Oil Mist Detection System
This publication may not be reproduced by any means whatsoever or passed on to any third parties.
8929
HEINZMANN
Engine & Turbine Management
Safety Systems
Triton OMD
CAN Protocol
Copyright 2020 by Heinzmann GmbH & Co. KG. All rights reserved.
Heinzmann GmbH & Co. KG
Engine & Turbine Management
Am Haselbach 1
D-79677 Schönau
Germany
Phone
+49 7673
8208 - 0
Fax
+49 7673
8208 - 188
E-mail
info@heinzmann.de
www.heinzmann.com
V.A.T. No.: DE145551926
Manual SF 19 001-e / 03-20
Advertisement
Table of Contents
Summary of Contents for Heinzmann Triton OMD
- Page 1 Oil Mist Detection System CAN Protocol Copyright 2020 by Heinzmann GmbH & Co. KG. All rights reserved. This publication may not be reproduced by any means whatsoever or passed on to any third parties. Manual SF 19 001-e / 03-20...
- Page 3 All instructions pertaining to the system and safety must be followed in full. Non-observance of the instructions may lead to injury to persons and/or material damage. HEINZMANN shall not be held liable for any damage caused through non-observance of instructions. Independent tests and inspections are of particular importance for all applications in which a malfunction could result in injury to persons or material damage.
- Page 4 HEINZMANN expressly rejects any implied guarantee pertaining to any marketability or suitability for a special purpose, including in the event that HEINZMANN was notified of such a special purpose or the manual contains a reference to such a special purpose.
-
Page 5: Table Of Contents
6.1 Direct sensor number counter command response ............15 6.2 Reverse sensor number counter command response ............. 15 6.3 Sensor configuration CRC invalidity report ..............16 6.4 Measurement value report telegram ................16 6.5 Error status report telegram ................... 17 Triton OMD CAN protocol / Rev.-No. 03... - Page 6 7.6.1 Measurement value report ..................24 7.6.2 Error and status report .................... 25 8 Lists ............................27 8.1 List of figures ........................ 27 8.2 List of tables ........................28 9 Download of manuals ......................29 Triton OMD CAN protocol / Rev.-No. 03...
- Page 7 18.10.2019 Section “7.6.2 Error and status report”: Bit description for OMD Error Status Report data items was revised accord- ing to the latest software state. 20.03.20 External range for temperature parameters was changed. Triton OMD CAN protocol / Rev.-No. 03...
-
Page 9: Safety Instructions And Related Symbols
This symbol does not refer to any safety instructions but offers important notes for better understanding the functions that are being discussed. They should by all means be observed and practiced. Triton OMD CAN protocol / Rev.-No. 03... -
Page 10: Basic Safety Measures For Servicing And Maintenance
• Make sure the control linkage has been reattached and all cables have been recon- nected. • Make sure all safety devices of the installation are in perfect order and are working properly! Triton OMD CAN protocol / Rev.-No. 03... -
Page 11: System Description
Communication in the OMD network is based on the following key functions: • HEINZMANN CAN protocol is used for internode communication within the network. • Each device in the network has its unique ID which is used as node number item of CAN telegram identifiers. - Page 12 2 System description Triton OMD CAN protocol / Rev.-No. 03...
-
Page 13: Heinzmann Can Protocol
3 HEINZMANN CAN protocol 3 HEINZMANN CAN protocol HEINZMANN CAN protocol is based on the CAN specification 2.0B with 29 bit identifier. The identifier contains information about sender and receiver and the command code. Maximum 8 data bytes are therefore available completely for operative data. -
Page 14: Telegram Identifier
Tab. 3.2 Identifier template 3.4 Node numbers For each device type in the HEINZMANN CAN network each node number in the range be- tween 1 and 31 must be assigned only once. Node number 0 is not allowed for a single device, since it is used as the number for messages to all nodes of a certain type. -
Page 15: Omd Network Communication Basics
(mmmmm). Other- wise, the message is processed and corresponding response is transmitted to the produc- er or other predefined actions are performed by the receiver device. Fig. 3.2 Tunneling connection Triton OMD CAN protocol / Rev.-No. 03... - Page 16 3 HEINZMANN CAN protocol Triton OMD CAN protocol / Rev.-No. 03...
-
Page 17: Omd Evaluator Commands Overview
Default 5.4 Network time update com- mand kSensorConfigDataTel1 Default 5.5 Sensor configuration data telegram kInternFunctionRequest Default 5.6 Sensor internal function ex- ecution request telegram Tab. 4.1 Overview of send telegrams Triton OMD CAN protocol / Rev.-No. 03... -
Page 18: Overview Of Receipt Telegrams
6.2 Revers sensor number coun- ter command response kSensorCRCInvalidReport Default 6.3 Sensor configuration CRC invalidity report kMesurementValueReport Default 6.4 Measurement value report kErrorStatusReport Default 6.5 Error and status report Tab. 4.2 Overview of receipt telegrams Triton OMD CAN protocol / Rev.-No. 03... -
Page 19: Send Telegrams Specification
Masters OMD parameter Unix Time High Word Unix Time Low Word set CRC Sensors in the network Tab. 5.2 Command 97 Telegram function details are described in section 7.2 Automatic sensor ID assignment. Triton OMD CAN protocol / Rev.-No. 03... -
Page 20: Network Time Synchronization Command
High byte Low byte High byte Low byte Data item Unix Time High Word Unix Time Low Word Tab. 5.4 Command 50 Telegram function details are described in section 7.3 Network time synchronization. Triton OMD CAN protocol / Rev.-No. 03... -
Page 21: Sensor Configuration Data Telegram
Timeout: not periodical telegram Activation: It is masters responsibility to activate the transmission of this telegram. In HEINZMANN OMD evaluator device it activated with DcDesk option “Error – Clear errors” or corresponding GUI option. Byte 0 Byte 1 Byte 2... - Page 22 5 Send telegrams specification Triton OMD CAN protocol / Rev.-No. 03...
-
Page 23: Receipt Telegram Specification
Low byte High byte Low byte High byte Low byte Data item Sensor Tx. CAN Number Output Counter Tab. 6.2 Command 96 Telegram function details are described in section 7.1 Actual sensor number verification. Triton OMD CAN protocol / Rev.-No. 03... -
Page 24: Sensor Configuration Crc Invalidity Report
High byte Low byte Data item OM Concentration OM Concentration Measured Tempera- Message Counter [mg/l] Alarm Percentage ture Tab. 6.4 Command 20 Telegram function details are described in section 7.5.1 Measurement value report. Triton OMD CAN protocol / Rev.-No. 03... -
Page 25: Error Status Report Telegram
High byte Low byte Data item OMD Error Status Sensor Error State Sensor Output State Reserved Reserved (detailed) Tab. 6.5 Command 40 Telegram function details are described in section 7.5.2 Error and status report. Triton OMD CAN protocol / Rev.-No. 03... - Page 26 6 Receipt telegram specification Triton OMD CAN protocol / Rev.-No. 03...
-
Page 27: General Communication Functions Overview
2582 CanNetFailure = 1. Therefore sensor number verification is not possible with kSensNumDirectCountCommand in such case. The alternative way to verify unit number is using kSensNumReversCountCommand. Triton OMD CAN protocol / Rev.-No. 03... -
Page 28: Sensor Number Verification Failure Scenario
The ID, assigned to each sensor acts as CAN telegram identifier node number item for further communication in the network. Data items within kNetworkIDDistributRequest message: • Actual number of sensors in the network; • Masters configuration parameter set CRC value; • Masters time and date (Unix time). Triton OMD CAN protocol / Rev.-No. 03... -
Page 29: Network Time Synchronization
In case new CRC value is equal to masters configuration pa- rameter set CRC value, sensor stops transmission of kSensorCRCInvalidReport message and start reporting operational data to the master. Triton OMD CAN protocol / Rev.-No. 03... -
Page 30: Configuration Parameter Set
• No XOR is performed on the output CRC. Values 0x0000 and 0xFFFF are not allowed as a final CRC value, calculated through desired data set. In such cases 0x0001 is returned instead. Triton OMD CAN protocol / Rev.-No. 03... -
Page 31: Configuration Data Memory Layout
Bit description for internal function execution command data item is provided in the tables below. Bit Number. Bit function Clear current errors free free free free free free free free free free free free free free free Tab. 7.2 Sensor internal function execution command Triton OMD CAN protocol / Rev.-No. 03... -
Page 32: Sensor Operational Data Reception
2640 - OMAllScore _Sensor1 – 0.0 – 100.0 0 - 65535 2655 OMAllScore _Sensor16 2660 - Temperature_Sensor1 – -128.0 – 128.0 ºC 0 - 65535 2675 Temperature_Sensor16 Tab. 7.3 Sensor measurement value control parameters Triton OMD CAN protocol / Rev.-No. 03... -
Page 33: Error And Status Report
Broken Wire LRD C Broken Wire LRD D Error Scattered Connected Dirty LERD A Dirty LERD B Primary Alarm Pre-Alarm Maintenance free free free free free Common Error Fatal Error Tab. 7.5 OMD-error status bits Triton OMD CAN protocol / Rev.-No. 03... - Page 34 Bit description for sensor output state data items is provided in the tables below. Bit Number. Bit function OMD Alarm OMD Prealarm Maintenance Level1 Maintenance Level2 Ready free free free free free free free free free free free Tab. 7.7 Sensor output state bits Triton OMD CAN protocol / Rev.-No. 03...
-
Page 35: Lists
8 Lists 8 Lists 8.1 List of figures Fig. 3.1 Communication network topology ..............7 Fig. 3.2 Tunneling connection ..................7 Triton OMD CAN protocol / Rev.-No. 03... -
Page 36: List Of Tables
Tab. 7.4 Sensor error and status control parameters ............ 25 Tab. 7.5 OMD-error status bits ..................25 Tab. 7.6 Sensor error state bits ..................26 Tab. 7.7 Sensor output state bits .................. 26 Triton OMD CAN protocol / Rev.-No. 03... -
Page 37: Download Of Manuals
HEINZMANN equipment We would be pleased to receive your comments about the contents and presentation of our publications. Send your comments to the e-mail or address shown above please. Triton OMD CAN protocol / Rev.-No. 03...
