27 Click the Properties button to view the configuration screen. The General tab displays basic information about the client’s network settings. You can install additional networking protocols from this screen, if necessary. Figure 4-10 WLAN Adapter Information and Networking Protocol Chapter 4 Proxim Client Utility...
  • Page 28 Under Preferred networks, you can connect to an access point (infrastructure) network that you know is available but is not listed under the Available networks by clicking the Add button. In Wireless Network Properties, specify the network name (Service Set Identifier). Chapter 4 Proxim Client Utility...
  • Page 29 WEP settings as the AP to allow successful communication. If your wireless networks do not have any AP, place a check mark in the This is computer-to-computer (ad-hoc) network; wireless access points are not used box. Chapter 4 Proxim Client Utility...
  • Page 30 Protocol (EAP), secure, encrypted and wireless access on a Microsoft network becomes easy and feasible. Figure 4-14 Authentication Screen Advanced The Advanced window offers Firewall and Internet Connection Sharing functions. You can select the functions below according to the specific networking environment. Chapter 4 Proxim Client Utility...
  • Page 31 Network adapter. To access configuration information for your adapter, follow the on-screen instructions. For the network adapter to function in a wireless LAN, you may need change the settings per the requirement of the network environment. Chapter 4 Proxim Client Utility...

  • Page 32: Chapter 5 Troubleshooting

    ORiNOCO 11b USB Wireless Networks User Guide Chapter 5 Troubleshooting The ORiNOCO 802.11b USB Client is designed to be very easy to install and operate. However, if you experience any difficulties, use the information in this chapter to help diagnose and solve the problem.

  • Page 33: How To Obtain Help With Your Lan Installation

    How to Obtain Help with Your LAN Installation If you require assistance to install your Local Area Network (LAN), Proxim can put you in touch with a reseller in your area. The reseller is an expert in the design, installation, and...

  • Page 34: Range

    (like a filing cabinet) between the antennas of two 802.11b devices. • Use the Proxim Client Utility to evaluate the signal strength and link quality between 802.11b devices. Refer to the documentation that came with your Access Points for suggestions on how to locate the AP and its antennas to maximize range and performance.

  • Page 35: Led Indicators

    ORiNOCO 11b USB Wireless Networks User Guide LED Indicators The ORiNOCO 802.11b USB Client includes one oval, green LED indicator on the upper part of front face of the device. The LED displays the following behavior: LED is off when the adapter is not receiving power or when the ORiNOCO driver is not installed.

  • Page 36: Appendix A Glossary

    ORiNOCO 11b USB Wireless Networks User Guide Appendix A Glossary Access Point - An internetworking device that seamlessly connects wired and wireless networks together. Ad-Hoc - Ad-Hoc is a peer- to-peer wireless network without Access Point. A group of wireless clients consistent an independent wireless LAN.

  • Page 37: Appendix B Specifications And Support

    ORiNOCO 11b USB Wireless Networks User Guide Appendix B Specifications and Support Radio Frequency Band: 2400 ~ 2483.5MHz (for US, Canada, and ETSI) 2400 ~ 2497MHz (for Japan) Actual frequencies in use vary by country Modulation TYPE: CCK, BPSK, QPSK Operating Channels: 11 channels (US, Canada) 13 channels (ETSI) 14 channels (Japan)

  • Page 38: Technical Support Contact Information

    ORiNOCO 11b USB Wireless Networks User Guide Technical Support Contact Information If you are having a problem using an ORiNOCO 802.11b USB Client, gather the following information and contact ORiNOCO Technical Support: What kind of network are you using? What were you doing when the error occurred? What error message did you see? Can you reproduce the problem? What version of the ORiNOCO driver are you using?

  • Page 39: Appendix C Regulatory Information

    ORiNOCO 11b USB Wireless Networks User Guide Appendix C Regulatory Information U.S. FCC Statements Declaration of Conformity This device complies with Part 15 of the FCC Rules. These limits are designed to provide reasonable protection against harmful interference in a residential installation. Operation is subject to the following two conditions: (1) This device may not cause harmful interference and (2) This device must accept any interference received, including interference that may cause undesired operation.

  • Page 40: Canada Ic Statements

    ORiNOCO 11b USB Wireless Networks User Guide organization or environment (e.g. airports), you are encouraged to ask for authorization to use this device prior to turning on the equipment. Modifications The manufacturer is not responsible for any radio or television interference caused by unauthorized modification of the devices included with this kit, or the substitution or attachment of connecting cables and equipment other than specified by manufacturer.

  • Page 41: 日本の通達 (Japan Regulatory Statement)

    帯は 2.400〜2.483 MHz です。この周波数帯域は、次のような産業・科学・医療機器でも使 用されています。 電子レンジ次のいずれかを含む移動体識別用システム (RF-ID) 免許を要する構内無線局 免許を要しない工場製造ライン用特定小電力無線局 この装置を使用する前に、無線 LAN 装置を使用する場所の近くに、移動体識別用システム (RF-ID) がないことを確認してください。40 メートル以内に近づくと、干渉が起きる場合 があります。 移動体識別用システム (RF-ID) への RF 干渉が発生した場合は、無線信号の発信を停止する か、装置が使用する周波数チャネルを変更してください。免許を要する移動体識別用システ ム (RF-ID) の付近で RF 干渉が発生した場合は、ただちに無線信号の発信を停止してくださ い。 無線装置から移動体識別用システム (RF-ID) への干渉が発生するなどの問題が生じた場合 は、正規の代理店またはメーカーまでご連絡ください。 お問い合わせ先については、Web サイト http://www.proxim.com を参照してください。 Appendix C Regulatory Information...
  • Page 42 ORiNOCO 11b USB Wireless Networks User Guide Voluntary Council for Interference from Information Technology Equipment (VCCI) VCCI (ベースの端末装置および USB Client のみ) この製品は、情報技術装置からの干渉に関する情報処理装置等電波障害自主規制協議会 (VCCI) の標準に基づくクラス B 製品です。家庭内のラジオやテレビなどの近くで使用する と、無線干渉を生ずることがあります。この装置の設置と使用にあたっては、取扱指示マニ ュアルに従ってください。 Radio Approvals USB certification model: B11FNF-USB For reference, see product label Appendix C Regulatory Information...
