- Page 1 DRONE ROVER Drone treasure detecting system for larger areas User manual TREASUREHUNTER3D Makes underground treasures visible...
- Page 2 TREASUREHUNTER3D Instruction manual Makes underground treasures visible Table of contents...
-
Page 3: Table Of Contents
Drone location is not visible or wrong ��������������������������������������������������������������������������������������������������������������������������������������������� 21 DroneRover application crashes ������������������������������������������������������������������������������������������������������������������������������������������������������� 21 GPS location & video is not updated in real-time / lag ����������������������������������������������������������������������������������������������������������������� 21 Drone does not connect to Drone Rover app ��������������������������������������������������������������������������������������������������������������������������������� 21 Smartphone application features Main control screen ��������������������������������������������������������������������������������������������������������������������������������������������������������������������������������������� 23 Battery &... -
Page 4: Welcome
Here at TreasureHunter3D we are constantly focusing on innovating in order to provide high quality, affordable & easy to use products that incorporate high technology to our customers, by purchasing this device you are helping us to push metal detecting to the next level�... -
Page 5: Read Before Use - Important Notes
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Read before use - important notes Metal detector safety warnings Any piece of equipment can be dangerous if not operated properly� It is YOU who is responsible for the safe operation of this equipment�... -
Page 6: Assembly & Getting Started
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Assembly & getting started... -
Page 7: Learn How To Use Phantom 4
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Learn how to use Phantom 4 Here is a short checklist of things that you need Before starting to use a DroneRover sensor device you need to learn how to use Phantom 4 drones� We highly... -
Page 8: What Do You Need Before Starting
TREASUREHUNTER3D Instruction manual Makes underground treasures visible What do you need before starting? NOT INCLUDED: • DroneRover sensor unit • 4x AA alkaline batteries (not rechargeable) • DJI Phantom 4 Advanced • DroneRover receiver unit • iPhone 6 or newer model Assembly 1. - Page 9 TREASUREHUNTER3D Instruction manual Makes underground treasures visible 3. Drone remote control unit preparation: • make sure remote control unit is fully charged • attach the smartphone to the holder on top of remote control unit and connect it with the original USB cable •...
-
Page 10: Sensor Unit
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Sensor unit Sensor unit is used to detect targets and transfer target information to the receiver unit� It has to be mounted on a drone� Switch GREEN ORANGE on/off device sensor status switch... -
Page 11: Receiver Unit
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Receiver unit Receiver unit receives data from the sensor unit and forwards it to the smartphone� It is recommended to place the receiver not more than 2m away from the smartphone� Switch on/off switch... -
Page 12: Turn It On
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Turn it on 1. Move the slider switch on the Sensor unit to ON position in order to turn it on� Green LED will indicate the sensor is turned ON� Orange LED will indicate that the sensor is ready to be used�... -
Page 13: Quick Start
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Quick start Before start 1. To learn how to properly and safely use the DroneRover app, first find an area that is not populated, is flat and has no obstacles, so it is safe to fly. A perfect test scan area can be a meadow or field, away from houses &... -
Page 14: Automated Scanning
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Automated scanning 1. Open settings menu and select Flight setting. SET: • Scan mode: AUTO • Scan resolution: LOW • Altitude hold: CONSTANT • Altitude: 10m 2. Press “Apply” to exit setting menu. - Page 15 TREASUREHUNTER3D Instruction manual Makes underground treasures visible 5. Make sure to keep distance from the drone and you are not located in the drone’s way to scan the area. 6. Press “Scan mission” button and confirm take off, the drone will now fly to scan the area and start scanning.
-
Page 16: Manual Scanning
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Manual scanning 1. Open settings menu and select Flight setting. SET: • Scan mode: MANUAL • Scan resolution: LOW 2. Press “Apply” to exit setting menu. 3. Press “Scan new area” button. 4. Drag rectangle over an area on the map you would like to scan. - Page 17 TREASUREHUNTER3D Instruction manual Makes underground treasures visible 5. Make sure to keep distance from the drone and you are not located in the drone’s way to scan the area. 6. Press the “Scan mission” button, app will now check GPS signal, battery and other drone status indicators to confirm everything is ok and ready for safe flight.
-
Page 18: Sensor Reading / Scan Interpretation
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Sensor reading / scan interpretation When a drone flys over a selected area, scan results are updated in real-time using different colours to indicate target probability� GRAY COLOUR indicates that sensor reading was incorrect due to unstable drone flight caused by wind or other disturbance. -
Page 19: Sensor Settings & Calibration
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Sensor settings & calibration Sensor settings enable users to set sensor sensitivity, stability limit and perform sensor calibration� SENSOR SENSITIVITY Sensor sensitivity defines how strong the signal from the sensor will be when objects or other underground anomalies are detected�... -
Page 20: Sensor Calibration
TREASUREHUNTER3D Instruction manual Makes underground treasures visible SENSOR CALIBRATION DroneRover has an integrated error correction system that requires calibration� In order to achieve best scanning results, the sensor needs to be calibrated after being mounted on the drone� Procedure to calibrate the sensor goes as follows�... -
Page 21: Troubleshoots
USB cable for connection with a remote controller downloads/djiapp/dji-go-4) and confirm the drone is is used� It is also recommended to have smartphone working properly before contacting TreasureHunter3D batteries full and close or other apps beside DroneRover� technical support�... -
Page 22: Smartphone Application Features
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Smartphone application features... -
Page 23: Main Control Screen
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Main control screen From the main control screen user can: • Observe map with smartphone and drone location • Select scan area • Enter settings menu to adjust sensitivity, scan resolution, flight mode & altitude •... -
Page 24: Automated Scanning Mode Mission Control
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Automated scanning mode mission control When automated scanning mode is selected in the Flight settings menu tab, the user has the ability to start automated area scanning� Starting mission Missions can be started or aborted with a button at the right bottom of the screen�... -
Page 25: Manual Scanning Mode Control
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Manual scanning mode control When manual scanning is enabled in the Flight settings menu tab, the user can scan the area manually using drone remote control� Starting mission The mission can be started with a button at the right bottom of the screen�... -
Page 26: Settings Menu
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Settings menu Settings menu provides two tabs, one for sensors and one for flight settings. Sensor settings tab SENSITIVITY Defines sensitivity of scanning sensor & algorithm. Best sensitivity is achieved when HIGH sensitivity is selected and the drone is flying close to the ground. -
Page 27: Exporting And Sharing Scan Data
TREASUREHUNTER3D Instruction manual Makes underground treasures visible ALTITUDE MODE Constant - means the drone will scan the area at constant altitude. Recommended for flat areas. Terrain - means drone will follow terrain while keeping constant distance from terrain. Recommended for not flat. -
Page 28: Technical Spec. & Warranty
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Technical spec. & warranty... -
Page 29: Technical Specification
TREASUREHUNTER3D Instruction manual Makes underground treasures visible Technical specification Operating temperature range: -10 to 50 °C Operating humidity: 0-90% Bluetooth connectivity: certified Bluetooth 4.0 low energy radio Sensor data link: certified long range low-power wide-area network technology Batteries: removable AA batteries... - Page 30 TREASUREHUNTER3D Instruction manual Makes underground treasures visible TREASUREHUNTER3D Makes underground treasures visible www.treasurehunter3d.com info@treasurehunter3d.com...
