How to use washer

Advertisement

Quick Links

H
ow to use washer
1. For use in the initial
Programme (Coloureds)
• Push the Power button to start.
• Push the Start/Pause button.
• Initial condition
- Wash : Only main wash
- Rinse : 3 times
- Spin : 800 rpm
- Program : Coloureds
14

2. Manual Selecting

• Push the Power button to start.
• Select the conditions which you want to
use, by pressing each button.
For selecting the each conditions, please
refer to the page15~page20
• Push the Start/Pause button.

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the WD-1070FD and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for LG WD-1070FD

  • Page 1 ow to use washer 1. For use in the initial 2. Manual Selecting programme (Coloureds) • Push the Power button to start. • Push the Power button to start. • Push the Start/Pause button. • Select the conditions which you want to use, by pressing each button.
  • Page 2 ow to use washer (1) Button : Option (4) Child lock (7) Button : Start/Pause (2) Button : Spin (5) Button : Time Delay (8) Dial : Program (3) Button : Temp. (6) Button : Rapid (9) Button : Power 3.
  • Page 3 ow to use washer Spin • WD-1070(5)F(H)(B) - Whites / Coloureds/Synthetic 800U 1000U Rinse HoldU No SpinU 400U 600 - Delicate 400U 600U 800U Rinse HoldU No Spin - Wool / Hand Wash 400U 600U 800U 1000U Rinse HoldU No Spin [WD-8070F(H)(B)] [WD-1070(5)F(H)(B)] [WD-1170(5)F(H)B]...
  • Page 4 ow to use washer Water Temp. • WD-1370(5)F(H)B • By pushing the Temp - Whites / Coloureds button, the water 800U 1100U 1300U Rinse HoldU temperature can be No SpinU 400U 600 selected. - Synthetic - Cold 800U 1100U Rinse HoldU No SpinU - 30˚C / 40˚C / 50˚C / 60˚C / 400U 600 95˚C...
  • Page 5 ow to use washer Child lock Time Delay Time Left Time Left If you want to lock all the buttons to prevent operation by a child or infirm persons, this 1. Time Delay function can be used. 1. Child lock Preparing washing before starting “Time Delay”...
  • Page 6 ow to use washer Start/Pause Rapid • By pressing the Rapid button, Rapid function is selected. 1. Start 1. Rapid • This Start/Pause button is used to start • Rapid function reduces the whole time wash cycle or pause the cycles. including the washing and rinsing time about by half an hour.
  • Page 7 ow to use washer 3. Completion of washing Display • When washing cycle is completed, “ ” is displayed on the “Multi display”. 1. Special function display 4. Time left • When child lock is selected, the • During washing cycle, the remaining “...
