AIS LDS410D Specifications

1U Console Drawer
1U Console LCD Drawer or Switch can save space, power and money. It only
takes 1U (1.75in), same height as the rack space. It is an ideal solution for
ASP, ISP, telecommunication companies, and testing rooms.
*All specifications are subject to change without notice.
What is KVM?
KVM is the acronym for keyboard, Video, Mouse. More specifically, multiple computers are
connected to the KVM and controlled from a single set of keyboard, monitor and mouse.
Although there are multiple computers connected the KVM, however only one can be
controlled at a time. Control of each computer is done separately via the use of switches
on the KVM. It does this by fooling each computer into thinking that it is currently actively
connected to a separate keyboard, mouse and monitor. Since the KVM incorporates only a single
set of keyboard, monitor and mouse, it saves space, cuts cost as well as increase the efficiency of
work done. Along with the ease of control, it saves time and adds valuable flexibility to the whole
system.
19" LDS410D-16P
Specifications
Display Area(mm)
Pixel Pitch
Number of Pixels
Contrast Ratio
Display Color
Brightness(CD/m )
Backlight Unit
Viewing Angle
I/O
Keyboard and Key Pad
Power Consumption
Power Supply
On-Screen Display
Hot Key Control
Environmental Consideration
Humidity
Size
376.3(H)x301.1(V)(19.0-inch diagonal)
0.294(H)x0.294(V)
1280(H)x1024(V)
1300:1
16.7M(8bit/ colors)
2
300
4 replaceable CCFLs edge-light (top/bottom)
-89~89(H);-89~89(V)(typ.)
Power:12V DC adapter (built-in)
Keyboard: PS/2
Mouse:PS/2
VGA:15-pin D-Sub
88-Key keyboard and integrated Touch Pad
17-Key numerical key pad
44 Watts
AC 100-240V Universal
Contrast, Brightness, H/V Position, H/V Size
H-scaling,Auto-adjust,Color Temp.(9300,6500,
User),Red-Gain,Blue-Gain,Green-Gain,Gamma,
Recall,Phase,OSD & Exit
OSD Hot Key
Operating temperature:0 C~50 C (32F~122F)
Storage temperature:-20 C~60 C (-4F~140F)
10~85% in operating;10-90% in storage
544mm(D) x483mm(W) x44.5mm(H)
